## Longitudinal Standing Waves and Complex Sound Waves

**An Image/Link below is provided (as is) to download presentation**
Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.
Content is provided to you AS IS for your information and personal use only.
Download presentation by click this link.
While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.
During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

**Longitudinal Standing Waves and Complex Sound Waves**17.6 and 17.7**17.6 Longitudinal Standing Waves**• Just like stringed instruments rely on standing transverse waves on strings • Wind instruments rely on standing longitudinal sound waves in tubes • The waves reflect off the open ends of tubes • One difference at the ends are antinodes instead of nodes**Formula for Tube Open at Both Ends**• Distance between antinodes = ½ • Tube must be integer number of ½ • L = n(1/2 n) or n = 2 L/n • fn = v / n**Example**• What is the lowest frequency playable by a flute that is 0.60 m long if that air is 20 °C. • f = 193.3 Hz**Tube with One Closed End**• Node at the closed end • Antinode at the open end • At fundamental frequency L = ¼ • The 2nd harmonic adds one more node or ½ • Thus the lengths are odd integer multiples of ¼ **17.7 Complex Sound Waves**• In reality most musical instruments not only produce the one fundamental frequency • Most instruments produce harmonics also • The wave we hear is the sum of the fundamental and the harmonics • The varying amplitudes of the harmonics give each instrument its timbre**Practice Problems**• Try blowing your way through these problems • 506 CQ 14 – 15, P 34 – 38 • Total of 7 Problems
