  1. Design and optimization of multicolor panels Holden T. Maecker

  2. Outline • Choosing fluorochrome combinations and filter sets • Matching antibody specificities with fluorochromes • Controls and standardization

  3. Outline • Choosing fluorochrome combinations and filter sets • Choose bright fluorochromes • Minimize spillover between detectors

  4. D Where D = difference between positive and negative peak medians, and W = 2 x rSD (robust standard deviation) “Bright” = good resolution sensitivity W1 W2

  5. Various fluorochromes-stain index

  6. Spillover affects resolution sensitivity FITC background contributes noise to PE measurement www.bdbiosciences.com/spectra

  7. Choices for 6-, 8-, 10-, and more colors

  8. Outline • Choosing fluorochrome combinations and filter sets • Matching antibody specificities with fluorochromes • Controls and standardization

  9. Fluorochrome selection considerations • “Bright” antibodies go on “dim” fluorochromes • Avoid spillover from bright cell populations into detectors requiring high sensitivity • Take special care with tandem dyes

  10. Data spread of fluorescent signals compensated uncompensated data spread FITC mean fluorescence PE mean fluorescence ---------------------------- ---------------------------- negative positive negative positive ----------- ---------- ----------- ---------- uncompensated 123 3541 184 1648 compensated 123 3564 134136 HT Maecker, T Frey, LE Nomura, J Trotter: Selecting fluorochrome conjugates for maximum sensitivity. Cytometry A 2004, 62:169-73.

  11. Spillover affects resolution sensitivity Without CD45 AmCyan: With CD45 AmCyan: CD19 FITC Note that this is only an issue when the two markers (CD45 and CD19) are co-expressed on the same cell population.

  12. Special requirements of tandem dyes • Compensation requirements for tandem dye conjugates can vary, even between two experiments with the same antibody • Require experiment-specific compensation • Certain tandem dye conjugates (APC-Cy7, PE-Cy7) can degrade with exposure to light, elevated temperature, and fixation • Minimize exposure to these conditions • Use BD Stabilizing Fixative for final fixation

  13. False positives due to tandem degradation A. With CD8 APC-Cy7 and CD4 PE-Cy7: Gating scheme CD8 APC-Cy7+ cells CD4 PE-Cy7+ cells False positives in APC channel reduced in absence of APC-Cy7 False positives in PE channel remain B. Without CD8 APC-Cy7:

  14. CD4 APC-Cy7 CD8 APC-Cy7 CD4 APC-H7 CD8 APC-H7 New tandems will be more stable • APC-H7 as a replacement for APC-Cy7: Comparison of Sample Stability (in BD Stabilizing Fixative at RT) 250 200 150 % Spillover 100 50 0 0 1 2 4 6 8 24 48 Hours of light exposure

  15. Outline • Choosing fluorochrome combinations and filter sets • Matching antibody specificities with fluorochromes • Controls and standardization

  16. Types of controls • Instrument setup controls • PMT voltage settings • Compensation (per experiment) • Gating controls • Isotype controls • Fluorescence-minus-one (FMO) controls • Biological controls • Unstimulated samples • Healthy donors

  17. Comparison of gating controls

  18. Standardization using lyophilized reagents • Lyophilization provides increased stability, even at room temperature or 37oC • One batch of reagents can be used for an entire longitudinal study • Pre-configured plates can avoid errors of reagent addition • Complex experiments (multiple stimuli, multiple polychromatic staining cocktails) become easier • Lyophilized cell controls can provide run-to-run standardization

  19. Conclusions • Polychromatic flow cytometry is not impossible • Select fluorochromes for brightness and least spillover • Optimize antibody panels by taking into account reagent brightness and data spread • Stabilize longitudinal experiments with proper QC • Some solutions that can help • Lyophilized reagent plates • Stabilizing fixative • Beads for calibration and compensation

  20. References • Maecker, H. T., Frey, T., Nomura, L. E., and Trotter, J. (2004).Selecting fluorochrome conjugates for maximum sensitivity. Cytometry A62, 169. • Maecker, H. T., and Trotter, J. (2006).Flow cytometry controls, instrument setup, and the determination of positivity. Cytometry A69, 1037.

  21. Acknowledgements • Laurel Nomura • Margaret Inokuma • Maria Suni • Smita Ghanekar • Daiva Gladding • Jack Dunne • Skip Maino • Joe Trotter • Dennis Sasaki • Marina Gever
