Security Methods for Statistical Databases by Karen Goodwin

1. Security Methods for Statistical Databasesby Karen Goodwin

2. Introduction • Statistical Databases containing medical information are often used for research • Some of the data is protected by laws to help protect the privacy of the patient • Proper security precautions must be implemented to comply with laws and respect the sensitivity of the data

3. Accuracy – Researchers want to extract accurate and meaningful data Confidentiality – Patients, laws and database administrators want to maintain the privacy of patients and the confidentiality of their information Accuracy vs. Confidentiality

4. Laws • Health Insurance Portability and Accountability Act – HIPAA (Privacy Rule) • Covered organizations must comply by April 14, 2003 • Designed to improve efficiency of healthcare system by using electronic exchange of data and maintaining security • Covered entities (health plans, healthcare clearinghouses, healthcare providers) may not use or disclose protected information except as permitted or required • Privacy Rule establishes a “minimum necessary standard” for the purpose of making covered entities evaluate their current regulations and security precautions

5. HIPAA Compliance • Companies offer 3rd Party Certification of covered entities • Such companies will check your company and associating companies for compliance with HIPAA • Can help with rapid implementation and compliance to HIPAA regulations

6. Static – a static database is made once and never changes Example: U.S. Census Dynamic – changes continuously to reflect real-time data Example: most online research databases Types of Statistical Databases

7. Security Methods • Access Restriction • Query Set Restriction • Microaggregation • Data Perturbation • Output Perturbation • Auditing • Random Sampling

8. Access Restriction • Databases normally have different access levels for different types of users • User ID and passwords are the most common methods for restricting access • In a medical database: • Doctors/Healthcare Representative – full access to information • Researchers – only access to partial information (e.g. aggregate information)

9. Query Set Restriction • A query-set size control can limit the number of records that must be in the result set • Allows the query results to be displayed only if the size of the query set satisfies the condition • Setting a minimum query-set size can help protect against the disclosure of individual data

10. Query Set Restriction • Let K represents the minimum number or records to be present for the query set • Let R represents the size of the query set • The query set can only be displayed if K  R

11. Query Set Restriction

12. Microaggregation • Raw (individual) data is grouped into small aggregates before publication • The average value of the group replaces each value of the individual • Data with the most similarities are grouped together to maintain data accuracy • Helps to prevent disclosure of individual data

13. Microaggregation • National Agricultural Statistics Service (NASS) publishes data about farms • To protect against data disclosure, data is only released at the county level • Farms in each county are averaged together to maintain as much purity, yet still protect against disclosure

14. Microaggregation

15. Microaggregation

16. Data Perturbation • Perturbed data is raw data with noise added • Pro: With perturbed databases, if unauthorized data is accessed, the true value is not disclosed • Con: Data perturbation runs the risk of presenting biased data

17. Data Perturbation

18. Output Perturbation • Instead of the raw data being transformed as in Data Perturbation, only the output or query results are perturbed • The bias problem is less severe than with data perturbation

19. Output Perturbation Query Results Results Query

20. Auditing • Auditing is the process of keeping track of all queries made by each user • Usually done with up-to-date logs • Each time a user issues a query, the log is checked to see if the user is querying the database maliciously

21. Random Sampling • Only a sample of the records meeting the requirements of the query are shown • Must maintain consistency by giving exact same results to the same query • Weakness - Logical equivalent queries can result in a different query set

22. Comparison Methods • Security – possibility of exact disclosure, partial disclosure, robustness • Richness of Information – amount of non-confidential information eliminated, bias, precision, consistency • Costs – initial implementation cost, processing overhead per query, user education The following criteria are used to determine the most effective methods of statistical database security:

23. A Comparison of Methods 1 Quality is low because a lot of information can be eliminated if the query does not meet the requirements

24. Sources • This presentation is posted onhttp://www.cs.jmu.edu/users/aboutams • Adam, Nabil R. ; Wortmann, John C.; Security-Control Methods for Statistical Databases: A Comparative Study; ACM Computing Surveys, Vol. 21, No. 4, December 1989 (http://delivery.acm.org/10.1145/80000/76895/p515-adam.pdf?key1=76895&key2=1947043301&coll=portal&dl=ACM&CFID=4702747&CFTOKEN=83773110) • Official HIPAA – (http://cms.hhs.gov/hipaa/) incur • Bernstein, Stephen W.; Impact of HIPAA on BioTech/Pharma Research: Rules of the Road (http://www.privacyassociation.org/docs/3-02bernstein.pdf) • Service Bureau; 3rd Party Testing (http://hipaatesting.com/service_bureau.html)
