  1. TheDie Casting Processof a Differential Casing Speaker:Jennifer Won Objective: To describe what is needed to understand the process of Die Casting and why it is used despite the disadvantages.

  2. Types of Casting Processes • Centrifugal Casting • Sand Casting • Die Casting

  3. High Pressure Die Casting

  4. Disadvantages • Expensive • Long time cycle for equipment construction • Cannot cast strong metals

  5. Advantages • More uniformity • Good surface finish • Good dimensional accuracy • Faster production rate

  6. References Resources: • Mikell P. Groover, Fundamentals of Modern Manufacturing,Materials, Processes, and Systems • Azom.com, http://www.azom.com/details.asp?ArticleID=1392#_Die_Casting • http://www.pylebros.com/parts-posis.htm • www.dictionary.com Differential images • http://www.atspeedimages.com/lotus_18_work/renault_type_318_transaxle/parts_list/
