  1. Revolution Centrifugal Pump Performance Overview Rev 2.1

  2. Centrifugal Pump Challenges • Bearing Failures • Leaks • Decouple • Noise & Fractured Magnets • Thrombus Generation & Hemolysis • Air Entrapment • Vane Impeller = Blender • Flow Sensor Issues • Ease of Set-up

  3. Designed by the experts in centrifugal pump design.

  4. Unique molded magnet driver: • Fills internal space • Assures balanced magnet • Consistent performance

  5. Pump Assembly Manufacturing Process • 100% Quality Control Process • Designed for manufacturability • Simple assembly • Minimal parts • Ultrasonic weld Assembly Simple Assembly = High Quality

  6. 1. Patented Curved Inlet Port 2. Patented Seal-less, Low Friction Upper Bearing 3. Patented “Spin-Inducer” 5. Ultrasonic Weld Upper & Lower Housing 4. Impeller floats while pumping Internal Features

  7. Flow Path Flow enters the inlet rinsing the top bearing Centrifugal force moves fluid to the outside Fluid not leaving the pump moves back to the low pressure center, rinsing the bottom bearing Recirculation is completed by fluid moving up thru the central channel As fluid moves up thru the central channel, it lifts the impeller off the bottom bearing, opposing the magnetic forces, reducing bearing load and bearing friction. The impeller literally floats.

  8. Pump-Head Internal Surface Area Revolution’s small surface area reduces platelet activation. Testing documented in Sorin Group Engineering Report SPN0263

  9. General Specifications data source: Manufacturers IFU

  10. Test Circuit 2 cc of air injected Volume collected in chamber

  11. Computational Flow Dynamics • Large changes in velocity would indicate vortexing. • Note steady increases from center to end of vane tips.

  12. Computational Flow Dynamics Analysis featured in Dynamics magazine Click here to read the article or go to: http://www.cd-adapco.com/press_room/dynamics/18/

  13. Flow Visualization Dr. Robin Shandas Professor of Pediatric Medicine & Mechanical Engineering – University of Colorado • Validates CFD: No Vane Tip Vortices • Gentle acceleration from center to outer diameter Click on picture to start/stop video

  14. Flow Visualization Unorganized flow upstream of inlet Upstream of inlet Click on picture to start/stop video

  15. Organized flow approaching inlet Flow Visualization Near inlet Click on picture to start/stop video

  16. Smooth rotational flow at inlet due to spin-inducer Flow Visualization Inlet Click on picture to start/stop video

  17. Flow Visualization Rotational flow created by spin-inducer Spin-inducer Click on picture to start/stop video

  18. Plasma Free Hemoglobin at 360 min P=.047 P=.073 P=.007 P=.472 P=.316 P=.762 Low Hemolysis Testing documented in Sorin Group Engineering Report SPN0263

  19. Plasma Free Hemoglobin Low Hemolysis Testing documented in Sorin Group Engineering Report SPN0263

  20. Index of Hemolysis P=.047 P=.076 P=.007 P=.464 P=.799 P=.308 Low Hemolysis Testing documented in Sorin Group Engineering Report SPN0263

  21. Temperature at 360 min Low Heat Generation Testing documented in Sorin Group Engineering Report SPN0263

  22. Pressure-Flow(@ Maximum RPM) Testing documented in Sorin Group Engineering Report SPN0263

  23. Pressure generated at 5 LPM High Efficiency: Highly efficient pump reduces hemolytic heat generation. Testing documented in Sorin Group Engineering Report SPN0263

  24. Thank you for your time and attention today! Contact Us Sorin Group USA, Inc. 14401 W. 65th Way Arvada, CO 80004 Toll free: 800.221.7943 www.soringroup-usa.com
