  1. TLETS Re-Engineering TxDPS Information Management Svc. May 5, 2006

  2. Agenda • Current Project Status • Benefits, Features, Enhancements • Getting Your Agency Prepared • Questions

  3. State of the Project • Computers and Software installed at TxDPS Headquarters • Phase I - new core network has been installed at TxDPS headquarters – 4/2/06 • Connections established with NCIC, NLETS, and MVD • Connectivity with TxDPS repositories: TCIC, Driver License, and CCH.

  4. State of the Project • Bridge programs in Legacy TLETS • Legacy TLETS converted to intercept and route all messages through new system • Phase II - Ongoing screen testing continues. Target date of 5/19/06

  5. Benefits • Logs stored in a relational database system • Capability for monitoring traffic real-time • Improved reporting features • More statistics • Weather messages delivered to county codes

  6. Features • Support for additional Message Keys • Commercial Vehicle • Wildlife Crime Inquiry • Query Probation Information • Driver License Name Query • Local Logs • Distance Broadcast

  7. Enhancements • Forward a received message • Populate a form with a sent message • Drop down list boxes for lookup values • Spell Check • Intuitive user interface • Configurable

  8. Minimum Requirements • Complete CJIS Security Package • To be CJIS compliant, all computers processing CJIS data must be firewalled (NIST certified) from the Internet and any other public access connectivity.

  9. Small Site – Satellite - no NAT • 1 terminal, network address translation (NAT) not required DPS Supplied Equipment • Router – DPS supplied Personal Earth Station (PES) Agency Supplied Equipment • PC/Workstation with minimum • CPU Type/Speed - Pentium 600Mghz or above • Memory - 128 MB • Display Resolution – 1024x768 • Disk Space – 50 MB • Operating System – Win 98 or newer • TCP/IP Network Interface Card (NIC)

  10. Medium Site – Satellite - no NAT • 16 terminals or less, NAT not required DPS Supplied Equipment • Router – DPS supplied PES Agency Supplied Equipment • Switch – 100 Mbps full duplex switch with enough ports for all terminals and printers • Interface/Gateway/CAD – Server with sufficient capacity to manage data flow from all assigned terminal devices • PC/Workstation with minimum: • CPU Type/Speed - Pentium 600Mghz or above • Memory - 128 MB • Display Resolution – 1024x768 • Disk Space – 50 MB • Operating System – Win 98 or newer • TCP/IP Network Interface Card (NIC)

  11. Medium Site – Satellite - NAT • 16 terminals or less on satellite, NAT required • DPS Supplied Equipment • PES • Agency Supplied Equipment • Router – Any standard router with console access for configuration changes • 100 Mbps Ethernet port • Switch – 100 Mbps full duplex switch with enough ports for all terminals and printers • Interface/Gateway/CAD – Server with sufficient capacity to manage data flow from all assigned terminal devices • PC/Workstation with minimum: • CPU Type/Speed - Pentium 600Mghz or above • Memory - 128 MB • Display Resolution – 1024x768 • Disk Space – 50 MB • Operating System – Win 98 or newer • TCP/IP Network Interface Card (NIC)

  12. Large Site – Satellite - no NAT • 17 terminals or more on satellite, NAT not required • DPS Supplied Equipment • Router – DPS supplied PES • Agency Supplied Equipment • Switch – 100 Mbps full duplex switch with enough ports for all terminals and printers • Interface/Gateway/CAD – Server with sufficient capacity to manage data flow from all assigned terminal devices • PC/Workstation with minimum: • CPU Type/Speed - Pentium 600Mghz or above • Memory - 128 MB • Display Resolution – 1024x768 • Disk Space – 50 MB • Operating System – Win 98 or newer • TCP/IP Network Interface Card (NIC)

  13. Large Site – Satellite - NAT • 17 terminals or more on satellite, NAT required DPS Supplied Equipment • PES Agency Supplied Equipment • Router – Any standard router with console access for configuration changes • 100 Mbps Ethernet port • Switch – 100 Mbps full duplex switch with enough ports for all terminals and printers • Interface/Gateway/CAD – Server with sufficient capacity to manage data flow from all assigned terminal devices • PC/Workstation with minimum: • CPU Type/Speed - Pentium 600Mghz or above • Memory - 128 MB • Display Resolution – 1024x768 • Disk Space – 50 MB • Operating System – Win 98 or newer • TCP/IP Network Interface Card (NIC)

  14. Large Site – Terrestrial - NAT • 17 terminals or more over terrestrial connectivity, NAT required DPS Supplied Equipment • FRATM connectivity commensurate with traffic demands at each specific location

  15. Large Site – Terrestrial - NAT Agency Supplied Equipment • Extranet Router – Cisco 2821 (no substitutions) configured as follows: • CISCO 2821 Security Bundle,AIM-VPN-EPII-PLUServ,64F/256D,HSEC/K9 • AIM-VPN/EPII- DES/3DES/AES VPN Encryption/Comp Plus • MEM2800-256D- 256 MB DDR DRAM Memory factory default 2800 • MEM2800-64CF- 64MB CF default for Cisco 2800 series • NM-28/38BLNK Cisco 2800 and 3800 Series Blank Panel • Pwr-2821-51-AC Cisco 2821/51 AC power supply • ROUTER-SDM Device manager for routers • S28NAISK9- Cisco 2800 IOS ADVANCED SERVICES 12308T • WIC-BLANK- Blank WAN Interface Panel • CAB-AC Power Cord, 110V • WIC-1DSU-T1-V2 Updated 1-Port T1/Fractional T1 DSU/CSU Card

  16. Large Site – Terrestrial - NAT Agency Supplied Equipment • PC/Workstation with minimum: • CPU Type/Speed - Pentium 600Mghz or above • Memory - 128 MB • Display Resolution – 1024x768 • Disk Space – 50 MB • Operating System – Win 98 or newer • TCP/IP Network Interface Card (NIC)

  17. Communications 900 local agencies, 400 DPS sites • TLETS Website has newsletters and documentation regarding the protocol. To obtain the address, send an email to: tlets@txdps.state.tx.us tena.watson@txdps.state.tx.us
