  1. Optical properties S. Kugler: Lectures on Amorphous Semiconductorsa

  2. General aspects Optical absorption and luminescence occur by transition of electrons and holes between electronic states (bands, tail states, gap states). If electron-phonon coupling is strong enough self-trapping occurs. S. Kugler: Lectures on Amorphous Semiconductorsa

  3. Absorption coefficient α is defined by I(z) = Io exp {- α z} where I(z) is the flux density if incident light is Io, z is the distance measured from the incident surface. Hence α = - (1/I(z)) dI(z)/dz S. Kugler: Lectures on Amorphous Semiconductorsa

  4. Absorption S. Kugler: Lectures on Amorphous Semiconductorsa

  5. Tauc law (Tauc plot, A region) The absorption coefficient, α, due to interband transition near the band-gap is well described: αħω = B (ħ ω– Eg)2 ħωis photon energy, Eg is optical gap. This Tauc plot defines the optical gap in amorphous semiconductors. S. Kugler: Lectures on Amorphous Semiconductorsa

  6. S. Kugler: Lectures on Amorphous Semiconductorsa

  7. S. Kugler: Lectures on Amorphous Semiconductorsa

  8. Urbach tail (B region) The absorption coefficient at the photon energy below the optical gap (tail absorption) depends exponentially on the photon energy: α(ħω) ~ exp (ħ ω/Eu) where Eu is called Urbach energy. S. Kugler: Lectures on Amorphous Semiconductorsa

  9. C region In addition, optical absorption by defects also appears at energy lower than optical gap. Likewise α is written as another exponential function of photon energy: α(ħω) ~ exp (ħω/Ed), Ed belongs to the width of the defect states. C region is rather sensitive to the structural properties of materials. S. Kugler: Lectures on Amorphous Semiconductorsa

  10. Direct/indirect transition • In the case of crystalline semiconductors (without defects, there is no localized state) photoluminescence occurs by transition between the bottom of the conduction band and the top of the valence band. k selection rule must be satisfied: kphoton = ki – kf. (kphoton, kiand, kfare the wave numbers of photons, electron of initial and final states. S. Kugler: Lectures on Amorphous Semiconductorsa
