  1. CREATIVE TELECOM PVT. LTD. MAGIC CLI-308 SL

  2. CPU CARD • CPU CARD CONSISTS OF FOLLOWING HARDWARE :- • SERIAL PORT-RS232 • EXTERNAL MUSIC PORT • DTMF DIALER / RECEIVER • IN BUILT MUSIC ON HOLD • REMOTE PROGRAMMING

  3. PSU CARD • INBUILT UPS CIRCUIT ALONG WITH BATTERY CHARGER. • LOW BATTERY CUT OFF TO PROTECT THE BATTERIES AGAINST DEEP DISCHARGE. • BATTERIES GETS CHARGED EVEN IF SYSTEM IS SWITCHED OFF.

  4. CPL CARD • 3 METAL OXIDE VARISTORS (MOV) AND POSITIVE TEMPRATURE CO-EFFICIENT (PTC) - RESETTABLE FUSES ARE PROVIDED ON P&T LINES TO PROTECT AGAINST HIGH VOLTAGES / EXCESSIVE CURRENT. • EXTENSIONS ARE ALSO PROTECTED WITH MOV’S AGAINST HIGH VOLTAGE. • EACH P&T LINE AND EXTN HAS HYBRID TRANSFORMER FOR ISOLATION & BALANCING.

  5. UNIQUE SELLING POINTS • Least Cost Routing. • CLI Based Routing. • Caller ID on Simultaneous Ringing. • Dialed Number (DNI) shown as Caller ID while transferring the call. • Call Progress Visual Indication on Trunk. • Computer Connectivity for Call Management. • Programming Data / Password of the system is stored in Flash RAM, which never gets erased in power off / power fluctuation.

  6. UNIQUE FEATURES • Caller Id : Internal / External / Transferable. • Video Door Phone Connectivity. • Buffer Memory for Incoming / Outgoing Calls. • Printout of Unanswered Calls. • Operator Dialing by “9”. • Delayed Hotline. • Boss Secretary System • Programmable Flash Timing of Individual Extension. • Automatic Day / Night Mode. • Auto Redial

  7. UNIQUE FEATURES • Walking Call of Service. • Auto Call Disconnection. • Programmable Do Not Disturb. • REMOTE MAINTENANCE. • DISA/DOSA. • JUNCTION/EXTENSION/BUFFER DISPLAY. • DYNAMIC STD/ISD LOCK FOR EACH EXTN. • DIRECT CALL BILLING IN RUPEES ON SERIAL PORT.

  8. THANK YOU ! FOR FURTHER CLARIFICATION, PLEASE CONTACT CREATIVE TELECOM PVT. LTD. 162, DSIDC COMPLEX, PHASE – I, OKHLA INDUSTRIAL AREA, NEW DELHI – 110 020. PH.: 26811492 / 26811496 / 26817414 EMAIL:- creative@ndb.vsnl.net.in sales@creativetele.com
