  1. CadSoft EAGLE Award-winning PCB Design software that it’s at the head of its class Welcome to the EAGLE Webinar January, 26th 2011

  2. Easily • Applicable • Graphical • Layout • Editor

  3. Schematic Editor • Layout Editor • Autorouter • Library Editor • CAM Processor • User Language Programming

  4. EAGLE Freemium at element14.com • All Features of EAGLE enabled • Up to 4 schematic sheets per design • Board size limit of approximately 100mm x 80mm. • Capable of handling up to 4 signal layers (internal layers can be assigned to supply signals) • Available for Windows, Linux and Mac operating systems • Limited to a period of 60 days

  5. Farnell Order Codes for Commercial EAGLE Licences L S R Modules Layout Editor Schematic Editor Autorouter L S LS LR LSR Possible Combinations 1 3 5 10 30 50 Number of Users CP CS Commercial Editions Commercial Standard Commercial Professional Professional Edition L: 16 Layer,1600mm x1600mm S: 999 Sheets Standard Edition L: 6 Layer, 160mm x 100mm S: 99 Sheets CP CS Additional available: CL Light Edition only LSR, Limitation: L:2 Layer, 100mm x 80mm S:1 Sheet LSR-1CL 1813739
