  1. Why Buy Intel® Desktop Boards November 2011 INTEL CONFIDENTIAL

  2. Objectives • What makes our products stand out • New “Embedded Lite” Segment • Somenewproducts

  3. What Makes OurProducts Stand Out

  4. Better Together Trusted Brand • Top to bottom platform • Designed by Intel • Intel Channel Benefits Quality & Reliability • Intel quality standards • Server grade testing, 5K+ • Extreme shock & vibe Distributor Friendly • 2 weeks CANX window • Stock rotation • Price protection Compatibility • Industry standards • Pass-through WHQL • Tested HW database Service & Support • 3yr Advanced Warranty • 24x7 support, 28 languages • Technical RMA IT’S WHAT’S INSIDE THAT COUNTS

  5. Unmatched World Class Warranty • Three years • Worldwide coverage • Door to door service • Replacement, not refund • Prepaid via DHL

  6. Unique Features • Uncompromised engineering • Pass-thru WHQL certification • Extended Life Plan: 24-36 months • Embedded Light designs • Intel® Fast Boot Technology • First to market: Lucid* Virtu* on Z68 & H67 SKUs • Power supervisor & ESD protection

  7. New “EmbeddedLite” Segment

  8. GFX Media VGA HDMI DP DDR3 IMC Display Major Atom Platform Refresh Platform • 12W Kit TDP • Fanless capable Cedarview-D Cedar Trail-D Platform CPU CPU Core • Frequency 1.86GHz – 2.13GHz • Dual-core only LVDS eDP Media • H/W accelerated video decoder • Blu-Ray* 2.0 Display/GFX • Legacy: VGA, LVDS • HDMI 1.3, DP/eDP1.1 • Dual independent digital displays • DX*10.1, OpenGL 3.0 DMI X4 NM10 Chipset I/O

  9. This Is What It Makes Possible D7XXMT (Marshalltown) • 20mm Z-Height • HDMI/VGA/LVDS/eDP • 2 mini PCIe, 19V DC power D7XXMUD (Mount Union) • Dual independent display • DVI-D/VGA/LVDS • Mini PCIe, Parallel, Serial D7XXDC (Dry Creek) • HDMI/DVI-D • SPDIF, HD Audio • Mini PCIe

  10. D945GSEJT (Johnstown) Mini-ITX 945GSE GbE LAN SATA Atom N270 Int Gfx TM Pine Trail-D DDR2 (UDIMM) Pine Trail-D DDR3 (SO-DIMM) Cedar Trail-D DDR3 (SO-DIMM) Roadmap & Transitions 1H ’10 2H ’10 2H ’11 D410PT D2700DC D2500CC DN2800MT D510MO D425KT D2700MUD D2500HN D2500HND D2700MU D525MW (Mount Union Legacy) (Mount Washington) (Mount Olive) (Canoe Creek) (Dry Creek) (Kinston) (Mount Union DVI) (Houlton Legacy) (Marshalltown) (Packton) (Houlton DVI) Mini-ITX Mini-ITX Mini-ITX Mini-ITX Mini-ITX Mini-ITX Mini-ITX Mini-ITX Mini-ITX Thin Mini-ITX Mini-ITX NM10 NM10 NM10 NM10 NM10 NM10 NM10 NM10 NM10 NM10 NM10 DVI-D/VGA SATA SATA HDMI/DVI-D DVI-I/VGA Legacy Legacy DVI-D/VGA VGA/HDMI SATA SATA 10/100 LAN GbE LAN GbE LAN GbE LAN GbE LAN GbE LAN GbE LAN Dual GbE 10/100 LAN GbE LAN GbE LAN Int. Gfx Int. Gfx Int. Gfx Int. Gfx Int. Gfx Int. Gfx Int. Gfx Int. Gfx Int. Gfx Int. Gfx Int. Gfx Atom™ D510 N2800 D2700 D2700 D2700 Atom™ D525 Atom™D425 D2500 Atom™D410 D2500 D2500 Notes: 1. D945GSEJT launched in Q2’09. 2. Cedar Trail expected to launch in Q4’11.

  11. Product Positioning All-In-One • Dual-core Atom with Hyper Threading • Slim form factor; <20mm z-height • Meets channel All-In-One specification D2500HND D2700DC DN2800MT D2700MUD D2500HN D2500CC (Dry Creek) (Canoe Creek) (Marshalltown) (Houlton DVI) (Houlton Legacy) (Mount Union DVI) VGA/DVI-D/2COM VGA/HDMI VGA/DVI-D/2COM VGA/DVI-I/4COM DVI-D/HDMI VGA/Legacy Atom™ D2700 Atom™ N2800 Atom™ D2500 Atom™ D2700 Atom™ D2500 Atom™ D2500 Home Theater PC • Dual-core Atom with Hyper Threading • 1080 High-Definition playback • Cost competitive entry-level HTPC Digital Signage • Dual-core Atom with & without Hyper Threading • DVI-I for full dual-independent display support • 4 serial ports & headers for multiple peripherals • Boards are suitable for other devices; ATM, Kiosk, POS, etc. D2700MU (Mount Union Legacy) VGA/Legacy Entry-level Desktop • Dual-core Atom with & without Hyper Threading • Passive thermal solution; 35mm z-height • Legacy features for basic computing needs Atom™ D2700

  12. Intel® Desktop Board Media Series:DH61AG feature highlight Support for the 2nd generation Intel® Core™ processors in the LGA1155 package up to 65W TDP Dual channel DDR3-1333, two SO-DIMM, 16GB1 max eDP/LVDS Flat Panel display support Full size PCI-Express* mini-card slot Half size PCI-Express* mini-card slot Stereo and 7.1 Surround Intel® High Definition Audio, with Multi-Streaming capability 19V DC Input, from back panel or internal power connector One eSATA 3.0 Gb/s port Two back panel SuperSpeed USB 3.0 ports Two Hi-Current/Fast Charging USB 2.0 ports DVI-I+HDMI for Intel® HD Graphics, supports dual independent display Note 1: Pending availability of 8GB SO-DIMMs

  13. Official Intel Distributors In Hungary ASBIS Hungary Kft. AvnetTechnologySolutions Ingram Micro Kvazar-Micro CEE Kft.

  14. Q&A

  15. Backup
