  1. Human Osteology ASA Bio 2014 Williams

  2. Major Divisions of the Body • Cranial – skull • Infracranial – the rest of the body • Axial – trunk & head (parts in midline) • Appendicular – appendages/ limbs • Includes pelvic and shoulder girdles

  3. Upper Limb • Clavicle • Scapula • Humerus • Radius • Ulna • Carpals • Metacarpals • Phalanges

  4. Clavicle • 1 right & 1 left • Articulates with sternum medially and scapula laterally • Part of shoulder girdle

  5. Scapula • 1 right & 1 left • Articulates with clavicle and humerus • Does NOT articulate with ribs • Part of shoulder girdle

  6. Humerus • 1 right & 1 left • Articulates with scapula, ulna & radius

  7. Ulna • 1 right & 1 left • Articulates with humerus & radius • Connected to radius by interosseous membrane • Does NOT articulate with carpal bones

  8. Radius • 1 right & 1 left • Articulates with humerus, ulna, and proximo-lateral aspect of carpal bones • Connected to ulnaby interosseous membrane

  9. Carpals • Bones of the wrist • 8 elements (per side) • 2 rows of 4 • Proximal row articulates with radius • Distal row articulates with metacarpals

  10. Metacarpals • Bones of the hand • 5 elements (per side) • Articulate with distal row of carpals and phalanges • Numbered lateral to medial • MC1 – MC5

  11. Manual Phalanges • Bones of the fingers • 14 elements (per side) • Separated into three rows • Proximal phalanges (5) • Intermediate phalanges (4) • Distal phalanges (5) • Singular – phalanx Intermediate

  12. Lower Limb • Innominate • Femur • Patella • Tibia • Fibula • Tarsals • Metatarsals • Phalanges

  13. Innominate • Oscoxa • 1 right & 1 left • Articulate with sacrum posteriorly, other innominate anteriorly, and femur laterally

  14. Innominates • 3 parts • Ilium • Ischium • Pubis

  15. Femur • 1 right & 1 left • Considered strongest bone • Articulates with innominate, tibia, and patella

  16. Patella • 1 right & 1 left • Sesamoid bone • Articulates only with femur

  17. Tibia • 1 right & 1 left • Articulates with femur, fibula and talus (tarsal bone) • Weight bearing bone of the lower leg • Connected to fibula with interosseous membrane

  18. Fibula • 1 right & 1 left • Non-weight bearing • Articulates with tibia and talus (tarsal bone) • Connected to tibia by interosseous membrane

  19. Tarsals • Bones of the ankle • 7 elements (per side) • Articulate with each other, tibia, fibula, and metatarsals

  20. Metatarsals • Bones of the foot • 5 elements (per side) • Numbered medially to laterally • MT1 – MT5 • Articulate with tarsals and phalanges

  21. Pedal Phalanges • Bones of the toes • 14 elements (per side) • Separated into three rows • Proximal phalanges (5) • Intermediate phalanges (4) • Distal phalanges (5) • Singular – phalanx
