Fault Detection

1. Fault Detection Sathish S. Vadhiyar Source/Credits: From Referenced Papers

2. Introduction • Fine Grain Cycle Sharing (FGCS) • Host computers allow guest jobs to utilize CPU cycles • Availability of host computers vary • Guest jobs may incur resource failures • Need to predict availability of host computers • A scheduling system can allocate guest jobs based on the availability of host computers

3. Kinds of Non Availabilities • FRC (Failures Caused by Resource Contention) • A guest job may significantly impact host processes • Hence a guest job can be removed • FRR (Failures Caused by Resource Revocation) • A machine owner suspends resource contribution without notice • Hardware-software failures occur

4. Resource Failure Prediction • A multi-state failure model and application of a semi-Markov Process (SMP) to predict the temporal reliability • Predicting probability that no resource failure will occur on a machine in a future time window • Observing host resource usage values in a time window; calculating parameters of SMP based on host resource usage values

5. Multi-state resource failure model • FRR – 2 states • A machine is either available or unavailable • FRC • Failures when host processes incur noticeable slowdown due to contention from guest processes • A host processor can first decrease the priority of guest processes; If this does not help, the guest process is terminated • Measured host resource usage as indicators of noticeable slowdown

6. Initial Experiments • To study relations between host resource usage and FRC - Experiments conducted to simulate resource contentions between a guest process and host processes • Host-group – an aggregated set of host processes with various resource usages • Slowdown of host group – reduction of its CPU utilization due to contending guest process • Host programs are run with their isolated CPU usage between 10% and 100% • Guest process – a CPU bound program

7. Experiments on CPU contention • Also measured reduction rate of host CPU usage for a host-group • Experiments repeated with different host groups with host priority 0, and guest priority 0 and 19 (renice) • Measured reduction rate plotted as function of isolated host CPU usage, LH • Found 2 thresholds for LH • Th1 – highest value of LH when guest process needs to be reniced to keep reduction rate below 5% • Th2 – highest value of LH when guest process needs to be suspended to keep reduction rate below 5%

8. State model for LRC • 3 states • S1 - When LH < Th1; ignore resource contention due to guest processes; slowdown already less than 5% • S2 - When Th1 < LH < Th2; renice guest processes for slowdown to be < 5% • S3 - When LH > Th2; terminate guest process

9. Experiments on CPU and Memory Contention • When memory trashing occurs • Total memory of guest and host processes exceed available memory size • Experiments were conducted to verify memory trashing does not depend on guest priority • S4 – for failure due to memory trashing

10. Multi-State Failure Model • Proposed prediction algorithm is to predict the probability that a machine will never transfer to S3, S4, or S5 within a future time window • Transitions • Between S1, S2, S3 – decided by measured host CPU usage • To S4 – when memory is limited

11. Semi-Markov Process Model (SMP) • Applicable when next transition depends only on • Current state • How long the system at the current state • Transition probabilities depend on amount of time elapsed since last change in state • SMP is defined by a 3-tuple • S – finite set of states • Q – state transition matrix • H – holding time mass function matrix

12. SMP (Contd…) • The most important statistics of SMP - Interval transition probabilities, P • To calculate P • Continuous time SMP is expensive • Hence the work develops a discrete time SMP model

13. SMP for Resource Availability • TR – probability of never transferring to S3, S4 or S5 within an arbitrary time window, W • Sinit – initial system state • W – Winit + T • Q and H calculated based on statistics from history logs due to monitoring host resource usage

14. SMP for Resource Availability • Pi,j(m) = Pi,j(Winit, Winit+m) • P1i,k(l) – interval transition probabilities for a one-step transition • d – time unit of a discretization interval • Q and H calculated based on statistics from history logs due to monitoring host resource usage

15. System Design and Implementation • Client requests job submission • Client’s job scheduler queries the gateways on available machines for temporal availabilities • Chooses a machine and spawns a guest job • During job execution, monitor detects state transition and notifies gateway • Gateway renices or kills the guest processes accordingly • Resource monitor uses simple cpu commands like `top’ to calculate cpu usages

16. Computation in Solving SMP • Matrix sparsity in SMP is exploited to reduce computations • The sparse matrix is constructed based on 2 facts: • It takes a finite amount of time to transition from one state to another • S3, S4, S5 are unrecoverable failure states

17. Prediction Accuracy TR gets close to 0 for large time windows

18. Appropriate Training Size

19. Comparison with Linear Regression Techniques

20. Injecting Noises

21. References • Resource Failure Prediction in Fine-Grained Cycle Sharing Systems. X. Ren, S. Lee, R. Eigenmann, S. Bagchi. HPDC 2006.
