Dimensioning

Dimensioning. Why Dimension?. Engineers, designers, and engineering technologists need to know. Size and Location of all features. Dimension Completely. Width. Dimension Completely. Width. Height. Dimension Completely. Width. Height. Depth. Dimension Line Types. Dimension Line.

Thomas
Télécharger la présentation

Dimensioning

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Dimensioning

  2. Why Dimension? Engineers, designers, and engineering technologists need to know • Size and • Location of all features

  3. Dimension Completely Width

  4. Dimension Completely Width Height

  5. Dimension Completely Width Height Depth

  6. Dimension Line Types Dimension Line Extension Line Leader Line

  7. Your Turn to Practice ¼ in. scale or 4 squares = 1 in.

  8. Check Your Answers

  9. Where are the Missing Dimensions? ¼ in. scale or 4 squares = 1 in.

  10. Here They Are
