  1. 68HC11 Analog I/O Chapter 12

  2. Analog to Digital Converter (ADC) • What is it? • Converts an analog voltage level to a digital output. Dout = F(Vin)

  3. Analog to Digital Converters • Terminology • Full Scale Voltage: VFS=VH-VL • Difference between maximum and minimum voltage levels • Bits (N): Number of bits in the digital output • Resolution (LSB): smallest quantizing step size • LSB = Vfs/2N • Conversion time: time needed for one conversion • Quantization error: Voltage error between digital output and analog input. • The maximum error is 1 LSB

  4. Analog to Digital ConvertersIn General • Given: VFS, N bits • LSB = VFS/(2N) • Digital Output: Dout • Analog Output: Vout • Vout = Dout*LSB = Dout * VFS/2N • Quantization Error = Vin - Vout

  5. Analog to Digital ConvertersExample • Given: VFS=5V, N=2 bit • What is the bit resolution (LSB) and the transfer curve • Answer: • LSB = 5/(22) = 1.25V • 0.000V < Vin < 1.25V  Dout = 00 • 1.25V < Vin < 2.50V  Dout = 01 • 2.50V < Vin < 3.75V  Dout = 10 • 3.75V < Vin < 5.000V  Dout = 11

  6. 2-bit Analog to Digital Converter Voltage Transfer Curve Dout Vin, V

  7. Analog to Digital ConvertersExample • Given: VFS=5V, N=8 bits • What is Dout (in hex) for Vin=2.35V • Answer: • LSB = 5/(28) = 0.0195V = 19.5mV • 2N = 256 • Dout = INT(2.35V/19.5mV)=120=$78

  8. Analog to Digital ConvertersExample • Given: VFS=5V, N=8 bits, Dout=$78 • What is the quantization error (in mV) if Vin=2.35V • Answer: • LSB = 5/(28) = 0.0195V = 19.5mV • Vout = Dout*LSB = 120*19.5mV=2.34V • QE = Vout – Vin = 2.35V-2.34V = 10mV

  9. 68HC11 A/D Converter 8-bit resolution (256 bit levels) 8 channels: Port E

  10. Port E • 8-bit • Address $100A • Multi-Function • Digital Input Port • Analog Input Port (Built-in A/D)

  11. 7 6 5 4 3 2 1 0 Port E - $100A Data Register I I I I I I I I Bits O=Output I =Input B=Bidirectional

  12. Using the 68HC11 A/D Converter • Power-up the A/D System • Configure the A/D conversion system • Two modes • Single channel scan • Continuous channel scan • Channel control • Conversion on a single channel • Conversion on four channels • Start the A/D conversion • Poll the conversion completion flag (CCF) • Read the result • Save the result

  13. Reading the Results • Load the ADC result from the • ADC Input Registers: • ADR1 = $1031 • ADR2 = $1032 • ADR3 = $1033 • ADR4 = $1034

  14. 7 6 5 4 3 2 1 0 Power the A/D Converter Option Register: $1039 System Configuration Options ADPU CSEL IRQE DLY CME N/A CR1 CR2 Bits ADPU = A/D Power-up 0 = A/D not powered up 1 = A/D powered up (need at least 100uS for process to stabilize) CSEL = Clock select 0 = Use external clock (E-clock) for power up (default) 1 = Use internal clock for power up CB = %11000000

  15. 7 6 5 4 3 2 1 0 Configure the ADCA/D Control/Status Register ADCTL Register: $1030 A/D Control/Status Register CCF N/A SCAN MULT CD CC CB CA Bits SCAN = Continuous Scan Control 0 = One cycle of four conversions each time ADCTL is written 1 = Continuous conversions MULT = Multiple Channel/Single Channel Control 0 = perform four consecutive conversions on a single channel 1 = perform four conversions on four channels consecutively

  16. 7 6 5 4 3 2 1 0 A/D Control/Status Register Single Channel Mode ADCTL Register: $1030 A/D Control/Status Register CCF N/A SCAN MULT CD CC CB CA Bits CD,CC,CB,CA = Channel Conversion Select Bits Mult=0

  17. 7 6 5 4 3 2 1 0 A/D Control/Status Register Multiple Channel Mode ADCTL Register: $1030 A/D Control/Status Register CCF N/A SCAN MULT CD CC CB CA Bits CD,CC,CB,CA = Channel Conversion Select Bits Mult=1

  18. 7 6 5 4 3 2 1 0 A/D Control/Status RegisterConversion Completion Flag ADCTL Register: $1030 A/D Control/Status Register CCF N/A SCAN MULT CD CC CB CA Bits CCF = A/D Conversion Complete Flag 0 = Conversion not complete 1 = Conversion complete. Set when all four A/D result registers contain valid conversions

  19. Project Pseudo-Code • * Power ADC using Internal Clock • Option ($1039)  %11000000 • * Delay Loop • N=10 • For I = 1 to N • Next I • * Configure ADC for • * Single channel, single scan, PE0 • * Set scan=0,mult=0, Cd,Cc,Cb,Ca to 0000 • ADCTL  %00000000 ; This starts conversion

  20. Project Pseudo-Code • * Wait for CCF Flag • Repeat • Until CCF=1 • * Read Result • A  ADR1 ($1031) • * Save Result • Dout  A • *

  21. TPS Quiz

  22. Initialization Examples • Single channel, single scan • Set scan=0,mult=0 • Set Cd,Cc,Cb,Ca to select channel • Single channel, continuous scan • Set scan=1,mult=0 • Set Cd,Cc,Cb,Ca to select channel

  23. Initialization Examples • Multiple channel, single scan • Set scan=0,mult=1 • Set Cd,Cc,Cb,Ca to select channel pair • Either PE0-PE3 or PE4-PE7 • Multiple channel, continuous scan • Set scan=1,mult=1 • Set Cd,Cc,Cb,Ca to select channel pair • Either PE0-PE3 or PE4-PE7

  24. Pseudo-code:Multi-Channel Mode68HC11 A/D Converter • Initialize A/D conversion system • Power A/D system • Enable A/D system ; This starts A/D conv. • Repeat • Until CCF=1 • For n = 1 to 4 • A  ADR(n) ; Read ADC register n • Out(n)  A ; Save conversion • Next n

  25. A/D Subroutine • **** Define Symbols • *** Assume standard equates • OPTION EQU $1039 • ADCTL EQU $1030 • ADR1 EQU $1031 • ADPU EQU %11000000 • ADC EQU %00010100 ; Single scan-multi channel • ; PE4-PE7 • CCF EQU %10000000 ; CCF • Delay EQU $1010 ; this is the delay • N EQU $04

  26. A/D Subroutine • **** Initialize the Interface • **** X contains the address of the output string • **** B contains the number of values to collect • Org Program • Start: LDY #Option ; Load address of A/D option register • BSET 0,Y #ADPU ; This power ups the A/D • LDAA #Delay • Loop: DECA • BNE Loop ; This delay allows the A/D to power up • LDAA #PE0 ; This are the bits to configure the ADCTL • STAA ADCTL ; Configure ADCTL and start conversion

  27. A/D Subroutine • LDY #ADCTL ; This is the address of the ADCTL • L0: BRCLR 0,Y #CCF L0 ; Stay here until CCF is set • LDAB #N • L1: LDY #ADR1 • LDX #OUT • LDAA 0,Y ; This will load the first conversion • STAA 0,X ; Save this conversion • INX ; Point to next character • INY • DECB • BNE L1 • RTS ; Return from subroutine • ORG Data • OUT RMB 4

  28. Maximum Sampling Rate • Nyquist Theorem: Must sample at twice the maximum frequency of the input signal to reconstruct the signal from the samples. • 68HC11 Conversion time: • 32 clock cycles = 32Tc • Maximum signal period: 1/(2Fmax) • 32Tc = 1/2Fmax  Fmax = 1/(64Tc) • Given Fclk=2Mhz  Tc= 0.5uS • Fmax=31.5KHz

  29. Aperture Time • The amount of time needed by ADC to sample the analog input is known as the “aperture time.” In the 68HC11, 12 cycles are needed to convert Vin. • If the input signal changes considerable during the sample, we will see Aperture Jitter, signal “noise”, or signal error due to the uncertainty of the input signal.

  30. TPS Quiz
