CAPACITOR READING

DESCRIPTION

CAPACITOR READING. ELECTROLYTIC CAPACITORS. Negative Lead. Indicated Value ( Capacitance / voltage ). 2 Terminal Lead. Positive Lead. ALL UNITS IN MICRO FARAD (µF). MYLAR CAPACITORS ( Plastic ). 4 7 3 4 7 000 47000 pico Farad is equal to 0.047 micro Farad J = ±5%

1 / 9

Télécharger la présentation

CAPACITOR READING

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. CAPACITOR READING

  2. ELECTROLYTIC CAPACITORS Negative Lead IndicatedValue (Capacitance / voltage) 2 Terminal Lead Positive Lead ALL UNITS IN MICRO FARAD (µF)

  3. MYLAR CAPACITORS (Plastic)

  4. 4 7 3 4 7 000 47000 pico Farad isequalto 0.047 micro Farad J = ±5% Thereforethecapacitanceis0.047micro Farad (µF) ±5% tolerance

  5. Thevalueis0.1µF ±10%tolerance. 0.1K 50V

  6. CERAMIC CAPACITORS 1 5 4 1 5 0000 –in pico Farad 150000 pFisequalto 0.15 µF – capacitor value

  7. 1K 1K = 1000 pico Farad Where: K = 1000 33 Capacitor value 33pF
