# 5-bit Decimation Filter

5-bit Decimation Filter. Loretta Chui, Xiao Zhuang Hock Cheah, Gita Kazemi Advisor: David Parent December 6, 2004. Agenda. Abstract Introduction Project Details Results Cost Analysis Conclusions. Abstract.

Télécharger la présentation

## 5-bit Decimation Filter

E N D

### Presentation Transcript

1. 5-bit Decimation Filter Loretta Chui, Xiao Zhuang Hock Cheah, Gita Kazemi Advisor: David Parent December 6, 2004

2. Agenda • Abstract • Introduction • Project Details • Results • Cost Analysis • Conclusions

3. Abstract • We designed a 5-bit Decimation Filter, which can be used to sample the output of an A/D converter at a lower rate. Our system operates at 143 MHz, uses less than 100 mW of power, and occupies an area of 360 x 280 mm2.

4. Introduction • The averaging filter used at the output of an A/D converter is called a decimation filter. • The decimation filter samples the incoming data until the sum of k inputs has been accumulated. Then, the sum is dumped into an output flip-flop. Through this process, the filter reduces (decimates) the output frequency by k times.

5. Longest Path Calculationsfor the 7-bit Adder

6. Longest Path Calculationsfor the D-Flipflops

7. Decimation Filter Schematic

8. System Counter

9. Decimation Filter Layout

10. LVS Verification

11. Simulations (schematic)

12. Simulations (extracted)

13. Impulse Output Impulse Input Step Output Step Input

14. DFF Fall Time For Hold DFF Rise Time For Hold

15. DFF Fall Time for Setup DFF Rise Time for Setup

16. Power Waveform

17. Cost Analysis • Estimated time spent on each phase of the project: • verifying logic (1 week) • verifying timing (1 week) • layout (3 weeks) • post extracted timing (1.5 weeks)

18. Conclusion • We designed a decimation filter, which samples and sums the incoming data 3 inputs at a time. Through this process, the filter reduces (decimates) the output frequency by a factor of 3. • Our design met all specifications except for timing because our adder was too slow. • We propose the use of an alternative design, which uses a mux select to implement a faster adder.

19. Alternative Adder using a Mux Select

20. Lessons Learned • It would be helpful to students to use a layered approach for the chip layout by creating instances of individual parts instead of copy and paste to improve debugging capabilities. • It would be helpful if professors could spend some time to cover testing methodology.

21. Acknowledgements • Thanks to our family and friends who missed us for the past 3 months. • Thanks to Cadence Design Systems for the VLSI lab. • Thanks to Dr. Parent and John for their advice and great patience.
