  1. ABO Blood Grouping Introduction Terry Kotrla, MS, MT(ASCP)BB

  2. ABO Basics • Blood group antigens are actually sugars attached to the red blood cell. • Antigens are “built” onto the red cell. • Individuals inherit a gene which codes for specific sugar(s) to be added to the red cell. • The type of sugar added determines the blood group.

  3. This diagram illustrates the terminal sugar for each blood group.

  4. ABO Type Frequencies In U.S.

  5. Landsteiner’s Rule • Individual’s will form immune antibodies to ABO blood group antigens they do not possess. • Substances are present in nature which are so similar to blood group antigens which result in the constant production of antibodies to blood group antigens they do not possess. • Critical for understanding compatibility between ABO blood groups.

  6. Antibody clinical significance • Immunizations are frequently done to protect us from disease. • Receive Hepatitis B immunization. • Actual bits of hepatitis virus injected. • Body recognizes as foreign and produces an immune antibody. • Subsequent exposure to real Hepatitis B virus will result in destruction of the virus by immune antibodies. • ABO antibodies are immune and will result in destroying incompatible cells which may result in the death of the recipient.

  7. Inheritance • Blood group antigens are “codominant”, if the gene is inherited, it will be expressed. • Some aberrant genotypes do occur but due to the rarity will not be discussed. • Understanding of basic inheritance important.

  8. Genetics • Two genes inherited, one from each parent. • Individual who is A or B may be homozygous or heterozygous for the antigen. • Heterozygous: AO or BO • Homozygous: AA or BB • Phenotype is the actual expression of the genotype, ie, group A • Genotype are the actual inherited genes which can only be determined by family studies, ie, AO.

  9. Example of Determining Genotype • Mom’s phenotype is group A, genotype AO • Dad’s phenotype is group B, genotype BO

  10. Other Examples

  11. Group O • Approximately 45% of the population is group O. • No A or B antigens present, think of as “0” antigens present. • These individuals form potent anti-A and anti-B antibodies which circulate in the blood plasma at all times.

  12. Group A • Approximately 40% of the population is group A. • No B antigens present. • These individuals form potent anti-B antibodies which circulate in the blood plasma at all times.

  13. Group B • Approximately 11% of the population is group B. • No A antigens present. • These individuals form potent anti-A antibodies which circulate in the blood plasma at all times.

  14. Group AB • Approximately 4% of the population is group AB. • Both A and B antigens present. • These individuals possess no ABO antibodies. • NOTE: This slide is in error as it only illustrates presence of one antigen not 2.

  15. Hemolysis • If an individual is transfused with an incompatible blood group destruction of the red blood cells will occur. • This may result in the death of the recipient.

  16. Summary

  17. Rh (D) Antigen • Of next importance is the Rh type. • Term “Rh” is a misnomer. • Rh is a blood group system with many antigens, one of which is D. • Re-education of public is difficult. • Rh refers to the presence or absence of the D antigen on the red blood cell.

  18. Rh (D) Antigen (continued) • Unlike the ABO blood group system, individuals who lack the D antigen do not naturally make it. • Production of antibody to D requires exposure to the antigen. • The D antigen is very immunogenic, ie, individuals exposed to it will very likely make an antibody to it. • For this reason all individuals are typed for D, if negative must receive Rh (D) negative blood.

  19. Rh (D) Antigen (continued) • The most important patient population to consider is females of child-bearing age. • If immunized to Rh (D) antigen the antibody can cross the placenta and destroy Rh (D) positive fetal cells resulting in death. • This is why Rh negative women are given Rhogam after birth of Rh positive baby.

  20. Hemolytic Disease of the Neborn – How it Occurs • A child is Rh pos • B during pregnancy fetal Rh pos rbc’s escape into maternal circulation • C Mother produces antibodies to Rh (D) antigen • D Second pregnancy with Rh (D) pos child results in destruction of fetal D pos rbcs

  21. Blood Typing • There are 2 components to blood typing: • Test unknown cells with known antibodies • Test unknown serum/plasma with known rbc’s • The patterns are compared and the blood group is determined.

  22. Slide Blood Typing • Very rudimentary method for determining blood groups. • CANNOT be used for transfusion purposes as false positives and negatives do occur. • A “false positive” is when agglutination occurs not because the antigen is present, but cells may already be clumpled. • A “false negative” is one in which the cells are not clumped because there are too many cells or not enough reagent.

  23. Slide Blood Typing - continued • The slide is divided into halves. • On one side a drop of anti-A is added, this will attach to and cause clumping of rbcs possessing the A antigen. • On the other side a drop of anti-B is added which will cause clumping of rbcs with the B antigen. • A drop of rbcs is added to each side and mixed well with the reagent. • The slide is tilted back and forth for one minute and observed for agglutination (clumping) of the rbcs

  24. Interpretation of Slide TypingTesting with Anti-A Anti-Serum • If an rbc contains the A antigen the red blood cells will be agglutinated by anti-A, a positive reaction. • If an rbc does not have the A antigen there will be no clumping, a negative reaction.

  25. Interpretation of Slide TypingTesting with Anti-B Anti-Serum • If an rbc contains the B antigen the red blood cells will be agglutinated by anti-B, a positive reaction. • If an rbc does not have the B antigen there will be no clumping by anti-B, a negative reaction.

  26. Slide Blood Typing Group A • An unknown rbc suspension is added to known anti-sera. • The left hand of the slide contains anti-A which reacts with the unknown cell. • The right hand side contains anti-B which does not react with the cell.

  27. Slide Blood Typing Group B • An unknown rbc suspension is added to known anti-sera. • The left hand of the slide contains anti-A does not react with the unknown cell. • The right hand side contains anti-B which reacts with the cell.

  28. Slide Blood Typing Group O • The left hand of the slide contains anti-A does not react with the unknown cell. • The right hand side contains anti-B does not react with the unknown cell.

  29. Slide Blood Typing Group AB • The left hand of the slide contains anti-A which reacts with the unknown cell. • The right hand side contains anti-B which reacts with the unknown cell.

  30. Summary of Slide Typing
