Single-ISA Heterogeneous Multi-Core Architectures: The Potential for Processor Power Reduction

This presentation explores the potential of Single-ISA heterogeneous multi-core architectures for reducing processor power consumption, anticipating a rise to 300W by 2015. Current chip multiprocessors (CMPs) primarily utilize homogeneous cores, which limits power efficiency. The proposed model enables applications to run on the most power-efficient core while maintaining performance within 10% of the peak. By dynamically switching between cores based on energy and performance metrics, significant reductions in energy consumption and energy-delay product can be achieved, showcasing a path toward more sustainable computing.

susane
Télécharger la présentation

Single-ISA Heterogeneous Multi-Core Architectures: The Potential for Processor Power Reduction

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Single-ISA Heterogeneous Multi-Core Architectures:The Potential for Processor Power Reduction University of California MICRO ’03 Presented by JinhoSeol

  2. Motivation • By 2015 processors will consume 300W • Existing CMP designs use only homogeneous cores • Applications with high ILP can be exploited on wider cores but applications with low ILP use less power on narrower cores with little loss in performance

  3. Main Idea • Single-ISA heterogeneous multi-core architecture • A mechanism to reduce power dissipation • Key idea • Choose the most power efficient processor under some performance constraints •  Power efficiency

  4. Architecture • Private L1 caches and a common L2 cache • Assumption • Only one application runs at a time on only one core • Unused cores are completely powered down • Switching timing • OS time slice intervals • Entire application

  5. Modeling of CPU Cores • Roughly modeled after cores of EV4(Alpha 21064), EV5(Alpha 21164), EV6(Alpha 21264) and EV8-(Alpha 21464) • Assumption • 0.10 micron technology • EV8- • Single-threaded version of EV8 • Subtracting out L2 cache

  6. Modeling of Power • Peak power • Data obtained from data sheets • EV8- data is estimated • Core-area • Estimated using CACTI • Typical power • Assumed from Intel processors • EV4 and EV5 is extrapolated

  7. Variation in Power & Performance • Benchmark, applu • Relative performance of the cores varies between phases.

  8. Oracle based on energy metric • Oracle chooses the core that has the lowest energy consumption, given the constraint that performance has always to be maintained within 10% of the EV8- core

  9. Oracle based on energy-delay metric • Oracle chooses the core that has the lowest energy–delay product. • Assumption that energy and response time have equal importance.

  10. Realistic Dynamic Switching Heuristics • Assumption • An ability to track both the accumulated performance and energy over a past interval • Heuristics • Neighbor • One of the 2 neighboring cores in the performance continuum is randomly selected for sampling. • Neighbor-global • Similar to neighbor, except selecting the accumulated energy-delay product. • Random • Randomly-chosen core is sampled. • All • All cores are sampled.

  11. Conclusion • Realistic dynamic switching algorithms show a decrease in energy and energy-delay with a small decrease in performance • Single ISA heterogeneous multi-core processors may be a way to decrease power dissipation
