  1. COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  2. COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  3. COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  4. WiMAX • WiMAX Router • RUT423, RUT425, RUT435 and RUT438 are compact routers offering high speed data rate connectivity to the WiMAX networks. Router is compliant with IEEE802.16e-2005 WiMAX Wave 2 standard and supports mobile wireless connectivity. 10/100 Base-T interface and integrated DHCP server allow easy connection to any device with ethernet cable. Router implements dual independent transmit chain with advanced 2Tx closed-loop diversity (2T-CLD) algorithm for significantly increased link budget, improved cell coverage and superior mobile performance. 2T-CLD delivers diversity gains well beyond single Tx solutions and ensures the best diversity for any channel environment. • Key Features: • IEEE 802.16e-2005 Compliant (Mobile WiMAX) • WiMAX Wave 2 Compliant • 10/100 Base-T LAN Interface • Embedded Web Server • Modern Graphical User Interface • Operates within 2.3 - 2.4, 2.5 - 2.7, 3.3 - 3.6 or 3.3 - 3.8 GHz Range • Compact Size (75mm x 45mm x 23mm) • 2 Tx with Closed Loop Diversity • HARQ Category 7 (40 Mbps combined UL and DL) • MIMO Matrix A and B for Improved Transmission Speed and Coverage • LEDs for Power, LAN and WiMAX Activity • DHCP server • Port forwarding • IP and MAC filtering COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  5. WiMAX • USB WiMAX Modem • UM6223, UM6225, UM6235 and UM6238 are compact USB modems offering high speed data rate connectivity to the WiMAX networks. Compliant with IEEE802.16e-2005 WiMAX Wave 2 standard it supports mobile wireless connectivity and is ideally suited for laptops and netbooks or can be used with stationary desktop PC. Modem incorporates separate embedded CPU for running connection management applications so only drivers are needed on host PC. Modem implements dual independent transmit chain with advanced 2Tx closed-loop diversity (2T-CLD) algorithm, for significantly increased link budget, improved cell coverage, and superior mobile performance. 2T-CLD delivers diversity gains well beyond single Tx solutions and ensures the best diversity for any channel environment. • Key Features: • Hostless Operation • IEEE 802.16e-2005 Compliant (Mobile WiMAX) • WiMAX Wave 2 Compliant • USB 2.0 Interface • Embedded Web Server • Operates within 2.3 - 2.4, 2.5 - 2.7,3.3 - 3.6 or 3.3 - 3.8 GHz Range • Compact Size • Self Install, no CD Required • 2 Tx with Closed Loop Diversity • Support up to HARQ category 7 (40 Mbps throughput DL+ UL) • MIMO Matrix A and B for Improved Transmission Speed and Coverage • LEDs for Link Status and Link Activity • Compatible with Windows XP/Vista/7, Linux, MAC OS X COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  6. WiMAX • Outdoor WiMAX Router • RUT723, RUT725, RUT735 and RUT738 are outdoor routers offering high speed data rate connectivity to the WiMAX networks. High gain MIMO antenna improves coverage and pole mounting kit ensures stable signal conditions. Included POE adapter allows the device to function with only Ethernet cable connected. • Key Features: • IEEE 802.16e-2005 Compliant • WiMAX Wave 2 Compliant • 10/100 Base-T LAN Interface • IEEE 802.3af-2003 Compliant POE (adapter included) • Embedded Web Server • Modern Graphical User Interface • Operates within 2.3 – 2.4, 2.5 - 2.7, 3.3 - 3.6 or 3.3 - 3.8 GHz Range • HARQ Category 7 (40 Mbps combined UL and DL) • 14 dBi dual-pol MIMO Antenna • Adjustable Pole Mounting Kit • Waterproof RJ45 Socket • MIMO Matrix A and B for Improved Transmission Speed and Coverage • DHCP Server • Port Forwarding • IP and MAC Filtering COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  7. WiMAX • WiMAX WLAN Router • RUT523, RUT525, RUT535 and RUT538 are compact WiMAX routers with high speed wireless and Ethernet connections. Compliant with IEEE802.16e-2005 WiMAX Wave 2 standard it supports mobile wireless connectivity. Router support latest IEEE802.11n and IEEE802.11b/g WLAN standards and provide wireless receiving and transmitting rate up to 150 Mbps. • Key Features: • WiMAX • IEEE 802.16e-2005 Compliant (Mobile WiMAX) • WiMAX Wave 2 Compliant • Operates within 2.5 GHz or 3.5 GHz WiMAX networks • 2 Tx with Closed Loop Diversity • HARQ Category 7 (up to 40 Mbps UL and DL combined throughput) • MIMO Matrix A and B for Improved Transmission Speed and Coverage • Router • Complies with IEEE 802.11n, IEEE 802.11g, IEEE 802.11b wireless standardsOver 3 times transmission distance of 11G productsComplies with IEEE 802.3 and IEEE 802.3u standardsFour Ethernet portsDurable aluminum housingIntegrated OpenVPN and Dynamic DNS COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  8. WiMAX • Mini PCI-E WiMAX Modem • GM6223, GM6225, GM6235 and GM6238 PCI Express Mini Card WiMAX modems offer high speed data rate connectivity via WiMAX networks. Both modems are compliant with IEEE802.16e-2005 WiMAX Wave 2 standard thus they support mobile wireless connectivity and are ideally suited for laptops, netbooks or any device with a Mini PCI-E socket. • Key Features: • Hostless Operation • IEEE 802.16e-2005 Compliant (Mobile WiMAX) • WiMAX Wave 2 Compliant • PCI Express Mini Card form factor • USB 2.0 Interface • Embedded Web Server • Integrated Firewall functionality • Operates within 2.3 - 2.4, 2.5 - 2.7, 3.3 - 3.6 or 3.3 - 3.8 GHz Range • 2 Tx with Closed Loop Diversity • 40 Mbps throughput (combined downlink and uplink) • MIMO Matrix A and B for Improved Transmission Speed and • Coverage • 2 x U.FL antenna connectors • Compatible with Windows XP/Vista/7, Linux, MAC OS COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  9. WiMAX • Outdoor WiMAX Camera • WiMAXCamera encompasses a large number of environmental monitoring applications. WiMAX technology provides wide coverage in remote areas allowing transmitting high resolution video or single images wirelessly.  Wireless camera saves installation time as no wired cable installation is required on the clients’ premises. • Key Features: • IEEE 802.16e Standard Compliant (Mobile WiMAX) • 2.3 – 2.4, 2.5 – 2.7 GHz, 3.3 – 3.6 GHz or 3.6 – 3.8 GHz frequency band • Video and/or single snapshot images • JPEG/H.264 compression • Image/Video recording to SD memory card • Pre-alarm function (transmit/record video before sensor activity) • Built-in Web server for monitoring via standard browser COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  10. WiMAX • WiMAX WLAN Router • RUT523U, RUT525U, RUT535U and RUT538U are compact WiMAX routers with high speed wireless and Ethernet connections. Compliant with IEEE802.16e-2005 WiMAX Wave 2 standard it supports mobile wireless connectivity. Router support latest IEEE802.11n and IEEE802.11b/g WLAN standards and provide wireless receiving and transmitting rate up to 150 Mbps. • Key Features: • WiMAX • External IEEE 802.16e-2005 compliant USB modem • WiMAX Wave 2 Compliant • Operates within 2.5 GHz or 3.5 GHz WiMAX networks • 2 Tx with Closed Loop Diversity • HARQ Category 7 (up to 40 Mbps UL and DL combined throughput) • MIMO Matrix A and B for Improved Transmission Speed and Coverage • Router • Complies with IEEE 802.11n, IEEE 802.11g, IEEE 802.11b wireless standardsOver 3 times transmission distance of 11G productsComplies with IEEE 802.3 and IEEE 802.3u standardsFour Ethernet portsUSB portDurable aluminum housingIntegrated OpenVPN and Dynamic DNS COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  11. GSM/GPRS/EDGE/HSDPA modems • Good speed for reasonable price. • Be advanced by staying online wherever you are! • Manage your remote devices in real-time! • Send and receive e-mails! • Browse WEB databases! • Access VPN! • Send SMS messages from your PC or server! • TeltonikaModemCOM/G10 is a simple, but powerful tool for wireless connection of personal or industrial computer to the Internet. This device acts like an ordinary modem, controlled by AT commands, so almost no changes would be required, if you used a fixed line modem before and want to upgrade to wireless modem. • Real-time business transaction, sending and receiving e-mails, browsing WEB database, accessing VPN and sending SMS messages from your PC or server - all in your hand! With the help of TeltonikaModemCOM/G10, you can maintain your top mobility, easy access to the Internet no matter you are in a train, bus, or in a car. • Unlike PCMCIA modems, TeltonikaModemCOM/G10 can be connected not only to notebook, but to any PC having COM support. • Main features: • The data type and data transfer speed depends on the service provided by your GSM operator. ModemCOM/G10 supports the following data-bearers: • GPRS: • Quad Band GPRS modem 850/900/1800/1900 MHz. • Capacity class 4 (2W) 850/900 MHz waves. • Capacity class 1 (1W) 1800/1900 MHz waves. • GPRS class 10. • GPRS CS1 – CS4. COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  12. GSM/GPRS/EDGE/HSDPA modems • CSD/GPRS • CSD: • Up to 9.6 kbps. • Terminal Equipment Interfaces • Supported Operating Systems: Win 2000, XP (SP2). • Drivers available: Linux kernel 2.4.32 or higher; Mac OS X. •  Connectors: • DB9 female for connection to PC. • 3,5 mm / 1,35 mm power supply connector. • Convenient push-push SIM card holder. • SMA connector for GSM antenna (optional). • Dimensions: • Housing dimensions: LxWxH 94mm x 64mm x 28mm (not including external antenna connector). • Package contents: • 1. TeltonikaModemCOM/G10. • 2. Power Supply (European and American versions available). • 3. RS232 cable. • 4. A CD with drivers and User’s Manual. • 5. A Quick Start Guide. • 6. GSM antenna (optional). • Features on demand • External antenna. • Support of more than one SIM card. • Great experience of branding (fully adopt the device and the package to your brand: choose your colors, logos and brand name). COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  13. GSM Voice Fax Gateway TVF200 Teltonika Voice Fax Gateway is a multifunctional device designed for facsimile and voice calls.Device works as fixed line equivalent so it eliminates fixed line and saves costs. Connection schemes: • Features: • The RF transceiver modulates the baseband signal to the desired frequency in the 900MHz or 1800MHz. • FAX G3, Class 2.0 • Two RJ14 sockets • SMA antenna connector • Configuration over DTMF • Product Kit: • Voice Fax Gateway unit • AC/DC power supply • Antenna • User guide • Cardboard box • Technical specifications • Dimentions: (H x W x L) 37 x 140 x 106 mm • Power adapter input: 100-240V • Power adapter output: 9-12V COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  14. GSM Voice Fax Gateway TVF200 • Configurable options • Volume level controll • Time interval between dialing and connecting • Prefix adding • Voice Fax prefix switching • Caller ID display control • Calling line identification restriction • Turning on/off the call duration signal • Changing Service menu password • Sepparate or duplicate RJ14 sockets • Baby Call • PIN code entering control • Prefix blocking • Number blocking • Number of rings to answer • Number of facsimile retries • Delay between retries • Allways answer as fax • Delete facsimile from memory after retries • Show incomming number of pages COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  15. Fleet management systems FM1100 • The smallest FM we've ever made • Car tracking• Parametrized operation (acquire & send)• Integrated scenarios• Green driving (ratings of acceleration, breaking, cornering)• Overspeeding• Authorized driving (50 iButton keys)• Immobilizer • Online tracking• Low energy consumption in deep sleep mode • Small size • TECHNICAL DETAILS • GSM • Quad-band 900/1800 MHz; 850/1900 MHz • GPRS class 10 (up to 85,6 kbps); • SMS (text/data) • GPS • NMEA, GGA, GGL, GSA, GSV, RMC, WGS-84 protocol compatible • 50 channel GPS receiver • -161 dBm sensitivity Interface • 1 Digital Input Reserved for Ignition Status Monitoring • 2 Digital Inputs • 2 Digital Open-collector Outputs (connecting external relays, LED, buzzers etc.) • 1-Wire® protocol • Power supply (+10...+30) V DC • 2 Status LEDs COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  16. Fleet management systems • USB Port • Configuration and firmware upload (FOTA and via USB cable) • External GSM antenna (SMA connector) • External GPS antenna (MCX connector) Features • GPS and I/O data acquisition • Real Time tracking • Smart algorithm of data acquisition (time, distance, angle, ignition and event based) • Sending acquired data via GPRS (TCP/IP and UDP/IP protocols) • Smart algorithm of GPRS connections (GPRS traffic saving) • Operating in roaming networks (preferred GSM providers list) • Events on I/O detection and sending via GPRS or SMS. • Scheduled 24 coordinates SMS sending • 5 geofence zones (rectangular or circle) • Deep Sleep mode (saving vehicle's accumulator) • FOTA (firmware updating via GPRS) • Motion sensor • Small and easy to mount case • Roaming dependant operation (GPRS traffic saving in roaming zones) • Operation mode presets: • Advanced overspeeding detection • Driver behavior monitoring (acceleration/breaking/cornering notification • to minimize the vehicle exploitation costs) • Driver identification (1-Wire® iButton ID key) COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  17. Fleet management systems FM3200 • Car security/tracking • Parametrized operation (acquire & send) • ALARM button • Online tracking • Geo-fence • Motion sensor • Low energy consumption in sleep mode • Internal backup battery • FM3200  is  light terminal with GPS and GSM connectivity, which  is able to get device  coordinates and other data and  transfer  them  via GSM network. This device  is  perfectly  suitable  for  applications  where  location  acquirement  of remote objects is needed. So you can track your remote objects (trucks, cars, ships etc) quickly and easily. • FM3200 can perform tasks on remote objects, such as monitoring engine status, controlling  truck's door and etc. • In case of  loosing connection FM3200 can store up to 15000 records, and once the connection  is established the device will send stored data via GPRS. So you won't lose your data  (coordinates,  sensors data and etc.). • TECHNICAL DETAILS • GSM • Dual-Band 900/1800 MHz • GPRS class 10 (up to 85,6 kbps) • SMS (text/data) • GPS • NMEA, GGA, GGL, GSA, GSV, RMC, WGS-84 protocol compatible • 50 channel GPS receiver • -160dBm sensitivity COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  18. Fleet management systems • Interface • Inputs: • 2 digitalinputs(fordooropeningmonitoring, panicbuttonorotherdigitalsensors) • 2 pinsforpowersupplycanmeasurevehiclebatteryvoltage (analog) and (inmostcases) enginestart (generatedhighervoltageonvehicle'sbattery) • Virtual (Data) inputs: • driven distance (GPS odometer); • vehicle speed monitoring • 2 Digital Outputs • Power supply +10V...+30V • 3 Status LEDs • USB Port • Configuration and firmware upload • Internal GSM antenna • External GPS antenna • FEATURES • GPS and I/O data acquisition • Real Time tracking • Smart algorithm of data acquisition (time, distance and event based) • Sending acquired data via GPRS (TCP/IP and UDP/IP protocols) • Smart algorithm of GPRS connections (GPRS traffic saving) • Operating in roaming networks (preferred GSM providers list) • Events on I/O detection and sending via GPRS or SMS • Scheduled 24 coordinates SMS sending • 5 geofence zones (rectangular or circle) • Sleep mode (saving vehicle's accumulators) • Internal NiMh 300 mAh backup rechargeable battery • OTA (firmware updating via GPRS) • Motion sensor • Small and easy to mount case • Applications • Security • Track and trace • Road assitance • Toll collect • Insurance COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  19. FM4200 Fleet management systems • New generation advanced automotive tracker • FM4200 is a terminal with GPS and GSM connectivity, which is able to get device coordinates and transfer them via GSM network. This device is perfectly suitable for applications where location acquirement of remote objects is needed. So you can track your remote objects (trucks, cars, ships, etc.) quickly and easily. • It has option of rechargeable battery inside and special controller for power management. Also there is an option of using external backup battery. Thus it can operate for up to 48 hours in Normal (Sending via GPRS) mode with external backup battery. FM4200 can perform tasks on remote objects, such as monitoring temperature, engine status, fuel consumption, controlling truck’s door, etc. • In case of losing connection FM4200 can store up to 7500 records, and once the connection is established the device will send stored data via GPRS. So you won’t lose your data (coordinates, sensors data, etc.). • The case of the device is robust and easy mountable for installation into harsh environment. • Monitor: • See when ignition is ON or OFF • Identify drivers with I-Button • Monitor fuel consumption • See when battery voltage is falling • Monitor temperature level in refrigerator • See when doors are open or closed • Acquire vehicle's CAN data • MAIN FEATURES • Track your remote objects (trucks, cars, ships etc) quickly and easily • The device supports the following GSM bearers: • GPRS class 10 (up to 85,6 kbps) • SMS (text/data) COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com • Dual-band GSM - 900 MHz / 1800 MHz • LOW energy consumption in deep sleep mode (less then 6 mA@12V) • Option of internal (or external) rechargeable battery with charge controller

  20. Fleet management systems • FM4200 has: • 4 digital inputs • 4 digital outputs • 4 analogue inputs (2 ranges 10V and 30 V, 10 bit resolution) • This could be used for performing tasks on remote objects, such as monitoring fuel tank level, engine status, or controlling truck door etc. • FM4200 has 1-Wire® I/O protocol integrated for temperature measuring or key ID identification. • FM4200 has CAN interface for FMS interface of trucks, which enables data acquisition from trucks on-board computer. • FM4200 has RS232 port which could be used for external peripheral data acquire • Voice function • 2 LED indicators: “Status” and “Navigate” • The package includes antenna, Coloured I/O cables and data cables • Teltonika’s firmware for the device enables such functions as: • GPS and I/O, 1-Wire, CAN data acquisition • External sensors connection capability • Real Time tracking • Smart algorithm of data acquisition (time and distance based • Sending acquired data via GPRS (TCP/IP and UDP/IP protocols) • Smart algorithm of GPRS connections (GPRS traffic saving) • Flexible configuration of data sending in roaming networks (depending on GSM providers list) • Events on I/O detection and sending via GPRS or SMS • Scheduled 24 coordinates SMS sending • Multi geofence zones (rectangular or circle) • Sleep mode and deep sleep mode (saving vehicle’s accumulators) • Acceleration detection (harsh breaking and accelerate measuring) • OTA (firmware updating via GPRS) • Real time internal processes monitoring • Authorized numbers list for commanding • *Service availability and maximum speed depends on your GSM operator. The specifications are subject to change without prior notice COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  21. Fleet management systems FM5300 • FM5300 is advanced terminal with GLONASS/GPS positioning and GSM connectivity, which is able to get device coordinates and other data and transfer them via GSM network. This device is perfectly suitable for applications where location acquirement of remote objects is needed. So you can track your remote objects (trucks, cars etc) quickly and easily. • In case of losing connection FM5300 can store more than 16000 records, and once the connection is established the device will send stored data via GPRS. So you won't lose your data (coordinates, sensors data and ect.). • Features: • GPS/GLONASS coordinates and I/O data acquisition • Real Time tracking • Smart algorithm of data acquisition (time, distance, angle, ignition and event based) • Sending acquired data via GPRS (TCP/IP and UDP/IP protocols) • 16000 records saving into flash memory • Two RJ45 (RS232) ports • RJ45 ports can be used to connect two LLS digital fuel sensor without a concentrator • RFID reader can be connected to use it for authentification purposes • Garmin navigation can be connected to send direct messages and new destinations to driver • Smart algorithm of GPRS connections (GPRS traffic saving) • Operating in roaming networks (preferred GSM providers list) • Events on I/O detection and sending via GPRS or SMS. • Scheduled 24 coordinates SMS sending • One configuration file enables convenient configuration COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  22. Fleet management systems • Data reading from CAN Bus (FMS standard) • CAN Bus Autoscanfuncionality which enables to automatically configure CAN bus data reading and therefore simplifies configuration process • Multi geofence zones (rectangular or circle) • Autogeofencingfuncionality which automatically draws geozones of certain radius, decreasing risk of car theft • Deep Sleep mode (saving vehicle‘s accumulator) • Firmware update and configuration using USB interface • OTA (firmware updating via GPRS) • Built-in 550 mA battery • Accelerometer • Small and easy to mount case • Roaming dependant operation (GPRS traffic saving in roaming zones) • Acceleration detection (harsh breaking and accelerate measuring) • Operation mode presets • Advanced overspeeding detection • Driver behavior monitoring (acceleration/breaking/cornering notification tominimize the vehicle exploitation costs) • Driver identification (1-Wire® iButton ID key) • Immobilizer scenario which enables to start engine only after reading the 1-Wire® iButton ID • Authorized driving which enables to start engine only after reading the 1-Wire® iButton ID from authorized ID list. List can contain 50 different ID's COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  23. FM5500 Terminal GLONASS/GPS GSM/GPRS Possibility to use 2 SIM cards which allow using two different GSM operators to reduce the bills • Multi system positioning engine • Vehicle online tracking • Parametrized operation (acquire & send) • Integrated scenarios: • ECO driving (ratings of acceleration • breaking, cornering based on • accelerometer) • Overspeeding • Authorized driving (50 iButton keys) • Immobilizer • Low energy consumption in deep sleep mode • APPLICATIONS: • International logistics • Vehicle tracking • Road assistance • Track and trace • Fuel consumption metering • Fleet management FM5500 is an advanced terminal with GLONASS/GPS positioning and connectivity, GSM/GPRS which is able to get device coordinates and other data and transfer them via GSM network. This device is perfectly suitable for real time object location and parameters monitoring. So you can track your remote objects (trucks, cars etc.) quickly and easily. In case of no GSM coverage FM5500 can store more than 150000 records and once the GSM connection is established stored data will be sent to server so you will not lose your data (coordinates, sensors data and etc.). COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  24. Terminal GLONASS/GPS GSM/GPRS • TECHNICAL DETAILS • GSM/GPRS: • Quad-band 900/1800 MHz; 850/1900 MHz • GPRS class 10 (up to 85,6 kbps) • SMS (text/data) • GPS/GLONASS: • NMEA-0183 protocol • 32 channel receiver • High sensitivity, not less than -160 dBm • Interface: • 4 Digital Inputs for object status monitoring • 4 Analog Inputs (switchable 10 V or 30 V range, 12 bit resolution) • 4 Digital Open-drain Outputs (controlling external relays, LED, buzzers, etc.) • 1-Wire® interface • CAN interface • Power supply (+10...+30) V DC • 2 Status LEDs • USB interface • 2x RS232 ports • Configuration and firmware update (FOTA and via USB cable) • External GSM antenna • External GNSS antenna • Internal (or optional external) rechargeable backup battery with charge controller • Voice interface • RS485 interface • Integrated automotive power protection, compatible with ISO 7637-2 standar COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  25. Terminal GLONASS/GPS GSM/GPRS Features: • 2 SIM Compatibility • Up to 150 000 records can be stored on flash memory • GPS/GLONASS coordinates and I/O data acquisition • Real Time tracking • Smart data acquisition (based on time, distance, angle, ignition and events) • Sending acquired data via GPRS (TCP/IP and UDP/IP protocols) • Smart algorithm of GPRS connections (GPRS traffc saving) • Operating in roaming networks (configurable GSM providers list) • Events on I/O detection and sending via GPRS or SMS • Scheduled 24 coordinates SMS sending • Multi geofence zones (rectangle or circle) • Deep Sleep mode (less power consumption) • FOTA (firmware updating via GPRS) • Accelerometer • Small and easy to mount case • Roaming dependent operation (GPRS traffic saving in roaming zones) • Operation mode presets • Over Speeding Detectio • Harsh driving detection (harsh braking, harsh acceleration and harsh cornering) • Driver identification (1-Wire® iButton ID key( • GPRS commands * • External RS232 peripherial device support: * • GARMIN FMI support • 2x LLS support TELTONIKA, JSC • RFID protocol support COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com * - available from 01.xx.xx firmware

  26. Terminal GLONASS/GPS GSM/GPRS • FM5500 has large internal Flash memory (16MB) • Up to 150 000 records or data from up to 180 days using standard configuration (min. period = 10 min, min. distance = 1 km and all I/O elements enabled) can be stored on internal flash memory • There is a possibility to disable data sending while in Roaming and to store data on internal flash memory. Stored data will be sent to server when FM5500 will register to home operator. • FM5500 can be used without a GSM connection • Additional function – Offline data logging – allows to download acquired data from FM5500 to PC via USB and later to upload it to TAVL server.This functionality helps to avoid high GSM bills caused by expensive roaming operators and keep acquired data save until it is downloaded to PC. • FM5500 supports a remote logs reading • FM5500 supports remote diagnostic logs functionality using GPRS. Possible issues resolving becomes more faster. Manufacturer can read logs remotely using SMS/GPRS to diagnose the FM5500 and timely respond to the fault. COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  27. Asset Tracker AT1000 • DESCRIPTION:AT1000 issuper-lightterminalwith GPS and GSM connectivityandautonomousbattery, whichisabletogetdevicecoordinatesandtransfervia GSM (GPRS or SMS). Thedeviceisperfectlysuitableforapplicationswherelocationacquirementofautonomousremoteobjectsisneeded. Trackyourassetswherevertheyare! • KEY FEATURES: • Smallsize • Longautonomouslifetime • SMS/GPRS communication • Flexibleconfigurationuptoyourapplication • Motionsensor • IP65 enclosure • APPLICATIONS: • Containertracking • Secrettracking • Security (Anti-theft) • Rail-carriagetracking • Transitgoodstracking • TECHNICAL DETAILS: • GSM: Quad-band 900/1800 MHz; 850/1900 MHz; • GPRS class 10 (upto 85,6 kbps); • SMS (text/data); • GPS: -160dBm sensitivity • Interface: USB Port • Configurationandfirmwareupload • Size: 148 x 84 x 36 mm COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  28. Asset Tracker • * - Lifetime is declared approximately and strongly depends on using conditions and device configuration (GSM/GPRS coverage, GPS visibility, configured parameters, temperature, place of mounting, batteries energy level etc). • FEATURES: • GPS data acquisition • Real Time tracking • Remote online/offline administration • Smart Geofence behaviour • Sending acquired data via GPRS (TCP/IP) • Operating in roaming networks (preferred • GSM providers list) • OTA (firmware updating via GPRS) • Motion sensor • Small and easy to install case COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  29. MH2000 Lightweight personal security tracker • MH2000 is an easily configurable smart tracking device combining GPS and GSM technologies. The device can be fully adapted to user requirements. Its main purpose is to act as a mobile tracking client for various security system solutions and applications: • Child tracking and security • Emergency companies • Service companies (personnel tracking) • Hospitals and other health-care institutions • The device works autonomously using internal rechargeable battery. • Key FeaturesEasy to use and configureEasy accessible Alarm buttonLong battery life65 channel GPS receiverDual band GSM moduleSMS requests, responses and configurationRemote configurationOnline tracking / 24 coordinates historyPersonal security and recoveryNotification about discharged battery • MH2000 General specificationGPS receiver  - YES (-161dBm / 65 channels)Internal GPS antenna – Patch (Dimensions: 25 x 25x 4)GSM module – YESFrequencies (MHz) – 900/1800 or 850/1900Keyboard – 2 (Alarm and turn on/off buttons)Battery – 1050 mAh (Li-ion)LED indicators – Battery / GSM / GPS-AlarmWeight – 80g (with battery)Dimensions (mm) – 92 x 44 x 18 COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  30. MH2000 Lightweight personal security tracker Data transferSMS – Requests / Alarm Connection to a PCConnector – YES (Firmware update and debug) ConfigurationConfiguration via SMS – YES MemoryInternal memory – 24 coordinates OtherRecommended operating temperature 0 up to 50?CStorege temperature -  -20 up to 60?CBattery life 24 coord./day  - 150 hourBattery life 24 1 coord./day  - 350 hourBattery life sleep  - 420 hour COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  31. Applications:Outdoor safety for elderly peopleLone worker protection (Man Down function)Children protectionAsset security Advantages:Man down function: movement sensor for fall detection and power savingAlarm button for data and voice transmissionVoice callsLoudspeakerPolygonal Geofence zonesParking functionSilent callModem emulationRemote control by SMS General information:GPS Sensitivity -160dBm, 50-channelsDual-band (optional)Internal memory 1MbMicro USB connectorFive keys for a function executionRecomended operating temperature 0 up to 50CStorage temperature -20 up to 60CThree LED indicators for device status indicationWeight 80gBattery 1050mAh (Li-ion)Dimensions 92x44x18Sending acquired data via GPRS (TCP/IP and UDP/IP protocols) Accessories (optional):12V to 5V Car charger230V to 5V chargerNeck trapQuick start user‘s manualCD with track assistant software and driversUSB-micro USB data cableMini screw for cover fixing Handheld GPS/GSM Tracker GH3000 COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  32. Wireless controllers Wireless Control Terminal TWCT22 • Are you looking for a product which allows you to monitor and control your remote units/equipments? Do you need a product which not only enables remote monitoring and control but also sends you SMS/Email in case of alarm conditions? If yes, then TWCT22 is the product which would fulfill these needs in the most effective and economic way. TWCT22 is an advanced yet simplified Remote Terminal Unit. Taking advantage of the reliable, widespread GSM networks and the supported GPRS service, TWCT22 becomes a remotely accessible unit from any part of the world. Using an embedded feature rich web server interface, you can configure various parameters of TWCT22. The inputs present on TWCT22 can be used for monitoring of external devices or connecting sensors (analog/digital). Alarm conditions can be configured for monitoring of these inputs. Since TWCT22 supports SMS and SMTP protocols, the device can be configured to send SMS/Email whenever alarm conditions occur. TWCT22 also gives you the freedom to control the states of the connected outputs. By sending a simple SMS you can change/get the status of the outputs. • Given the set of hardware features, software ability and GSM connectivity TWCT22 is an ideal product for use in wide variety of application areas. With minimal to no effort, TWCT22 can be easily integrated in an operational system with ease. Some of the application areas could be (the list is however not limited to these application areas) • Security systems       • Irrigation & fire alarm systems      • Building surveillance and control     • Home & garden automation projects     • Heating, lighting & climate control     • Remote monitoring and device/equipment control • Wide coverage of GSM networks and the provision of GPRS connectivity have made it possible to interconnect systems wirelessly. TWCT22 exploits the benefits of this wireless technology and gives you control of your remote units from any part of this World. All-in-all TWCT22 is an advanced, effective and an economical solution for fulfilling your needs of remote monitoring and control applications. COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  33. Wireless controllers • Features: • Dual band: 900/1800 MHz • 7A relay outputs, to drive heavy loads • Surge and reverse voltage protection on all the inputs. • Two Analog inputs with mode selection, voltage mode (0-10V) or current mode (4-20mA) • Turn ON/OFF the outputs by sending SMS • Alarm message service over SMS or email • Simple configuration through any web browser • DIN rail mounting, for easy integration in industrial environment • 4 LED‘s for input status, 4 LED‘s for output status • Dual color device status LED • 12-24V power supply, ideal for use in heavy duty vehicles like buses, trucks • Watchdog controller ensures reliable and continuous operation • RS232 hardware interface. • Firmware upgrade possibility • Electrical: •  Power 12V - 24V ±10% • 4 digital inputs (“0” (false) 0 3V, “1” (true)3-24V, terminal blocks) • 2 analog inputs. (0 10V, 4-20mA, terminalblocks) • 4 relay outputs (~250V, 7A, terminalblocks) COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  34. Gate Controller Wireless controllers • Do you need a product which can provide authorized access system for car parking or door control mechanisms? A product which allows you to turn ON/OFF your system, machines, equipments remotely? If yes, then all you need is Teltonika’s VRT014 remote switch. • VRT014 is a very simple device which can be used for authorized door access, controlling gates, switching of remote equipments, car parking systems; activate/deactivate alarm systems and etc. Actually this device can be used in places which require ON/OF switching action. • Your cell phone can become your Remote control. You don’t need any more the ordinary remote control, because you will be able to open your Barriers and doors with your cell phone. Just dial from Authorized User number and the Barrier and doors are opened. There are no call costs; the device rejects the call from authorized number • Let you phone do 2 jobs – call and control. • No need to provide a remote control for different users. • Real time add/remove users. • Control by SMS. • No call costs. • VRT014 is also a configurable device. User can configure the settings for relay and authorized phone numbers. There are two ways in which the device can be configured; • By sending an SMS. • By connecting the device to a PC using COM port interface and then using the VRT014 configuration software. • In short it can be said that VRT014 is a simplified, user-friendly and economical product which can be easily integrated into your existing system with minimal modifications. • Who needs VRT014: • Home and garage owners • Business companies • Hotels • Hospitals • Parking places • Warehouses COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  35. Wireless controllers • Features: • Wireless control using the GSM • Up to 500 authorized phone numbers can be configured • Automatic relay turn OFF through relay timeout or external input • Remote configuration through SMS • Local configuration through RS232 (serial) port • In built relay with 5A current rating • External GSM antenna • Easy integration into existing systems • Small form factor with DIN railing package • Easy to use configuration software • Technical specifications: • Dual band 900/1800 Mhz GSM modem • Non-answering call support • Text SMS support • 5A relay rating • Single digital input • Connector: Serial port (using RJ45 socket) • 12V DC power supply • 4 single colour LED’s • External antenna connector (SMA) COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  36. Wireless controllers WirelessCOM/G10 TeltonikaWirelessCom/G10 is a device designed for communication with remote devices which have RS232 ports. RS232 interface is one of the industries leading standard. This interface can be found in a large variety of devices like, data loggers, POS terminals, vending machines, PLCs, control panels, various meters, switches, routers and the list goes on.  It is a frequent case when such devices are present in remote locations and there is a need to monitor/control/collect data. In such cases GSM network coupled with GPRS/CSD service can provide a very reliable wireless solution.  TeltonikaWirelessCom/G10 is ready-to-go solution for such situations. It acts as a transparent RS232 port. Thus you would be able to see your devices as directly connected to the computer, no matter how far you are from your devices. Why do you need to go to your devices for data collection, for device configuration or to monitor and control them, if it can be easily done over the internet using TeltonikaWirelessCom/G10. Simply connect TeltonikaWirelessCom/G10 to your remote device via RS232 interface and configure WirelessCom/G10 to connect to your server. Whenever some data arrives from your machine to the serial port, WirelessCom/G10 will connect to the configured server and make data transfer. Upon connection you can even send commands to your machine/device from your PC remotely. WirelessCom/G10 will thus transmit all the data coming on its serial port to GPRS and all the data coming from GPRS to serial port. In short it is acting as a bridge between GPRS and the serial port. In addition to GPRS you can also use CSD connection and reach your remote devices just by dialing into the SIM number of WirelessCom/G10. WirelessCom/G10 also supports SMS bearer. Using SMS you can remotely configure the settings of WirelessCom/G10.   The device can act as a master, and initiate the connection to the server or it can act as a slave and wait for incoming connection. All in all TeltonikaWirelessCom/G10 provides a cost-effective wireless solution of controlling your remote devices which have RS232 interface. No matter how far you are, you can always stay connected with your devices.  COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  37. Wireless controllers • Features: • Providestransparent GPRS/CSD connection • Receive SMS alertswhenexceptionsoccurindevice • Nodriversrequired, henceworkswithanydevice/machine/equipment/computer • Simpleandinformativeconfigurationmenu • Configurablethroughanyterminalsoftware • Hardwareresetfrom DTR pin (optional) • Deviceisremotelyconfigurablethrough GPRS/CSD/SMS • Accessonlythroughauthorizedphonenumbers (for CSD and SMS) • Upto 5 configurableauthorizedphonenumbers • Auto PIN feature, noneedtoenter SIM card PIN afterrestart • Passwordprotectedconfiguration • Dualcolour LED indicationforvariousstatesofdevice (Upto 9 states) • Supportsvariousdataformats (8N1,8N2,8E1,8O1,7E1,7O1) • Firmwareupdatepossibility • CHAP/PAP authenticationsupported • CE certified • Technicalspecifications: • GSM: • Quadband: 850/900/1800/1900 MHz • GPRS Class 10: 16-24 Kbpsupload, 32-48 Kbpsdownload • CSD: Upto 9.6 Kbps • SMS: Textmode COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  38. Wireless controllers • RS232 interface: • Socket: DB9 female • Datarate: Upto 115200 • Databits: 7,8 • Parity: Odd, Even • Flowcontrol: No • Physical: • DB9 Femaleconnectorforconnectingtoa PC (orotherdevice). • SIM cardholder. • 3.5 mm /1.35 mmpowersupplyconnector. • LatestVersions: • - WirelessCom_G10 Quickstartguide 1.0.0- WirelessCom_G10 Usermanual 4.0.1- WirelessCom_G10 Firmware 2.3.0 • Featurescomingup: • - Clockfunctionality (24hour clock), configureWirelessCom/G10 toconnecttoyourserveratapreconfiguredtime. • - WirelessCom/G10 utilitytool, aPC-sideall-in-onesoftwarewhichwouldinclude (intheorderofpriority), • WirelessCom/G10 configurator • WirelessCom/G10 firmwareflasher • Simpleterminalsoftware • Tcp-serial-tcpsoftware • Virtualserialportsoftware • * Thespecificationspresentedinthisflyeraresubjecttochangewithoutpriornotice. Maximumdataspeedsmentionedintheflyer, dependontheservicesprovidedbyyour GSM operator. COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  39. Video monitoring GSM EDGE Camera • MVC-100 EDGE Camera - compact mobile surveillance and monitoring system for transmission of high resolution video and single images via GPRS/EDGE network, so even in places with no Internet connection available - ideal for remote surveillance and monitoring of temporary or distant sites or mobile assets. The images can be aquiredautomaticaly with programmable period and/or upon external triggers such as motion sensors or door contacts. The video and single images can be viewed on a PC or a handheld device, and can also be transmitted to FTP-server and/or by e-mail. The video and single images can be recorded on a local microSD card and later downloaded or reviewed via built-in Web server.  • Main features: • Video clip (desirable time duration) and/or single snapshot images • JPEG and MPEG-4 compression • Images can be saved on a local microSD card • Lens can be selected according to user requirements and needs • Built-in microphone for audio surveillance • Built-in Web server for monitoring via standard browser • Quad Band 850/900/1800/1900 MHz GPRS/EDGE network COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  40. Video monitoring MVC300 • Video logger / IP camera • The MVC300 camera is a sleek and compact video recording device perfect for in-car mounting: an ideal solution if you want to capture any significant events that might occur on the road. With Ethernet functionality you can take the MVC300 camera out of the car altogether and integrate it into a stationary surveillance system.  • Key Features: • Digital video recorder (DVR) • IP network camera • Recording to SD card and RTSP streaming • 5Mpixel sensor • Full HD • Ethernet port • Embedded web server • Two powering options • Microphone • IR LEDs and light sensor (for night version) COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  41. Video monitoring MVC330 • Outdoor IP Camera for video recording  and Surveillance • Teltonika outdoor Camera encompasses a large number of environmental monitoring applications and is an ideal solution if you want to capture any significant events that might occur on the area. It can also be used as a fully-fledged IP network camera. Simple installation and remote management allows user deploying the device easily. ‘Live’ video stream can be accessed from any location via  Web Users Interface or through any video player. Camera has a huge amount of control settings and operational modes that can satisfy even the most demanding user’s needs. • Key Features: • Digital video recorder (DVR) • IP network camera • Recording to microSD card and RTSP streaming • 5Mpixel sensor • Full HD • Ethernet port • Embedded web server • Video/Alarm In/Alarm Out/Power via single Ethernet cable COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  42. Mobile routers RUT500 • HSPA+ wireless router • RUT500 is compact HSPA+ 3G router with high speed wireless and Ethernet connections Internal HSPA+ modem can reach download rate of up to 14.4Mbps.Router support latest IEEE802.11n and IEEE802.11b/g WLAN standards and provide wireless receiving and transmitting rate up to 150 Mbps. • Key Features: • HSPA+ 14.4Mbps DL and 5.75Mbps UL • Quadband UMTS and GSM • Complies with IEEE 802.11n, IEEE 802.11g, IEEE 802.11b wireless standards • Complies with IEEE 802.3 and IEEE 802.3u standards • Four Ethernet ports • Durable aluminum housing • External antennas • Integrated OpenVPN and Dynamic DNS • 3G backup WAN function • SMS reboot function • DIN rail mounting (optional) COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com

  43. Мы поможем сделать Ваш бизнес эффективным! За более подробной информациейи приобретения системы обращайтесь к нашим специалистам: sales@uti360.com support@uti360.com Спасибо за внимание! США A: PO Box 13154, Shawnee Mission, KS 66282 P: +1 (479) 422 5365 New Zealand A: Level 2, 135 Broadway, Newmarket, Auckland 1013 A: PO Box 9635, Newmarket, Auckland 1149P: +64 9 373 6555 UK A: Withall & Co., Squires House, 145A High Street, West Wickham,Kent BR8 0PH Australia A: Suite 201, 220 George St., Sydney, NSW 6432 SALES: 1300 353 136SUPPORT: 1300 540 882 Украина A: 03028, Оф. 1, П. Феодосийский 14, Киев P: +38 (044) 250 72 89 (063) 991 1199 COMPANY UT www.UTi360.com sales@uti360.com support@uti360.com
