BST addElement. To addElement(), we essentially do a find( ). When we reach a null pointer, we create a new node there. void addElement(Object el, BinaryTreeNode t) { if (t == null) t = new BinaryTreeNode(el, null, null); else if (el < t.element) addElement(el, t.left);

Télécharger la présentation
## BST addElement

**An Image/Link below is provided (as is) to download presentation**
Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.
Content is provided to you AS IS for your information and personal use only.
Download presentation by click this link.
While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.
During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

**BST addElement**• To addElement(), we essentially do a find( ). When we reach a null pointer, we create a new node there. void addElement(Object el, BinaryTreeNode t) { if (t == null) t = new BinaryTreeNode(el, null, null); else if (el < t.element) addElement(el, t.left); else if (x > t.element) addElement(x, t.right); else ; // duplicate; do appropriate thing } • Can be implemented iteratively. TCSS 342 BST v1.0**5**4 8 1 7 11 3 findMin, findMax • To find the maximum element in the BST, we follow right children until we reach NULL. • To find the minimum element in the BST, we follow left children until we reach NULL. TCSS 342 BST v1.0**BST remove**• Removing an item disrupts the tree structure. • Basic idea: find the node that is to be removed. Then “fix” the tree so that it is still a binary search tree. • Three cases: • node has no children • node has one child • node has two children TCSS 342 BST v1.0**5**4 8 1 7 11 3 5 4 8 1 7 11 3 No children, one child TCSS 342 BST v1.0**5**4 8 1 7 11 3 7 4 8 1 7 11 3 Two children • Replace the node with its successor. Then remove the successor from the tree. TCSS 342 BST v1.0**Height of BSTs**• n-node BST: Worst case depth: n-1. • Claim: The maximum number of nodes in a binary tree of height h is 2h+1 – 1. Proof: The proof is by induction on h. For h = 0, the tree has one node, which is equal to 20+1 – 1. Suppose the claim is true for any tree of height h. Any tree of height h+1 has at most two subtrees of height h. By the induction hypothesis, this tree has at most 2(2h+1 – 1)+1 = 2h+2 – 1. TCSS 342 BST v1.0**Height of BSTs, cont’d**• If we have a BST of n nodes and height h, then by the Claim, n 2h+1 – 1. So, h log (n+1) – 1. • Average depth of nodes in a tree. Assumptions: insert items randomly (with equal likelihood); each item is equally likely to be looked up. • Internal path length: the sum of the depths of all nodes. TCSS 342 BST v1.0**r**TR TL Average Depth • Let D(n) be the internal path length of some tree with n nodes. • The left subtree has i nodes, and the right subtree has n–i–1 nodes. • D(1) = 0 • D(n) = D(i) + D(n – i – 1) + n – 1 TCSS 342 BST v1.0**D(n) 1.442 n log n**• How long does it take to insert the items 1, 2, 3, …, n (in that order) into a BST? • What if they were inserted so that the resulting BST were perfectly balanced? TCSS 342 BST v1.0
