  1. Registration Helper Classes Stephen Aylward Matt Turek Luis Ibanez

  2. Goals • Increase the speed of image registration in ITK • Provide Slicer modules for image registration • Provide Slicer modules for batch image registration • Reduce the effort and expertise required for ITK image registration

  3. Outline • ITK Image Registration Helper class • Features • Slicer Modules • Status and Future Work

  4. Image Registration Helper Class • Multi-threaded • Implicitly handles oriented images • Options (via enumerations): • Transforms • VersorRigid3D, Affine, BSplines • Metrics • MattesMI, NormalizedCorrelation, MeanSquaredError • Interpolators • Linear, BSpline, Windowed Sinc • Optimizers • Gradient • FRPR for Rigid/Affine and LBFSGB for BSpline • Multi-resolution • 3-levels, Gradient at each level • Evolutionary • OnePlusOne followed-by Gradient • Initialization • Centers of Images, Centers of Mass, Second Moments

  5. Image Registration Helper Class • Examples of member functions • LoadParameters( std::string filename ) • “T1-T2-BrainRegistration.prm”, “CT-CT-LiverRegistration.prm”, “MyProjectsRegistration.prm” • Simplifies batch processing • SetExpectedOffsetMagnitude( double expectedOffset ) • Used to calculate scales for rigid/affine optimization • SetBSplineControlPointPixelSpacing( double controlPointSpacing ) • Used to calculate number of control points for BSplines • Update( void ) • Load transform and resample moving image • Initial registration • Rigid registration • Affine registration • BSpline registration

  6. Image Registration Helper Class • Default behavior of Update() • Initial • Centers of mass • Rigid • Versor3D + MattesMI + LinearInterpolation + SamplingRatio=0.05 + EvolutionaryOptimization + MaxIterations=100 + … • Affine • Affine + MattesMI + LinearInterpolation + SamplingRatio=0.10 + Gradient + MaxIterations=100 + … • BSpline • BSpline + MattesMI + BSplineInterpolation + SamplingRatio=0.2 + Gradient + MaxIterations=50 + ControlPointPixelSpacing=20

  7. Usage #include “itkImageToImageRegistrationHelper.h” Int main(int argc, char *argv[]) { typedef itk::OrientedImage< short, 3> ImageType typedef itk::ImageToImageRegistrationHelper< ImageType > RegType; RegType::Pointer reg = RegType::New(); reg->LoadFixedImage( argv[1] ); reg->LoadMovingImage( argv[2] ); reg->LoadParameters( argv[3] ); reg->SetRigidOptimizationMethodEnum( RegType::MULTIRESOLUTION_OPTIMIZATION ); reg->Update(); reg->SaveImage( argv[4], reg->GetFinalMovingImage() ); }

  8. Internal Class Hierarchy itkProcessObject itkImageToImageRegistrationMethod itkOptimizedImageToImageRegistrationMethod itkInitialImageToImageRegistrationMethod itkRigidImageToImageRegistrationMethod itkAffineImageToImageRegistrationMethod = Derives from itkBSplineImageToImageRegistrationMethod

  9. Multi-threaded

  10. New Slicer Modules • Status: • Requires CVS ITK • CMake enable: • ITK_USE_REVIEW • ITK_USE_OPTIMIZED_REGISTRATION_METHODS • Bug in Optimized Linear Interpolation • Parameter tweaking • Testing modules: oriented images, etc. • RegisterImages • BatchRegisterImages

  11. NAMIC DTI Atlas Registration Atlas = FixedImage = Red Channel = ICBM DTI Atlas: ICBM_T2.nhdr Subject = MovingImage = Green Channel = 01009-t2w.nrrd

  12. More Information • IJ article on multi-threaded registration • Article on modifications to ITK pending • Matt Turek et al. • Thanks Matt Turek and Luis Ibanez!!!

  13. Future Work • Fix linear interpolation • Testing and tweaking • Oriented images • Manage memory requirements • itkOptimization.h: typedef Array< double > ParametersType; • Speed • BSplines: • Only process control points that contain samples
