  1. Transportation Problems Dr. Ron Tibben-Lembke

  2. Transportation Problems • Linear programming is good at solving problems with zillions of options, and finding the optimal solution. • Could it work for transportation problems? • Costs are linear, and shipment quantities are linear, so maybe so.

  3. Defining Variables • Define cij as the cost to ship one unit from i to j. • Demand at location j is dj. • Supply at DC i is Si • Xij is the quantity shipped from DC i to customer j.

  4. Formulation

  5. Transportation Method You have 3 DCs, and need to deliver product to 4 customers. Find cheapest way to satisfy all demand D 2 A 10 E 4 B 10 F 12 C 10 G 11

  6. Solving Transportation Problems • Trial and Error • Linear Programming – ooh, what’s that?! • Tell me more!

  7. Setting up LP • Create a matrix of shipment costs (in grey in example). • Create a matrix to hold the decision variables, shipment quantities (in yellow). • Sum amount sent to each destination. • Sum amount sent from each DC. • Enter demands and supplies at each location. • Compute total cost of shipments (in blue).

  8. Using Solver

  9. If you don’t check “assume non-negative” we get the following results: • Solver doesn’t converge to an optimal solution. Why not?

  10. Inequalities • Use <= for shipments from DCs. • Use >= for shipments to customers. • Do we really need to? • What do we do if supply is greater than demand?

  11. Product Shortages • If total demand is greater than total supply, what happens? • If demand in G is 15, we get this:

  12. Product Shortages • If demand at G is 15, there are no feasible solutions, much less a best one. • We need to add a phantom source, Z, with huge capacity. Think of it as a supplier that ships empty boxes. • Now supply can satisfy total demand.

  13. Shortage Costs • What cost should we use for supplier Z? • It should be the last resort, so it should be higher than any real costs. • The cost of a shipment from Z is really the cost of shorting the customer. • If all customers are created equal, give them all the same shortage cost. • If some are more important, give them higher shortage costs, and we’ll only short them as a last resort.

  14. Shortage Solution • Shortage is dealt with by shorting customer A, and B. • Demand exceeds supply by 3 units. Our first choice is to short A, because they are the cheapest. We can only short them by 2, their total demand. • Next, short B by 1 unit.
