Chapter 4 (Part 2) Network Security

1. Chapter 4 (Part 2)Network Security Chapter 4 – Protection in General-Purpose Operating Systems Section 4.5 User Authentication

2. In this section • Authentication • Passwords • Effective passwords • Breaking passwords • One-Time Systems • Biometrics

3. User Authentication • Most software and OS base there security on knowing who the user is • Authentication based on 1 of 3 qualities: • Something the user knows – Passwords, PIN, passphrase • Something the user has – Key, license, badge, username • Something the user is – physical characteristics or biometrics • Two forms of these can be combined together

4. Passwords as Authenticators • Most common authentication mechanism • Password – a word unknown to users and computers • Problems with passwords: • Loss • Use – time consuming if used on each file or access • Disclosure – if Malory finds out the password might cause problems for everyone else. • Revocation – revoke one persons right might cause problems with others

5. Additional Authentication Information • Placing other condition in place can enforce the security of a password • Other methods: • Limiting the time of access • Limiting the location of access • Multifactor Authentication is using additional forms of authentication • The more authentication factors cause more for the system and administrator to manage

6. Attacks on Passwords • Figuring out a password • Try all possible passwords • Try frequently used passwords • Try passwords likely for the user • Search for the system password list • Ask the user • Loose-Lipped Systems • Authentication system leaks information about the password or username • Provides information at inconvenient times

7. Exhaustive Attack • Brute force attack is when the attacker tries all possible passwords • Example: • 26 (A-Z)character password of length 1 to 8 characters • One password per millisecond would take about two months • But we would not need to try every password

8. Password Problems • Probable Passwords • Passwords Likely for a user • Weakness is in the users choice • Weakness is in the control of the system • Look at table 4-2 on page 225

9. Figure 4-15  Users’ Password Choices.

10. Password Selection Criteria • Use characters other than just A-Z • Choose long passwords • Avoid actual names or words • Choose an unlikely password • Change the password regularly • Don’t write it down • Don’t tell anyone else – beware of Social Engineering

11. One-Time Passwords • Password that changes every time • Also known as a challenge-response systems • F(x)=x+1 - use of a function • F(x)=r(x) – Seed to a random number generator • F(a b c d e f g) = b d e g f a c – transformation of a character string • F(E(x))=E( D (E (x)) + 1 ) – Encrypt value must be decrypted and run through a function

12. The Authentication Process • Slow response from system • Limited number of attempts • Access limitations • Fixing Flaws with a second level of protection • Challenge-Response • Impersonation of Login

13. Biometrics • Biometrics are biological authenticators • Problems with Biometrics • Still a relatively new concept • Can be costly • Establishing a threshold • Single point of failure • False positives • Speed can limit accuracy • Forgeries are possible
