‘C’ for Microcontrollers, Just Being Efficient

1. ‘C’ for Microcontrollers,Just Being Efficient Lloyd Moore, President Lloyd@CyberData-Robotics.com www.CyberData-Robotics.com

2. Agenda • Microcontroller Resources • Knowing Your Environment • Memory Usage • Code Structure • Interrupts • Math Tricks • Optimization

3. Disclaimer • Some microcontroller techniques necessarily need to trade one benefit for another – typically lower resource usage for maintainability • Point of this presentation is to point out various techniques that can be used as needed • Use these suggestions when necessary • Feel free to suggest better solutions as we go along

4. Microcontroller Resources • EVERYTHING resides on one die inside one package: RAM, Flash, Processor, I/O • Cost is a MAJOR design consideration • Typical costs are $0.25 to $25 each (1000’s) • RAM: 16 BYTES to 32K Bytes typical • Flash/ROM: 384 BYTES to 256K Bytes • Clock Speed: 4MHz to 80MHz typical • Much lower for battery saving modes (32KHz) • Bus is 8, 16, or 32 bits wide (just like the old days)

5. Other Considerations • Specialized resources often present • Counters, UART, USB PHY, LCD Controller • Portability inside families a big concern • Across families, not so much • Typically no operating system present • May have hardware centric API, or just raw registers! • No floating point hardware • May have other math hardware (MAC, CRC) • No protected memory / MMU • Do have specialized memory segments

6. Power Consumption • Microcontrollers typically used in battery operated devices • Power requirements can be EXTREMELY tight • Energy harvesting applications • Long term battery installations (remote controls, hard to reach devices, etc.) • EVERY instruction executed consumes power, even if you have the time!

7. Know Your Environment • Traditionally we ignore hardware details • Need to tailor code to hardware available • Specialized hardware MUCH more efficient • Compilers typically have extensions • Interrupt – specifies code as being ISR • Memory model – may handle banked memory and/or simultaneous access banks • Multiple data pointers / address generators • Debugger may use some resources

8. Memory Usage • Use ‘const’ to put data into program memory • Alignment / padding issues • Typically NOT an issue, non-aligned access ok • Avoid dynamic memory allocation • Take extra space and processing time • Memory fragmentation a big issue • Use and reuse static buffers • Reduces variable passing overhead • Allows for smaller / faster code due to reduced indirections • Does bring back over write bugs if not done carefully • Use the appropriate variable type • Don’t use int and double for everything!! • Affects processing time as well as storage

9. char cX; cX++; 000A 900000 MOV DPTR,#cX 000D E0 MOVX A,@DPTR 000E 04 INC A 000F F0 MOVX @DPTR,A 6 Bytes of Flash 4 Instruction cycles int iX; iX++; 0000 900000 MOV DPTR,#iX 0003 E4 CLR A 0004 75F001 MOV B,#01H 0007 120000 LCALL ?C?IILDX 10 Bytes of Flash + subroutine overhead Many more than 4 instruction cycles with a LCALL Char vs. Int Increment on 8051

10. Code Structure • Count down instead of up • Saves a subtraction on all processors • DJNZ style instruction on some processors • Pointers vs. array notation • Generally better using pointers • Bit Shifting • May not always generate what you think • May or may not have barrel shifter hardware • May or may not have logical vs. arithmetic shifts

11. cX = cX << 3; 0006 33 RLC A 0007 33 RLC A 0008 33 RLC A 0009 54F8 ANL A,#0F8H Constants turn into seperate statements Variables turn into loops Both of these can be one instruction with a barrel shifter cA = 3; cX = cX << cA; 000B 900000 MOV DPTR,#cA 000E E0 MOVX A,@DPTR 000F FE MOV R6,A 0010 EF MOV A,R7 0011 A806 MOV R0,AR6 0013 08 INC R0 0014 8002 SJMP ?C0005 0016 ?C0004: 0016 C3 CLR C 0017 33 RLC A 0018 ?C0005 0018 D8FC DJNZ R0,?C0004 Shifting Example

12. More Code Structure • Actual parameters typically passed in registers if available • Keep function parameters to less than 3 • May also be passed on stack or special parameter area • May be more efficient to pass pointer to struct • Global variables • While generally frowned upon for most code can be very helpful here • Typically ends up being a direct access • Read assembly code for critical areas • Know which optimizations are present • Small compilers do not always have common optimizations • Inline, loop unrolling, loop invariant, pointer conversion

13. ucMode = g_Channels[uc_Channel].ucMode; 01DC 52FC mov A,[X-4] 01DE 5300 mov [__r1],A 01E0 5000 mov A,0 01E2 08 push A 01E3 5100 mov A,[__r1] 01E5 08 push A 01E6 5000 mov A,0 01E8 08 push A 01E9 5007 mov A,7 01EB 08 push A 01EC 7C0000 xcall __mul16 01EF 38FC add SP,-4 01F1 5F0000 mov [__r1],[__rX] 01F4 5F0000 mov [__r0],[__rY] 01F7 060000 add[__r1],<_g_Channels 01FA 0E0000 adc[__r0],>_g_Channels 01FD 3E00 mvi A,[__r1] 01FF 5403 mov [X+3],A ucMode = pChannel->ucMode; 01ED 5201 mov A,[X+1] 01EF 5300 mov [__r1],A 01F1 3E00 mvi A,[__r1] 01F3 5405 mov [X+5],A Does the same thing Saves 29 bytes of memory AND a call to a 16 bit multiplication routine! Pointer version will be at least 4x faster to execute as well, maybe 10x Most compilers not this bad – but you do find some! Indexed Array vs Pointer on M8C

14. Interrupts • Generally implemented as individual hardware vectors with a small amount of program memory at the location • ISR is what you get – no OS, no threads, no IST • Can use a flag with main loop to get IST behavior for less time critical code • Also very common to use interrupts to simulate threads • Interrupt itself take the place of the WaitFor_XXX or signal • Follows very naturally for hardware tasks and timers • Generally an “interrupt” statement provided

15. Interrupt Example static unsigned char g_TimerTriggered; void main() { ConfigureTimer0(); g_TimerTriggered = 0; GlobalEnableInterrupt(); while(1) { if(g_TimerTriggered) { g_TimerTriggered = 0; //Could also disable the timer interrupt here DoTimerTask(); //to avoid a race condition resetting g_TimerTriggered } //Can put optional sleep here, interrupts can wake up processor } } void Timer0ISR(void) interrupt 1 using 2 //Interrupt source 1, attached to vector 2 { g_TimerTriggered = 1; //Can put other small, quick work here }

16. Switch Statement Implementation • Switch statements can be implemented in various ways • Sequential compares • In line table look up for case block • Special function with look up table • Specific implementation can also vary based case clauses • Clean sequence (1, 2, 3, 4, 5) • Gaps in sequence (1, 10, 30, 255) • Ordering of sequence (5, 4, 1, 2, 3) • Knowing which method gets implemented critical to optimizing!

17. switch(cA) { case 0: cX = 4; break; case 1: cX = 10; break; case 2: cX = 30; break; default: cX = 0; break; } 0006 900000 MOV DPTR,#cA 0009 E0 MOVX A,@DPTR 000A FF MOV R7,A 000B EF MOV A,R7 000C 120000 LCALL ?C?CCASE 000F 0000 DW ?C0003 0011 00 DB 00H 0012 0000 DW ?C0002 0014 01 DB 01H 0015 0000 DW ?C0004 0017 02 DB 02H 0018 0000 DW 00H 001A 0000 DW ?C0005 001C ?C0002: 001C 900000 MOV DPTR,#cX 001F 7404 MOV A,#04H 0021 F0 MOVX @DPTR,A 0022 8015 SJMP ?C0006 ...More blocks follow for each case Switch Statement Example

18. Bit Variables • Some processors have special memory areas and op-codes for single bit storage • Saves overhead of masking operations • Some key from bit fields notation, some need keyword (frequently ‘bit’) • struct { unsigned int foo : 1; } flags; • unsigned int my_bit : 1; • bit my_bit;

19. Math Tricks • Floating point math VERY expensive on microcontrollers • No hardware support • Typically 32 bits for float, 64 bits for double • Support provided by a BIG library • Can use fixed point math in many cases • Basically the same as integer math, however move the decimal inside the integer. • Binary number is really: • 2^7 + 2^6 +… 2^2 + 2^1 + 2^0 • To make a fixed point number just adjust the exponents: • 2^6 + 2^5 + … 2^1 + 2^0 + 2^-1 :Note 2^-1 = 0.5 • Assume 8 bit value: Range = [0,255] • Assume one binary decimal point • XXXXXX.X • Range is now [0, 127.5] • All the internal math stays the same so long as only fixed point numbers with the same binary point location used together!

20. More Math Tricks • You may not have multiply and/or divide ops! • Decomposing operations can help X * 5 = X * 4 + X (X * 4) can become 2 shift left operations • Formulas should also be restructured for math available: Y=ax^2 + bx + c : 1 Pow or Mult, 2 Mult, 2 Add Y = x (ax + b) + c : 2 Mult, 2 Add • Lookup tables can be great for limited domain problems

21. Optimization • Step 0 – Before coding anything think about risk points and prototype unknowns!!! • Step 1 – Get it working!! • Fast but wrong is of no use to anyone • Optimization will typically reduce readability • Step 2 – Profile to know where to optimize • Usually only one or two routines are critical • You need to have specific performance metrics to target

22. Optimization • Step 3 – Let the tools do as much as they can • Turn off debugging! • Select the correct memory model • Select the correct optimization level • Step 4 – Do it manually • Read the generated code! Might be able to make a simple code or structure change. • Last – think about assembly coding

23. Summary • Microcontroller hardware is much simpler than most of us are used to • Be familiar with the hardware in your microcontroller • Be familiar with your compiler options and how it translates your code • For time or space critical code look at the assembly listing from time to time

24. Questions?
