  1. Developing Orientation based on Current project • Huy-Tien, Bui • 裴輝進 • Department of Mechanical Engineering • National Cheng Kung University • Tainan, Taiwan • March30, 2013

  2. Outline • Indoor Navigation • Remote controlling the electronic furniture via Wi-Fi

  3. Indoor Navigation (1/2) • With GPS only, it is not allowed to navigating somewhere without GPS or poor signal such as inside the high building, under ground… • Solutions • Developing algorithm with INS module (6 degree of freedom including three accelerometers, three gyroscopes and MAGNETOMETER-totally 9 degree of freedom) via velocity constraints, height constraint.

  4. Indoor Navigation (2/2) • Applications • Navigating inside high building • Navigating at parking areas under ground or inside tower building • Navigating animal in farm

  5. Remote controlling the electronic furniture via Wi-Fi (1/3) • Applications • Monitoring on/off status of furniture anywhere at home through Wi-Fi (Using smartphone or controller board). • Detecting emergency status such as poor air, firing in mine.

  6. Remote controlling the electronic furniture via Wi-Fi (2/3) • System components • Microcontroller –Atmega 2560 (Arduino) • Wi-Fi module • Sensors for specific applications • Devices-embedded Wi-Fi (light Wi-Fi)

  7. Remote controlling the electronic furniture via Wi-Fi (3/3) • System components
