  1. Trees, Binary Trees, and Binary Search Trees

  2. Trees • Linear access time of linked lists is prohibitive • Does there exist any simple data structure for which the running time of most operations (search, insert, delete) is O(log N)? • Trees • Basic concepts • Tree traversal • Binary tree • Binary search tree and its operations

  3. Trees • A tree T is a collection of nodes • T can be empty • (recursive definition) If not empty, a tree T consists of • a (distinguished) node r (the root), • and zero or more nonempty sub-trees T1, T2, ...., Tk

  4. Tree can be viewed as a ‘nested’ lists • Tree is also a graph …

  5. Some Terminologies • Child and Parent • Every node except the root has one parent  • A node can have a zero or more children • Leaves • Leaves are nodes with no children • Sibling • nodes with same parent

  6. More Terminologies • Path • A sequence of edges • Length of a path • number of edges on the path • Depth of a node • length of the unique path from the root to that node • Height of a node • length of the longest path from that node to a leaf • all leaves are at height 0 • The height of a tree = the height of the root = the depth of the deepest leaf • Ancestor and descendant • If there is a path from n1 to n2 • n1 is an ancestor of n2, n2 is a descendant of n1 • Proper ancestor and proper descendant

  7. Example: UNIX Directory

  8. Tree Traversal • Used to print out the data in a tree in a certain order • Pre-order traversal • Print the data at the root • Recursively print out all data in the leftmost subtree • … • Recursively print out all data in the rightmost subtree

  9. Example: Unix Directory Traversal PreOrder PostOrder

  10. Binary Trees • A tree in which no node can have more than two children • The depth of an “average” binary tree is considerably smaller than N, even though in the worst case, the depth can be as large as N – 1. Generic binary tree Worst-casebinary tree

  11. Convert a Generic Tree to a Binary Tree

  12. Binary Tree ADT • Possible operations on the Binary Tree ADT • Parent, left_child, right_child, sibling, root, etc • Implementation • Because a binary tree has at most two children, we can keep direct pointers to them • a linked list is physically a pointer, so is a tree. • Define a Binary Tree ADT later …

  13. A drawing of linked list with one pointer … A drawing of binary tree with two pointers … Struct BinaryNode { double element; // the data BinaryNode* left; // left child BinaryNode* right; // right child }

  14. Example: Expression Trees • Leaves are operands (constants or variables) • The internal nodes contain operators • Will not be a binary tree if some operators are not binary

  15. Preorder, Postorder and Inorder • Preorder traversal • node, left, right • prefix expression • ++a*bc*+*defg

  16. Postorder traversal left, right, node postfix expression abc*+de*f+g*+ Inorder traversal left, node, right infix expression a+b*c+d*e+f*g Preorder, Postorder and Inorder

  17. Preorder, Postorder and Inorder Pseudo Code

  18. Binary Search Trees (BST) • A data structure for efficient searching, inser-tion and deletion • Binary search tree property • For every node X • All the keys in its left subtree are smaller than the key value in X • All the keys in its right subtree are larger than the key value in X

  19. Binary Search Trees A binary search tree Not a binary search tree

  20. Binary Search Trees The same set of keys may have different BSTs • Average depth of a node is O(log N) • Maximum depth of a node is O(N)

  21. Searching BST • If we are searching for 15, then we are done. • If we are searching for a key < 15, then we should search in the left subtree. • If we are searching for a key > 15, then we should search in the right subtree.

  22. Searching (Find) • Find X: return a pointer to the node that has key X, or NULL if there is no such node • Time complexity: O(height of the tree) find(const double x, BinaryNode* t) const

  23. Inorder Traversal of BST • Inorder traversal of BST prints out all the keys in sorted order Inorder: 2, 3, 4, 6, 7, 9, 13, 15, 17, 18, 20

  24. findMin/ findMax • Goal: return the node containing the smallest (largest) key in the tree • Algorithm: Start at the root and go left (right) as long as there is a left (right) child. The stopping point is the smallest (largest) element • Time complexity = O(height of the tree) BinaryNode* findMin(BinaryNode* t) const

  25. Insertion • Proceed down the tree as you would with a find • If X is found, do nothing (or update something) • Otherwise, insert X at the last spot on the path traversed • Time complexity = O(height of the tree)

  26. void insert(double x, BinaryNode*& t) { if (t==NULL) t = new BinaryNode(x,NULL,NULL); else if (x<t->element) insert(x,t->left); else if (t->element<x) insert(x,t->right); else ; // do nothing }

  27. Deletion • When we delete a node, we need to consider how we take care of the children of the deleted node. • This has to be done such that the property of the search tree is maintained.

  28. Deletion under Different Cases • Case 1: the node is a leaf • Delete it immediately • Case 2: the node has one child • Adjust a pointer from the parent to bypass that node

  29. Deletion Case 3 • Case 3: the node has 2 children • Replace the key of that node with the minimum element at the right subtree • (or replace the key by the maximum at the left subtree!) • Delete that minimum element • Has either no child or only right child because if it has a left child, that left child would be smaller and would have been chosen. So invoke case 1 or 2. • Time complexity = O(height of the tree)

  30. void remove(double x, BinaryNode*& t) { if (t==NULL) return; if (x<t->element) remove(x,t->left); else if (t->element < x) remove (x, t->right); else if (t->left != NULL && t->right != NULL) // two children { t->element = finMin(t->right) ->element; remove(t->element,t->right); } else { Binarynode* oldNode = t; t = (t->left != NULL) ? t->left : t->right; delete oldNode; } }

  31. Insertion Example Construct a BST successively from a sequence of data: 35,60,2,80,40,85,32,33,31,5,30

  32. Deletion Example 30 30 5 5 40 60 2 80 2 80 35 35 32 32 85 85 60 33 33 31 31 (b) (a) Removing 40 from (a) results in (b) using the smallest element in the right subtree (i.e. the successor)

  33. 30 30 5 5 35 40 2 80 32 2 80 35 32 85 60 31 33 60 85 33 31 (c) (a) Removing 40 from (a) results in (c) using the largest element in the left subtree (i.e., the predecessor) COMP152 34

  34. 30 5 5 2 35 35 80 2 80 32 32 31 31 33 33 60 60 85 85 (d) (c) Removing 30 from (c), we may replace the element with either 5 (predecessor) or 31 (successor). If we choose 5, then (d) results. COMP152 35

  35. Example: compute the number of nodes?

  36. Example: Successor The successor of a node x is defined as: The node y, whose key(y) is the successor of key(x) in sorted order sorted order of this tree. (2,3,4,6,7,9,13,15,17,18,20) Successor of 13 Successor of 6 Some examples: Which node is the successor of 2? Which node is the successor of 9? Which node is the successor of 13? Which node is the successor of 20? Null Successor of 2 Successor of 9 Search trees 37

  37. Finding Successor:Three Scenarios to Determine Successor Successor(x) x has right descendants => minimum( right(x) ) x has no right descendants Scenario I x is the left child of some node => parent(x) x is the right child of some node Scenario II Scenario III Search trees 38

  38. Scenario I: Node x Has a Right Subtree By definition of BST, all items greater than x are in this right sub-tree. Successor is the minimum( right( x ) ) maybe null Search trees 39

  39. Scenario II: Node x Has No Right Subtree and x is the Left Child of Parent (x) Successor is parent( x ) Why? The successor is the node whose key would appear in the next sorted order. Think about traversal in-order. Who wouldbe the successor of x? The parent of x! Search trees 40

  40. Scenario III: Node x Has No Right Subtree and Is Not a Left-Child of an Immediate Parent Keep moving up the tree until you find a parent which branches from the left(). Successor of x y Stated in Pseudo code. x Search trees 41

  41. Successor Pseudo-Codes Verify this code with this tree. Find successor of 3  4 9  13 13  15 18  20 Note that parent( root ) = NULL Scenario I Scenario II Scenario III Search trees 42

  42. Problem If we use a “doubly linked” tree, finding parent is easy. But usually, we implement the tree using only pointers to the left and right node.  So, finding the parent is tricky. For this implementation we need to use a Stack. class Node { int data; Node * left; Node * right; Node * parent; }; class Node { int data; Node * left; Node * right; }; Search trees 43

  43. Use a Stack to Find Successor PART I Initialize an empty Stack s. Start at the root node, and traverse the tree until we find the node x. Push all visited nodes onto the stack. PART II Once node x is found, find successor using 3 scenarios mentioned before. Parent nodes are found by popping the stack! Search trees 44

  44. An Example push(15) Successor(root, 13) Part I Traverse tree from root to find 13 order -> 15, 6, 7, 13 push(6) push(7) 13 found (x = node 13) 7 6 15 Stack s Search trees 45

  45. Example y =pop()=15 ->Stop right(15) != x return y as successor! Successor(root, 13) Part II Find Parent (Scenario III) y=s.pop() while y!=NULL and x=right(y) x = y; if s.isempty() y=NULL else y=s.pop() loop return y y =pop()=6 y =pop()=7 x = 13 7 6 15 Stack s Search trees 46

  46. Make a binary or BST ADT …

  47. For a generic (binary) tree: Struct Node { double element; // the data Node* left; // left child Node* right; // right child } class Tree { public: Tree(); // constructor Tree(const Tree& t); ~Tree(); // destructor bool empty() const; double root(); // decomposition (access functions) Tree& left(); Tree& right(); bool search(const double x); void insert(const double x); // compose x into a tree void remove(const double x); // decompose x from a tree private: Node* root; } (insert and remove are different from those of BST)

  48. For BST tree: Struct Node { double element; // the data Node* left; // left child Node* right; // right child } class BST { public: BST(); // constructor BST(const Tree& t); ~BST(); // destructor bool empty() const; double root(); // decomposition (access functions) BST& left(); BST& right(); bool serch(const double x); // search an element void insert(const double x); // compose x into a tree void remove(const double x); // decompose x from a tree private: Node* root; } BST is for efficient search, insertion and removal, so restricting these functions.

  49. Weiss textbook: class BST { public: BST(); BST(const Tree& t); ~BST(); bool empty() const; bool search(const double x); // contains void insert(const double x); // compose x into a tree void remove(const double x); // decompose x from a tree private: Struct Node { double element; Node* left; Node* right; Node(…) {…}; // constructuro for Node } Node* root; void insert(const double x, Node*& t) const; // recursive function void remove(…) Node* findMin(Node* t); void makeEmpty(Node*& t); // recursive ‘destructor’ bool contains(const double x, Node* t) const; }
