Understanding Quality Inspection Systems in Industry

This lecture covers four key quality inspection systems used in the industry: the 4-point system, the 10-point system, the Clock-wise garment inspection system, and Acceptance Sampling. The 4-point system assesses fabric defects based on size and significance, while the 10-point system is outdated. Acceptance Sampling, first introduced during WWII, is an efficient method but poses risks of type-I and type-II errors. Key concepts such as Acceptance Quality Level (AQL), Lot Tolerance Percent Defectives (LTPD), and OC Curve are explained along with inspection level classifications.

chanel
Télécharger la présentation

Understanding Quality Inspection Systems in Industry

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Lecture 26 Quality inspection systems

  2. Quality Inspection Systems • There are four systems which are used in industry • 4-point system • 10 point system • Clock-wise garment inspection system • Acceptance Sampling

  3. 4-point system • This is a fabric inspection method for different type of faults. This is issued by The American Society for Testing and Materials with reference to the designation:(ASTM D5430-93) • Faults are scored with penalty points of 1, 2, 3 and 4 according to their size and significance.

  4. 4-point system • We can also assess fabric fault/defect rates against other systems as required by the client, for example jersey fabrics are often expressed in meters per fault/defect.

  5. 10-point system • This is an old system and not being used now a days

  6. Clock-wise garment inspection system • See last page (Photocopy is attached)

  7. Acceptance sampling • This a different technique. • This technique was first time used in 2nd world war • This is a time saving technique • But in this technique there is a possibility of type-I error (Producer’s risk) and type-II error (Consumer’s risk)

  8. Acceptance Sampling Plans … • Single sampling plans • Double sampling plans • Multiple sampling plans • Sequential sampling plans • Skip lot sampling plans

  9. Important definitions … • Acceptance quality level (AQL) • Lot tolerance percent defectives (LTPD) • OC Curve (Operating Characteristic) • Average outgoing quality (AOQ)

  10. OC Curve • OC curve means operating characteristic curve • X-Axis : % non-conformity • Y-Axis : Probability of acceptance

  11. Inspection Levels… • Special Inspection Levels • There are 4 levels (S1, S2, S3, S4) • They are used for small sample sizes • General Inspection Levels • There are 3 levels (I, II, III)
