  1. Software Testing:A Selection of Papers by Elaine Weyuker Peter Greenwood for EEE 599

  2. Elaine Weyuker • PhD (CS) Rutgers U ‘77 • Software Testing Researcher at AT&T Bell Labs, Murray Hill, NJ • CS Professor Courant Institute of NYU • 30+ papers, primarily on Software Testing EEE 599 - Weyuker Presentation

  3. The Papers • Axiomatizing Software Test Data Adequacy (TSE Dec 86) • The Automatic Generation of Load Test Suites and the Assessment of the Resulting Software (TSE Sep 95, with Avitzer) • Reliability Testing of Rule-Based Systems (Software Jun 96, with Avritzer and Ros) EEE 599 - Weyuker Presentation

  4. Goal of Presentation • highlight some of Weyuker’s prolific work in software testing • contrast the general and theoretical character of her early work with the specific and practical nature of her current work EEE 599 - Weyuker Presentation

  5. Axiomizing Software Test Data Adequacy (Dec 86) • How much testing is enough to determine if a program is acceptable? • very important question • relatively little research activity (1986) • no industry standards • test until testing time expired • test until all cases in current test set pass EEE 599 - Weyuker Presentation

  6. When Should Testing Stop? • Terminate when an adequacy criterion is met • a measure of how well the testing process has been performed • relates a test set to the program, the specification, or both • could relate a test set to the program’s operational profile EEE 599 - Weyuker Presentation

  7. Constraints of this Approach • deals only with dynamic testing (running the program on test cases) • does not involve any static testing (analysis of code, structure, etc.) EEE 599 - Weyuker Presentation

  8. Constraints (con’t) • Weyuker’s paper deals only with program-based criteria • ignores specifications • most adequacy criteria are of this type • easier to automate EEE 599 - Weyuker Presentation

  9. Weyuker on Testing “The purpose of testing is to uncover errors, not to certify correctness.” EEE 599 - Weyuker Presentation

  10. The Axioms (1 & 2) • Axiom 1: (Applicability) For every program, there exists a finite adequate test set. • Axiom 2: (Nonexhaustive Applicability) There is a program P and a test set T such that P is adequately tested by T, and T is not an exhaustive test set. EEE 599 - Weyuker Presentation

  11. Axioms 3 & 4 • Axiom 3: (Monotonicity) If T is adequate for P, and T is a subset of T’, then T’ is adequate for P. • Axiom 4: (Inadequate Empty Set) The empty set is not adequate for any program. EEE 599 - Weyuker Presentation

  12. Axioms 5 & 6 • Axiom 5: (Anti-extensionality) There are programs P and Q such that P is equivalent to Q, T is adequate for P, but T is not adequate for Q. • Axiom 6: (General Multiple Change) There are programs P and Q which are the same shape, and a test set T such that T is adequate for P, but T is not adequate for Q. EEE 599 - Weyuker Presentation

  13. Axiom 7 • Axiom 7: (Anti-decomposition) There exists a program P and a component Q such that T is adequate for P, T’ is the set of vectors of values that variables can assume on entrance to Q for some t of T, and T’ is not adequate for Q. EEE 599 - Weyuker Presentation

  14. Axiom 8 • Axiom 8: (Anti-composition) There exist programs P and Q such that T is adequate for P and P(T) is adequate for Q, but P is not adequate for P;Q. EEE 599 - Weyuker Presentation

  15. Summary of Axiomatizing • axioms are applied to 5 adequacy criteria • path, branch, statement, mutations, modified size • path, branch, statement fail application and antidecompositon • branch and statement also fail anticomposition EEE 599 - Weyuker Presentation

  16. Summary of Axiomatizing EEE 599 - Weyuker Presentation

  17. Criticism • Zweben & Gourlay, On the Adequacy of Weyuker’s Test Data Adequacy Axioms (IEEE TSE Apr 89) • “The properties proposed by Weyuker are neither fundamental enough nor precise enough to serve as a useful formal system for discussing adequacy or comparing criteria” EEE 599 - Weyuker Presentation

  18. More Criticism • Professor Norman Fenton, keynote address to 2nd QUALMS User Group Meeting, South Bank University, Jul 92 • “Elaine Weyuker … has presented a list of axioms … Measurement Theory reveals that some of these axioms are contradictory.” EEE 599 - Weyuker Presentation

  19. Dr. Weyuker’s Current Work EEE 599 - Weyuker Presentation

  20. Automatic Generation of Load Test Suites (Sep 95) • develops 3 algorithms for automatic test case generation • applies them to 5 real industrial software systems • assess the results EEE 599 - Weyuker Presentation

  21. Failure Types • Hard failure • complete loss of traffic ( ie cable break, power failure, router failure) • Soft failure • degraded performance (ie activity burst) • important that this does not occur • telecoms designed with excess capacity • avoid permanent soft failure EEE 599 - Weyuker Presentation

  22. Goals • a smoothly degrading system • graceful recovery EEE 599 - Weyuker Presentation

  23. Load Testing Strategies • system functionality has already been tested • assess system performance under a known load • black-box oriented • based on system operational profile EEE 599 - Weyuker Presentation

  24. Typical Telecom Operational Profile • number of different types of call • average service demands and probability distribution of each call type • average external arrival rate • routing probabilities for each node • this information is usually readily available EEE 599 - Weyuker Presentation

  25. Purpose of Algorithms • tests resource allocation mechanisms associated with software systems • system behavior under load is not measured by functionality testing • each variable vector is a distinct system state EEE 599 - Weyuker Presentation

  26. Basis of Algorithms • too many states to exhaustively test • calculate probability of system being in each state (from operational profile) • heuristically determine some threshold  • generate a test case for those states where P(S) >  EEE 599 - Weyuker Presentation

  27. The Algorithms • Deterministic State Testing (DST) • generate a test case for each state S where P(S) >  • DST with State Transition Checking (TDST) • as for DST, but also generate test cases for every S’ reachable from S EEE 599 - Weyuker Presentation

  28. The Algorithms (con’t) • DST with Length N Cycles (CDST) • as for DST, but also generate test cases for every S’ within a cycle of length N from S with a probability >  EEE 599 - Weyuker Presentation

  29. Target Systems • Project 1: telephone call rerouter • Project 2: 800 number call traffic monitor • Project 3: routing automator • Project 4: transaction processing system • Project 5: network interface software EEE 599 - Weyuker Presentation

  30. Testing Results • automated test generation routines were developed for all five projects • automated test results were presented for projects 1 & 2 EEE 599 - Weyuker Presentation

  31. Project 1 Results • telephone call rerouter software • test results accurately predicted system performance • testing revealed a serious architectural problem EEE 599 - Weyuker Presentation

  32. Project 2 Results • 800 number call traffic monitor • led to better requirements analysis • used automated test case generation exclusively, replacing hand-crafting • more test cases with more variety • uncovered four potentially severe faults • minimal additional cost EEE 599 - Weyuker Presentation

  33. Reliability Testing of Rule-Based Systems (Sep 96) • applies same automatic test case generation algorithm to an industrial network surveillance system • system was a reimplementation, so a large body of operational data was available from the original system • system designed to run 24 hours/day; 365 days/year EEE 599 - Weyuker Presentation

  34. Approach • system has very large state space • 355 days of operational data from 93 switches were used to identify 857 states entered • 0.999 coverage required testing 843 states EEE 599 - Weyuker Presentation

  35. State Testing Requirements EEE 599 - Weyuker Presentation

  36. Findings • historical data is useful for selecting test cases based on state probabilities • selection algorithm must consider • reliability requirements • size of the (limited) state space • comprehensiveness of individual test cases EEE 599 - Weyuker Presentation

  37. change of focus from theory to application extension from telecom to general application accomplished, respected, and prolific researcher in software testing and reliability Summary EEE 599 - Weyuker Presentation
