  1. ELEC4601 Microprocessor systemsLab 1 Tutorial

  2. Teaching Assistants

  3. General Information • Groups of TWO • Before entering labs: • 2 prelabs + 1 cover-page • Cover-page will contain your marks (signed by TA) • 1 week after the lab: • Submit 1 (ONE) lab report per group (attach both prelabs and the cover-page with the report) Pre Lab Cover Page Pre Lab Lab Report

  4. Things To Do Immediately • Buy a set ofLab manuals from IEEE office (3rd floor, ME) • Everyone must have own copy • Collect Lab package (contains 3 parts) • Intel 8086 manual • SDK manual • Peripheral manual One (1) for each group • You need to deposit $20 for a copy

  5. Before You come to the Lab • BEFOREcoming to the lab: • Make a photo copy of the lab pages from lab manual • Complete ALL the pre-lab requirements before coming to the lab (Do not work on pre-lab during lab time) • From the course website: • Download the lab’s .asm files and save them onto your own USB drive • Download the lab’s cover page, print it and bring it

  6. Lab Cover Page Fill up the top portion only One cover page per group

  7. General Instructions for Labs • At theSTARTof the lab: • TA check your pre-lab, mark and initial it • You will be asked questions to determine your understanding of the pre-lab • A demo on the lab will be given at the beginning of the lab by a TA at the beginning of the lab • When you finish EACH PART of the lab: • Show your work to a TAand have initial on cover page • At the END of the lab: • TA will ask question to find our your level of understanding on the lab • TA will put marks and initial lab-demo section

  8. Report Instructions • Submission: • Submit all required sections of the lab report. • Attach printed copies of codes (commented). Indicate CLEARLY which sections of code you have written. • Deadline: • Reports are due one week afteryour lab-day by4PM in the boxes on the 4th floor of the Mackenziebuilding near stairs (between first and second blocks). • Reports will be returned in your next lab. YOU are responsible for picking up your reports.

  9. Lab Marking Scheme Pre-lab: 5 marks Completion+Demo: 5 marks Q&A: 5 marks Report: 10 marks Total: 25 marks Late Submission Penalty: -1 marks/day Each lab weighs 4% towards final marks (5 labs) Total lab weighs towards final marks: 20%

  10. Lab # 1 Familiarization with SDK-86

  11. Lab #1 Instructions: Part A • Part A: • Pre-lab Preparation: • Read about: EB,EW,MV,ER,GO instructions in the SDK manual • Review memory addressing for the Intel 8086 (ie. Segment:Offset) • Gain familiarity with the SDK-86 board • View and modify memory and registers

  12. Lab #1 Instructions: Part B,C • Part B: • Pre-lab Preparation: • Encode the necessary instructions with help from the course notes, and the 8086 reference manual. • Manually input lab1B.asm into the SDK-86 and execute it. • Part C: • Pre-lab Preparation: • Save lab1B.asm onto a USB drive • Assemble, link and download code from the PC to the SDK

  13. Lab #1 Instructions: Part D • Part D: • Pre-lab Preparation: • With help from the 8086 reference manual, implement the WAIT subroutine to wait one second. Bring this code (lab1D.asm) on your USB drive. • Demonstrate to the TA that your code (written in the prelab) successfully implements the WAIT subroutine described in the lab manual.

  14. SDK-86 board on desk SDK Board

  15. SDK display Keypad SDK-86 board: keypad and display Know the ICs mentioned in the manual

  16. Same key performs different tasks depending on the sequence SDK-86 board: multi-function keys

  17. Online help • http://library.n0i.net/hardware/i8086opcodes • http://www.emu8086.com/assembler_tutorial/ See you next week!
