Angular Motion. The radian was defined for circular motion. There are 2 p radians in a complete circle. The distance around a circle is s = r q. Angle vs. Position. Dq. q. r. The angular displacement is Dq. Angular Velocity. Velocity has an angular equivalent. Linear velocity ( v )

Télécharger la présentation
## Angular Motion

**An Image/Link below is provided (as is) to download presentation**
Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.
Content is provided to you AS IS for your information and personal use only.
Download presentation by click this link.
While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.
During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

**The radian was defined for circular motion.**There are 2p radians in a complete circle. The distance around a circle is s = rq. Angle vs. Position Dq q r The angular displacement is Dq**Angular Velocity**• Velocity has an angular equivalent. • Linear velocity (v) • Angular velocity (w) • They are related, since the displacement is related to the angle.**Angular Acceleration**• In uniform circular motion there is a constant radial acceleration. • ar = v2 / r = rw2 • If the angular velocity changes there is acceleration tangent to the circle as well as radially. The angular acceleration is a**Kinematic equations with constant linear acceleration were**defined. vav = ½ (v0 + v) v = v0 + at x = x0 + v0t + ½at2 v2 = v02 + 2a(x - x0 ) Kinematic equations with constant angular acceleration are similar. wav = ½ (w0 + w) w = w0 + at q = q0 + w0t + ½at2 w2 = w02 + 2a(q - q0 ) Rotational Motion**The Effect of Torque**• A tangential force on a mass creates an acceleration. • Tangential force: Ft = mat • Tangential acceleration: at = ra • The force is associated with a torque. • Torque: t = rFt Ft r m**Rotational Law of Action**• The force law can be combined with rotational motion. • Torque: t = rFt = r mat = m r2a • If torque replaces force, and angular acceleration replaces acceleration, this looks like the law of action.**Rotational Inertia**• The term mr2 takes the place of mass in the rotational law of action. • This is called the rotational inertia or moment of inertia. • The symbol is I • For a single mass at a distance: I = mr2. next
