  1. Chapter 13 Data Structures

  2. 13.1 Multidimensional Arrays • Multidimensional arrays have more than one dimension. • Java allows arrays to have any number of dimensions. • In practice, arrays rarely have more than two dimensions.

  3. Creating and Initializing a Multidimensional Array • The declaration of a multidimensional array will contain more than one set of square brackets: int[][] a; • It’s legal to put some or all of the brackets after the array name: int[] a[]; int a[][];

  4. Creating and Initializing a Multidimensional Array • The new keyword is used to allocate space for a multidimensional array: a = new int[5][10]; a will have 5 rows and 10 columns. • The declaration of a multidimensional array can be combined with the allocation of space for the array: int[][] a = new int[5][10];

  5. Creating and Initializing a Multidimensional Array • The array a can visualized as a table with 5 rows and 10 columns:

  6. Creating and Initializing a Multidimensional Array • Rules for assigning default values to array elements: • Numbers are set to zero. • boolean elements are set to false. • Elements of a reference type are set to null. • The array a will be full of zeros initially:

  7. Creating and Initializing a Multidimensional Array • If an array declaration contains an initializer, it’s not necessary to use new to allocate space for the array. • The initializer for a two-dimensional array looks like a series of one-dimensional array initializers: int[][] square = {{8, 3, 4}, {1, 5, 9}, {6, 7, 2}}; • The square array:

  8. Subscripting a Multidimensional Array • Selecting an element of a multidimensional array requires more than one subscript. • If a is a two-dimensional array, the element in row i, column j can be accessed by writing a[i][j] • Each subscript can be a literal, a variable, or any expression that produces an int value. • Java requires square brackets around each subscript: writing a[i,j] would be illegal.

  9. Processing the Elements in a Multidimensional Array • The elements of a multidimensional array can be accessed sequentially or in no particular order. • For a two-dimensional array, sequential access is normally done by visiting all elements in row 0, then all elements in row 1, and so on. • It’s also possible to visit elements column by column.

  10. Processing the Elements in a Multidimensional Array • Statements that sum the elements in an array a by visiting the elements row by row: int sum = 0; for (int row = 0; row < 3; row++) for (int col = 0; col < 3; col++) sum += a[row][col]; • Because the loops are nested, the row and col variables will take on all possible combinations of values.

  11. Processing the Elements in a Multidimensional Array • Order in which the elements of a will be visited: a[0][0] a[0][1] a[0][2] a[1][0] a[1][1] a[1][2] a[2][0] a[2][1] a[2][2] • Nested for loops are ideal for processing multidimensional arrays.

  12. How Multidimensional Arrays Are Stored • In Java, a two-dimensional array is a one-dimensional array whose elements are one-dimensional arrays. • Let a be the following array: int[][] a = new int[5][10]; • How a is stored:

  13. How Multidimensional Arrays Are Stored • Because a is really a one-dimensional array, it’s legal to write a.length to find the number of rows in a. • The expression a[0].length gives the number of columns. (The choice of 0 is arbitrary.) • The length of the next dimension—if a had more than two dimensions—would be a[0][0].length, and so on.

  14. How Multidimensional Arrays Are Stored • An improved version of the code that uses nested loops to sum the elements of a two-dimensional array: for (int row = 0; row < a.length; row++) for (int col = 0; col < a[0].length; col++) sum += a[row][col]; • The literals representing the number of rows and columns have been replaced by a.length and a[0].length.

  15. Using Two-Dimensional Arrays as Matrices • Multidimensional arrays play an important role in mathematical calculations, because a matrix can be stored in a two-dimensional array. • Two example matrices:

  16. Using Two-Dimensional Arrays as Matrices • A and B can be represented by two-dimensional arrays: double[][] a = new double[2][3]; double[][] b = new double[3][2]; • The subscripts will be off by 1, however, as they were for vectors. • For example, element aij of the matrix A will be stored in element a[i-1][j-1] of the array a.

  17. Using Two-Dimensional Arrays as Matrices • Common operations on matrices include addition, subtraction, and multiplication. • Formula for computing the product of A and B: • In general, A and B can be multiplied only if the number of columns in A matches the number of rows in B.

  18. Using Two-Dimensional Arrays as Matrices • Statements that multiply arrays named a and b, storing the result in a new array named c: double[][] c = new double[a.length][b[0].length]; for (int row = 0; row < a.length; row++) for (int col = 0; col < b[0].length; col++) { c[row][col] = 0.0; for (int i = 0; i < b.length; i++) c[row][col] += a[row][i] * b[i][col]; } The number of columns in a must be equal to the number of rows in b.

  19. Using Two-DimensionalArrays to Store Images • Two-dimensional arrays are often used to store images. • Images are sometimes stored in gray scale, rather than in color. • In a gray-scale image, each pixel is a shade of gray. • Typically there are 256 shades, represented by integers between 0 (black) and 255 (white).

  20. Using Two-DimensionalArrays to Store Images • A sample gray-scale image:

  21. Using Two-DimensionalArrays to Store Images • A two-dimensional array of integers that represents this image:

  22. Using Two-DimensionalArrays to Store Images • Ways to store a full-color image: • Three parallel two-dimensional arrays (storing the red, green, and blue components of the pixels) • A two-dimensional array of Color objects • A three-dimensional array

  23. Using Two-DimensionalArrays to Store Images • A three-dimensional array that could be used to store a full-color image: int[][][] colorImage = new int[numRows][numColumns][3]; • The pixel at position (row,column) would be represented by three array elements: colorImage[row][column][0] — red component colorImage[row][column][1] — green component colorImage[row][column][2] — blue component

  24. Using Two-DimensionalArrays to Store Images • Arrays often occupy large amounts of memory, especially when they have more than one dimension. • If numRows and numColumns are both 1000, the colorImage array will require 12,000,000 bytes of memory (1000  1000  3  4). • Arrays this large may exceed the limits of a Java interpreter.

  25. Using Two-DimensionalArrays to Store Images • Memory can often be conserved by switching to a smaller element type (short instead of int or float instead of double). • Switching from int to short will reduce the colorImage array’s memory requirements by a factor of 2.

  26. Using Two-DimensionalArrays to Store Images • Storing colors as byte values is possible, even though byte values range from –128 to 127 instead of 0 to 255. • By subtracting 128 from each color value when storing it into the array, color values can be scaled so that they become legal byte values. • Switching to byte will reduce the size of the colorImage array by a factor of 4.

  27. Ragged Arrays • Each row of a two-dimensional array is an array in its own right, so there’s no reason that the rows can’t have different lengths. • If they do, the array is said to be ragged. • A table containing distances between major American cities:

  28. Ragged Arrays • The table could be stored as a two-dimensional array with eight rows and eight columns, using a total of 64 elements. • However, it’s possible to save space by using a ragged array instead. • The elements on the diagonal aren’t used, so there’s no need to store them. • The values above the diagonal are symmetric to the values below the diagonal, so it’s not necessary to store both groups.

  29. Ragged Arrays • If a ragged array is initialized at the time the array is declared, the rows in the initializer can have different lengths. • A declaration that creates and initializes an array containing the distances between cities: int[][] distances = {null, {1110}, { 710, 1000}, { 790, 1830, 1090}, {2190, 3020, 2050, 1540}, { 850, 210, 810, 1610, 2790}, {2480, 3130, 2170, 1910, 390, 2930}, { 620, 450, 710, 1370, 2650, 240, 2840}};

  30. Ragged Arrays • There’s no need to store the first row of the table. • However, the array will be easier to work with if it has eight rows, corresponding to the eight cities. • Putting null at the beginning of the array indicates that row 0 has no elements.

  31. Ragged Arrays • The appearance of the distances array:

  32. Ragged Arrays • Creating a ragged array without initializing it is a little more difficult. • Steps needed to allocate space for the distances array without initializing it: • Create a one-dimensional array with eight elements, which will be arrays of integers. • Use a loop to allocate storage for each of the “inner” arrays.

  33. Ragged Arrays • Statements that perform both steps: int[][] distances = new int[8][]; for (int i = 1; i < distances.length; i++) distances[i] = new int[i]; • The value of distances[0] will be null by default. • The length of a row can be changed during program execution. • Each row is a separate one-dimensional array, so it can be replaced by another one-dimensional array of a different length.

  34. Using Multidimensional Arrays as Parameters and Results • Multidimensional arrays can be passed to methods and returned by methods. • A method that returns the sum of all the elements in the two-dimensional array a: public static int sumElements(int[][] a) { int total = 0; for (int row = 0; row < a.length; row++) for (int col = 0; col < a[row].length; col++) total += a[row][col]; return total; } • Using a[row].length as the limit on the inner loop allows the array to have rows of different lengths.

  35. Using Multidimensional Arrays as Parameters and Results • Methods that return multidimensional arrays are not uncommon in Java. • A method that returns an identity matrix of a specified rank: public static double[][] createIdentityMatrix(int rank) { double[][] matrix = new double[rank][rank]; for (int row = 0; row < rank; row++) for (int col = 0; col < rank; col++) if (row == col) matrix[row][col] = 1.0; return matrix; }

  36. Using Multidimensional Arrays as Parameters and Results • To save time, createIdentityMatrix assigns values only to elements on the main diagonal of matrix. • Other elements will have the value 0.0 by default. • A sample call: double[][] identityMatrix = createIdentityMatrix(3);

  37. Program: Finding the DistanceBetween Two Cities • The FindDistance program will display the distance between two cities: This program finds the distance between two cities. Supported cities: Atlanta, Boston, Chicago, Houston, Los Angeles, New York, San Francisco, Washington. Enter starting city: San Francisco Enter destination city: Atlanta The distance from San Francisco to Atlanta is 2480 miles. • The user will be asked to re-enter the name of a city if it doesn’t match any of the names supported by the program. • A normal two-dimensional array will be used to store the distances between cities. A ragged array could be used instead.

  38. FindDistance.java // Finds the distance between two major American cities import jpb.*; public class FindDistance { private static final String[] CITY_NAMES = {"Atlanta", "Boston", "Chicago", "Houston", "Los Angeles", "New York", "San Francisco", "Washington"}; private static final int[][] DISTANCES = {{ 0, 1110, 710, 790, 2190, 850, 2480, 620}, {1110, 0, 1000, 1830, 3020, 210, 3130, 450}, { 710, 1000, 0, 1090, 2050, 810, 2170, 710}, { 790, 1830, 1090, 0, 1540, 1610, 1910, 1370}, {2190, 3020, 2050, 1540, 0, 2790, 390, 2650}, { 850, 210, 810, 1610, 2790, 0, 2930, 240}, {2480, 3130, 2170, 1910, 390, 2930, 0, 2840}, { 620, 450, 710, 1370, 2650, 240, 2840, 0}};

  39. public static void main(String[] args) { // Display initial message, including a list of legal // cities System.out.println( "This program finds the distance between two cities.\n" + "Supported cities: Atlanta, Boston, Chicago, Houston,\n" + "Los Angeles, New York, San Francisco, Washington.\n"); // Call getCityCode to obtain codes for starting city // and destination city int start = getCityCode("Enter starting city: "); int destination = getCityCode("Enter destination city: "); // Display distance between chosen cities System.out.println( "\nThe distance from " + CITY_NAMES[start] + " to " + CITY_NAMES[destination] + " is " + DISTANCES[start][destination] + " miles."); }

  40. // Prompts user to enter city name; returns corresponding // city code. If city name is not recognized, allows user // to enter another name. private static int getCityCode(String prompt) { while (true) { SimpleIO.prompt(prompt); String cityName = SimpleIO.readLine().trim(); for (int i = 0; i < CITY_NAMES.length; i++) if (cityName.equalsIgnoreCase(CITY_NAMES[i])) return i; System.out.println("City name was not recognized."); } } }

  41. 13.2 The Vector Class • An array has a fixed number of elements. • The only way to enlarge an array is to allocate space for a new, larger array and then copy the values of the old array into the new one. • Vectors (instances of the Vector class) resemble arrays, except that they can grow (or perhaps shrink) during the execution of a program. • The Vector class belongs to the java.util package.

  42. Properties of Vectors • A vector stores references to objects. • There’s no limit on the number of objects that can be stored in a vector, nor is there any restriction on what type of objects can be stored. • The elements of a vector, like the elements of an array, are indexed from 0. • Key differences between vectors and arrays: • Vectors can grow or shrink as needed. • Vectors must contain objects.

  43. Properties of Vectors • Each vector has a capacity and a capacity increment. • The capacity is the number of elements the vector can store without requiring additional memory. • When a vector becomes full, Java automatically increases its capacity by the amount of the capacity increment. • The size of a vector—the number of items that it currently stores—is always less than or equal to its capacity.

  44. Properties of Vectors • A vector with a capacity of five and a size of three: Two elements of the vector are currently not in use.

  45. Creating a Vector • The Vector class has three constructors. • One of them allows the initial capacity of the vector to be specified: Vector v = new Vector(5); • The capacity of v is five and its size is zero:

  46. Storing Data into a Vector • The Vector class provides methods that add an object to a vector in one of three ways: • Add the object after all objects currently stored in the vector (addElement). • Insert the object somewhere in the middle of the vector (insertElementAt). • Replace an existing object with the new one (setElementAt). • All three methods have a parameter of type Object, representing the object to be stored.

  47. Storing Data into a Vector • Examples of calling addElement: v.addElement("a"); v.addElement("b"); v.addElement("c");

  48. Storing Data into a Vector • A call of insertElementAt: v.insertElementAt("d", 1); • insertElementAt throws an ArrayIndexOutOfBoundsException if the second argument isn’t between 0 and the vector’s size.

  49. Storing Data into a Vector • A call of setElementAt: v.setElementAt("e", 2); • ArrayIndexOutOfBoundsException is thrown if the second argument to setElementAt is out of range.

  50. Storing Data into a Vector • In a call of insertElementAt, the index at which the new element is to be inserted must be less than or equal to the vector’s current size. • In a call of setElementAt, the index at which the new element is to be stored must be less than the vector’s current size.
