Optimizing Surface Roughness for Enhanced Functional Properties in Mechanical Engineering

shanna avatar
shanna
13 diapositives · 284 Views · Sep 25, 2014

This report presents a novel methodology for optimizing surface roughness in mechanical engineering applications. It focuses on selecting the most suitable roughness values to improve the strength of joints formed through hot pressing. By employing non-parametric criteria, the study evaluates the impact of surface roughness on component performance. Key findings include optimal processing parameters for threaded collars and shafts, as well as graphical representations of roughness distributions. The methodology provides a comprehensive framework for precise roughness assessment and control in production environments.

#optimizing surface roughness for enhanced functional properties in mechanical engineering #optimizing surface roughness for enhanced functional properties in mechanical engineering ppt #powerpoint #presentation
Optimizing Surface Roughness for Enhanced Functional Properties in Mechanical Engineering - slide 1
01 / 13Optimizing Surface Roughness for Enhanced Functional Properties in Mechanical Engineering
1 / 17

Télécharger la présentation

Optimizing Surface Roughness for Enhanced Functional Properties in Mechanical Engineering
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. METHODOLOGY FOR OPTIMIZING THE INFLUENCE OF SURFACE ROUGHNESS ON THE FUNCTIONAL PROPERTIES OF DETAILS IN MECHANICAL ENGINEERING Dipl. eng. Leonov D., PhD Ivanov A., Phd Lilov I.

  2. Purpose of the report The article deals with a fundamentally new methodology for optimization, assessment, and control of the roughness of surfaces that can be applied in all production facilities. What is meant by optimization is the choice of the most appropriate roughness from among all the practically possible values that can be achieved in certain production conditions. The given methodology is used as a basis for the assessment of the influence of surface roughness on the strength of a joint formed through the process of hot pressing.

  3. y yp Rmax m yv m l Roughness parameters according toISO 4287

  4. The profiles with equal parameters The profiles describing absolutely different microrelief have equal parameters

  5. Non – paramterical approach for evaluation and control of surface roughness A method by using non-parametric criterions and as such the graphics of different functions are taken : • functions of distribution of the ordinates of the profile or the tangents of the angles of the profile’s gradien ; • density of distribution of the ordinates of the profile or angles’ tangents of the profile’s gradient .

  6. The physical sense of non-parametric criterions

  7. d D l Object of testing A hot-pressed joint with a nominal diameter of contact area D = 20 mm, external diameter of the threaded collar d = 30 mm, length of contact area l = 20 mm. Under exploitation the joint is loaded with axis force F = 6,65.10³N.

  8. Technology of manufacture of each model

  9. Graphics of the groups of models The graphics of non-parametric criteria „Density of distribution of the angles’ tangents of the profile’s gradient” of models: а) for the threaded collars, b) for the shafts. The X axis – value of the angles’ tangents of the profile’s gradient. The Y axis – frequency of emergence of the angles’ tangents of the profile’s gradient.

  10. Results

  11. Results and discussion • - a mathematical model relating the optimization parameter with the technological modes of processing and making it possible to forecast the level of force required for un-pressing with variations of the above-mentioned factors ; • - technological modes of processing which produce an optimal surface roughness, guaranteeing the highest level of force required for un-pressing S threaded collar = 0,43 m/min, V threaded collar = 37,5 m/s, Sshaft = 0,467 m/min, Vshaft = 36 m/s • - optimal surface roughness of the following machine parts «Threaded collar» and «Shaft», which can be controlled through the use of non-parametric criteria

  12. Control of the roughness The optimal graphics“Density of distribution of the angles’ tangents of the profile’s gradient”and the deviation tolerances for: а) the threaded collars, b) the shafts. The X axis – value of the angles’ tangents of the profile’s gradient. The Y axis – frequency of emergence of the angles’ tangents of the profile’s gradient.

  13. Conclusion The use of standard parameters to assess and control the surface roughness of machine parts, appliances and machines has only one advantage – the simplicity of its practical use. When we are looking for a complex criterion dependent on several factors, it is simply impossible to apply numerical criteria because they do not allow for the optimal characteristic (the most appropriate of all the possible ones) of the normed functional property of the surface to be accurately defined with a practicable degree of accuracy. The functions of density of distribution and the functions of distribution of ordinates and tangents of the angles of inclination of the pattern unequivocally define the roughness of surfaces and fully satisfy the legitimate requirement of a thorough and comprehensive definition.
