  1. The MB-NG project is a major collaboration between different groups. This is one of the first projects to bring together users, industry, equipment providers and leading edge e-science application. Technically, it enabled a leading edge U.K. Diffserv enabled network running at 2.5 Gbit/s; configured and demonstrated the use of MPLS traffic engineering to provide tunnels for preferential traffic; deployed a middleware to dynamically reserve and manage the available bandwidth-on a per-flow level-at the edges of the network; investigated the performance of end-host systems for high throughput; deployed and tested a number of protocols designed to tackle the issue of standard TCP in long fat pipes and finally demonstrated the benefits to the application of the advanced network environment. MB-NG Managed Bandwidth BB BB BB BB CCLRC Manchester HPCx CSAR UKERNA MAN-HEP MAN-MCC Warrington UCL-Chemistry London APPLICATION / GUI APPLICATION / GUI RAL UCL-HEP request NRSE NRSE Reading ULCC configure data CORE BABAR SurfNet Netherlands Starlight Chicago Applications: GridFTP vs APACHE Domain C BB Bandwidth Broker Traffic flows Signalling between BB Provisioning devices Core Domain Frequency N Domain A Domain B Mbits/s Time μs GridFTP Distribution of Throughput GridFTP Time Series Frequency N Mbits/s APACHE Distribution of Throughput Time μs APACHE Time Series TCP and High Throughput QoS Middleware: GRS - Grid Resource Scheduling • Standard TCP transfers data memory-to-memory across MB-NG at 941 Mbits/s. This is the maximum “line rate” for TCP. • The MB-NG network is QoS enabled with three classes using DiffServ. • WHAT IT IS: • Middleware component to reserve network bandwidth dynamically; • Based on a model where QoS is managed locally at each edge site and the bottleneck is at the edge. • HOW IT WORKS: • A Network Resource Scheduling Entity (NRSE) manages a single site and stores information about local network resources and users; • A request can be issued via a GUI (from an end-user) or an API (from an application); • Authentication is performed locally on the local user and then between NRSEs to improve scalability and to support multi-domain operation; • Bi-directional reservations that require bandwidth to be reserved on both directions are supported; • Reservations between any two sites can be initiated from a third remote site; • GRS AND MB-NG: • MB-NG is the first deployment on a WAN of GRS; • NRSE has a locally-programmable back-end to ensure that the router configuration is consistent and correctly restored after the reservations are completed; • Traffic that matches the reservation parameters is marked and guaranteed enough bandwidth before entering the core in the edge router. • FUTURE GOALS: • Currently planning a version to work in an environment where bottlenecks may occur anywhere in the network; • Possible integration with MPLS in order to have GRS establishing end-to-end Tunnels. Congestion point 2.5Gbit/s 24 hours continuous Transfer TCP mem-mem at line rate. Manchester Traffic flow London RAL 2 Classes: Voice 20%, BE 80% QoS switched on • An issues with standard TCP is its performance in high bandwidth-delay networks • New TCP stacks being proposed to deal with thid issue (HSTCP, STCP, H-TCP, FAST, ….) • In low RTT-high bandwidth environment, standard TCP performs just as well as the new stacks. In high RTT-high bandwidth environments, the new stacks are more reactive to losses. 3 Classes: EF 33%, BE 57%, LBE 10% QoS switched on TCP in high bandwidth networks: Short RTT vs long RTT RTT~6ms RTT~120ms RAID Studies Disk-to-disk performance across MB-NG using RAID5 • Read speed: • line rate. • Write speed: • For small files less than 400MBytes = line rate • For larger files ~ 600 Mbits/s. • Optimal performance obtained using optimal hardware configuration • RAID 5 disk arrays give high read/write speeds together with built in redundancy to ensure fault tolerance. Max read speed ~ 1300 Mbit/s Middleware: GARA – General-purpose Architecture for Reservation and Allocation Write speed (large files) ~ 600 Mbit/s Applications: Reality Grid • Developed as part of the Globus project. • GARA provides end-to-end QoS to the applications using three types of Resources Managers (RM) • In our case, we just make use of the Network RM (Differentiated Services). It allows immediate and advance reservations. Parameters needed in a reservation are: • Reservation type: network (or cpu, disk) • Start Time: seconds from Epoch • Duration: seconds • Resource-specific parameters :e.g. bandwidth… Realtime remote visualisation: • Processing in London, visualisation in Manchester. • Without QoS, the level of background traffic affects the application performance. • With QoS, the applications is protected from the background traffic. • QoS setting: 10% (230 Mbit/s) of 2.5 Gbit/s bottleneck reserved for EF. The average application throughput of 65 Mbit/s is sufficient for a usable refresh rate Visualisation Server Visualisation client Steering Simulation data Through the use of MB-NG Reality-grid The TeraGyroid project won the HPC Challenge Award for Most Innovate Data-Intensive Application at SuperComputing 2003 in Phoenix, Arizona. Manchester Computation node London MPLS: Multiprotocol Label Switching • BASICS: • Layer 2.5 switching technology developed to integrate IP and ATM. • Forwarding based on label switching; • Traffic Engineering extensions allow the use of different routing paradigms compared with routing based on the shortest path as found in IP networks; • MPLS Tunnels, using RSVP, help with emulating virtual Leased Lines; • RSVP allows for easy accounting and better utilization of all the available bandwidth; • Provides reroute techniques comparable with SONET in terms of speed; • Other possible use of MPLS (VPNs, AToM, etc) use different protocols. • MPLS & MBNG: • Deployed in the core of the MB-NG network; • Carried extensive testing to check capabilities of Tunnels in respect of bandwidth reservation; • Because RSVP works on the control plane only, QoS still need to be extensively deployed. • CONCLUSIONS: • MPLS with Traffic Engineering extensions helps in enabling efficient utilization of available networks resources; • Tunnels ease end-to-end traffic management but are not a complete solution to bandwidth allocation; • QoS needs to be deployed all over the MPLS core. • Raid0 with 4 disks in the array. • Transfer of 2 Gbyte files from London to Manchester • GridFTP average throughput of 520 Mbit/s APACHE average throughput of 710 Mbit/s.
