1 / 11

Correlation and Causation

Correlation and Causation. Part I – Scatterplots. This video is designed to accompany pages 19-24 in Making Sense of Uncertainty Activities for Teaching Statistical Reasoning Van- Griner Publishing Company. Vernacular. cor·re·la·tion [ kàwrə láysh'n ]

questa
Télécharger la présentation

Correlation and Causation

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Correlation and Causation Part I – Scatterplots

  2. This video is designed to accompany pages 19-24 in Making Sense of Uncertainty Activities for Teaching Statistical Reasoning Van-Griner Publishing Company

  3. Vernacular cor·re·la·tion [ kàwrəláysh'n] mutual or complementary relationship: a relationship in which two or more things are mutual or complementary relatedness of variables: the degree to which two or more variables are related and change together

  4. Example Variables: Height and Weight Bigger values of Height tend to be associated with bigger values of Weight.

  5. Scatterplot A scatterplot of height (y-axis) versus weight (x-axis) would likely look something like this.

  6. Other Scatterplots Plots! Oh No! Student Grades LDL Levels Time Spent Studying Hours Exercised Life Expectancy at Birth Final Exam Score GNP per capita Quiz Average

  7. Language of Association positive association - points have an upward trend from left to right negative association - points have a downward trend from left to right strength- points are tightly clustered about some clear pattern (maybe straight line) Often the word “correlation” is used interchangeably with “association.” That’s OK until we get more technical.

  8. Scatterplots Revisited Plots! Oh Yeah! Student Grades LDL Levels Negative Pretty Strong Positive Moderately Strong Time Spent Studying Hours Exercised Life Expectancy at Birth Final Exam Score Positive Arguably Pretty Strong Not Straight Line Not Very Strong GNP per capita Quiz Average

  9. Using Your Eyes Scatterplots Visual way of assessing association, both direction and strength. Makes sense as long as you have two variables that you can display in a scatterplot

  10. Association Between Gender and Hours Spent Doing Homework What do you see?

  11. One-Sentence Reflection Simple scatterplots are an informal, but useful visual means of addressing both the direction and strength of the relationship between two variables that are appropriate for this kind of plot.
