Lava Flows

Commonly destroy property in Hawaii and Iceland. Lava Flows. Damage limited to the vicinity in the immediate area of the volcano. Fatalities rare due to slow speed of advancing lava flow. Lava Flows. Lava Flows. Lava Flows. Streams of molten rock Usually slow speed -Only a few mph

Télécharger la présentation

Lava Flows

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.


Presentation Transcript

  1. Commonly destroy property in Hawaii and Iceland. Lava Flows Damage limited to the vicinity in the immediate area of the volcano. Fatalities rare due to slow speed of advancing lava flow.

  2. Lava Flows

  3. Lava Flows

  4. Lava Flows Streams of molten rock Usually slow speed -Only a few mph -Can reach up to 60 mph

  5. Lava Flows Kupaianaha Started eruptions in 1983, by 2002, 189 structures destroyed and 13 km of highway covered with up to 25m of lava. Flow through 2002

  6. Lava Flows Etna 1983 -Fire threat -Destroys most structures -Affects large areas of farmland -May dam rivers & modify drainage

  7. Etna 1991 Lava Flows Heimaey 1973

  8. Fire fountaining at Pu’u O’o, Hawaii, which has been erupting since 1983 Lava Flows

  9. Summit caldera of Mauna Loa volcano, Hawaii: A basaltic shield volcano

  10. Pahoehoe lava flows at Pu’u O’o, Hawaii.

  11. A’a lava flows, Pu’u O’o, Hawaii.

  12. Lava from Pu’u O’o, Hawaii, enters the ocean.

  13. Pyroclastic Flows View From Space - Klyuchevskaya, Russia

  14. Pyroclastic Flows Fluid avalanche of rock material, hot ash and gas -Highly destructive -Typically faster than 80km/hr and up to 700°C • Can incinerate, burn, and asphyxiate

  15. Pyroclastic Flows NueeArdente

  16. Pyroclastic Flows- Nuée ardente Nuée ardentes are flows of fast-moving currents of hot gas and rock (collectively known as tephra), which travel away from the volcano at speeds generally greater than 80 km/h (50mph). -Destroy life and property in their paths. 60 people, thousands of animals and fish, and hundreds of acres of lumber were destroyed by ash flows from Mt. St. Helens. A Nuée Ardent killed 20,000 people when Mt. Vesuvius exploded and shed a pyroclastic flow across the village of Pompeii in 79 AD.

  17. Pyroclastic Flows The nuée ardente that was generated when Mt. Pelée erupted swept 6 km downslope through the town of St. Vincent.

  18. Pyroclastic Flows Mt. Pelee– 1902 Nuee Ardente Almost the entire population of 30,000 people were killed within minutes of inhaling the hot gases and ash.

  19. Pyroclastic Flows Montserrat 1996

  20. Montserrat Montserrat Pyroclastic Flows

  21. Mt. Pinatubo, June 12th, 1991 An explosive Island Arc volcano in the Philippines

  22. Pyroclastic Flows Vesuvius: People and animals died instantly from the rushing cloud of hot gas and ash.

  23. Tambora (1815) 10,000 people were killed by bomb impacts, tephra falls and pyroclastic flows. By far the largest impact was on the Earth’s atmosphere. The eruption plume reached 44 km above the earth, loading the stratosphere with ashes and gases.

  24. Tambora (1815) Greatest impacts from pyroclastic flows and ash and gas eruptions. Dust that reaches the upper atmosphere (stratosphere) can remain suspended and may cause global cooling for months or years after the eruption. -This is why 1815 is known as “the year without a summer” Approximately 150 km3 of ash was erupted with the explosions.

  25. Tambora (1815) “The year without a summer”

  26. Pyroclastic Flows 1883 Krakatau

  27. Krakatoa (1883) On the Island of Rakata, Krakatoa was one of 130 active volcanoes in Indonesia (the country with the most active volcanoes in the world). The volcano had been inactive for almost 200 years prior to a series of small eruptions that began in 1883.

  28. Krakatoa (1883) Krakatoa began its eruptive stage on May 20, 1883 immediately following a strong earthquake (no sensors were there to measure it). The first explosions were heard 160 km away and sent steam and ash upwards to a height of 11 km. By August 11 three vents were active on the volcano. On August 26 several loud eruptions took place over the course of the day sending dust and ash to over 25 km elevation into the atmosphere.

  29. 23 km2 area of the island was gone following the fourth eruption. On August 27, four very large eruptions began at 5:30 am. The last of the four was the largest and could be heard from Sri Lanka to Australia, up to 4,600 km from the volcano. Krakatoa (1883)

  30. Krakatoa (1883) The caldera collapsed with the explosion, from an original height of 450m above sea level to 250m below sea level. The blast itself is thought to have ejected 20 km3 of tephra. The pyroclastic flow was experienced at sea as far as 80 km away. Ships experienced hurricane force winds loaded with tephra and smelling strongly of Sulfur. Burn-related fatalities were recorded up to 40 km away from the blast. An estimated 4,500 people died from the direct effects of the blast.

  31. Krakatoa (1883) The collapse of the caldera, combined with the explosion, generated a massive tsunami with a maximum height at landfall of 45 m. The impact was greatest on the nearby islands. Coral blocks up to 600 tons were washed ashore.

  32. Krakatoa (1883) Along low lying coasts of Java the waves washed 8 km onshore, dragging people along with them as they washed back to sea. The tsunami was recorded as a small rise in sea level as far away as the California coast (20 hours after the fourth blast). An estimated 36,417 people were killed by the tsunami alone. Ash from the volcano fell to Earth as far away as 2,500 km downwind over the days following the eruption. Ash and gases in the upper atmosphere led to a lowering of global temperature by several degrees.

  33. Tephra -Airborne volcanic rock -Consists of wide range of rock types -Larger rocks fall closer to volcano; ash can travel thousands of kilometers Bombs (64mm+), lapilli (2-64mm) and ash (2mm-) Reticulite

  34. Tephra Tephra hazard

  35. Tephra Large bomb (Etna)

  36. Ballistic damage potential: Etna & Montserrat

  37. Mt. St. Helens’ ash cloud Ash fall Extensive property damage and fatalities can result from heavy ash falls. Significant ash in the upper atmosphere can circle the globe in a matter of weeks. More than 80 commercial jets have been damaged by flying through volcanic ash clouds.

  38. Ash fall An ashfall 10 million years ago killed these rhinos that are preserved at Ashfall Fossil Beds State Historic Park, Nebraska. Death was not by burial but by lung failure due to inhaling the ash.

  39. Pyroclastic Flows Volcanic Ash

  40. Rabaul Pinatubo Ash fall Ash damage potential • May collapse roofs • Fine ash causes breathing problems • May damage car and truck engines • May interfere with plant photosynthesis

  41. Ash fall Ash damage potential -Provide source for lahars -Disrupts transportation communication, power distribution, and electronics -Crop and fishery damage and water contamination -Human and livestock health problems Heimaey 1973

  42. Ash fall Heimaey 1973 Ash cloud: El Chichon 1983

  43. 2.1 Ma Yellowstone eruptions: • Compacted ash deposits 20 cm thick 1500 km from eruptions site • Ash fell in Los Angeles & El Paso • Metres thick ashy mud deposits in Caribbean cores attest to massive reworking of ash • Global climatic impact unknown but probably catastrophic

  44. Depth of ash from a future Yellowstone super-eruption 100 cm 30 cm 10 cm 1 cm

  45. Lahar Lahars are large debris flows that originate on volcano flanks. Lahars can surge tens or even hundreds of kilometers downstream from a volcano Lahars are fast moving mudflows that can engulf urban areas that are nearby the eruption. Lahars can also dam rivers and which can lead to extensive flooding. Heimaey 1973

  46. Lahar Ecuador 's Inter Andean Valley , home to some three million inhabitants, is subject to the lahar activity of many volcanoes that border the valley. Heimaey 1973

  47. A relatively small eruption of Nevada del Ruiz, Columbia, in 1985, generated a lahar when the volcano melted a 2.5 km2 area of snow and ice. Lahar Lahars can be the most devastating outcome of many volcanoes. Water and debris rushed down the slopes, picking up more debris along the way. Heimaey 1973

  48. Nevado del Ruiz – Columbia Lahar Heimaey 1973

  49. Lahar Example of a Hazard Map showing lahars and degrees of risk at Pinatubo(Feb. 2002) Heimaey 1973
