  1. Nuclear Energy

  2. Using Nuclear Energy • There are currently 65 commercially operating nuclear power plants with 104 nuclear reactors in 31 states around the country. These plants have generated about 20% of U.S. electricity each year since 1990. Source: www.eia.gov

  3. Nuclear Reactors • All reactors have: • Fuel that can undergo fission • Control rods to control the reactions • A cooling system to keep the reactor from being damaged • A core where the actual fission takes place

  4. Nuclear Fuel • Only certain elements can undergo nuclear fission. • Uranium-235 is most commonly used • Enriched uranium for nuclear power is 3% - 5% Uranium

  5. The Reactor Core • Nuclear fuel pellets are stacked together to form fuel rods. • Control rods absorb nuclei to slow the chain reactions • Water is pumped through the core to remove the heat • 1g of matter is converted into energy for every 1kg uranium that undergoes fission Energy from 1 kg uranium = energy from 3 million kg coal

  6. Nuclear Fission • When uranium-235 nucleus absorbs a neutron, it splits into 2 smaller nuclei and 2 or 3 extra neutrons • The extra neutrons are absorbed into the nuclei of other atoms in a chain reaction

  7. Nuclear Power Plants

  8. Nuclear Power Plants • Fission is very, very hot • The heat from fission reactions is used to heat water and produce steam • The steam is used to rotate a turbine • The turbine drives an electric generator • The overall efficiency is about 35%, about the same as coal or gas power plants

  9. Advantages • Nuclear power plants do not release air pollutants or carbon dioxide • Can reduce the effects of global climate change

  10. Risks • Accidents could release radioactive chemicals into the environment • Radioactive waste materials must be safely disposed of • Low level waste remains radioactive for a short time • High level waste remains radioactive for tens of thousands of years

  11. Chernobyl Disaster 1986

  12. Fusion • Hydrogen nuclei join together at high temperatures converting a small amount of mass to energy • Hydrogen would be a cheap abundant fuel source • Has to happen at temperatures of millions of degrees
