Addressing Modes

1. Addressing Modes

2. Addressing Modes Implicit part of CPU12 instructions 16-bit effective address Each addressing mode except inherent mode generates a which is used during the memory reference portion of the instruction. Effective address computations do not require extra execution cycles.

3. Addressing Modes Inherent (INH) Immediate (IMM) Direct (DIR) Extended (EXT) Relative (REL) Indexed (IDX,IDX1,IDX2) Indexed-indirect ([D,IDX],[IDX2])

4. Inherent Addressing ModeINH Either, the instruction has no operand Ex: NOP A7 O Or, all operands are in internal CPU registers Ex: INX 08 O (operand is X register)

5. Immediate Addressing ModeIMM Operands are included in the instruction stream and are fetched into the instruction queue one 16-bit word at a time during normal program fetch cycles. LDAA #$55 86 55 P LDAA #55 86 37 P LDX #$1234 CE 12 34 PO LDY #$67 CD 00 67 PO

6. Direct Addressing ModeDIR Also known as zero-page addressing as it is used to access operands in the address range $0000-$00FF. LDAA $55 96 55 rPf LDY $67 DD 67 RPf

7. Extended Addressing ModeEXT The full 16-bit address of the memory location to be operated on is provided in the instruction. LDAA $F03B B6 F0 3B rPO LDY $6776 FD 67 76 RPO

8. Relative Addressing ModeREL Relative to PC. Used only by branch instructions. If the offset is 0, the CPU executes the instruction immediately following the branch instruction, regardless of the test involved.

9. Relative Addressing ModeREL Short branch instructions consist of an 8-bit opcode and a signed 8-bit offset contained in the byte that follows the opcode The numeric range of offset values is [$80,$7F], i.e. [–128,127]. BCC L1 24 34 PPP/P L1 is a label in [PC-128,PC+127] range.

10. Relative Addressing ModeREL Long branch instructions consist of an 8-bit prebyte, an 8-bit opcode, and a signed 16-bit offset contained in the two bytes that follow the opcode. The numeric range of offset values is [$8000,$7FFF], i.e. [–32768,32767]. LBCC L1 18 24 25 55 OPPP/OPO L1 is a label in [PC–32768,PC+32767] range.

11. Relative Addressing ModeREL Loop primitive instructions consist of an 8-bit opcode, an accumulator or a register and a signed 9-bit offset. The numeric range of offset values is [$100, $0FF], i.e. [–256,255] DBEQ B, L1 04 01 25 PPP/PPO L1 is a label in [PC,PC+255] range DBEQ B, L1 04 11 05 PPP/PPO L1 is a label in [PC-256,PC) range

12. Relative Addressing ModeREL Bit-condition branches test whether bits in a memory byte are in a specific state. The numeric range of offset values is [$80, $7F], i.e. [–128,127] BRCLR $35,#$25,L1 4F 35 25 21 rPPP L1 is a label in [PC-128,PC+127] range

13. Indexed Addressing ModeIDX, IDX1, IDX2 Offset is added to the base index register (X, Y, SP, or PC) to form the effective address of the memory location that will be affected by the instruction. A postbyte is used to do the following tasks: Specify which index register is used Determine whether a value in an accumulator (A, B, or D) is used as an offset Enable automatic pre- or post-increment or pre- or post-decrement Specify size of increment or decrement Specify use of 5-, 9-, or 16-bit signed offsets Automatic pre- or post-increment or pre- or post-decrement by –8 to +8

14. 5-bit Constant Offset Indexed AddressingIDX The numeric range is [–16,+15] Syntax: <opcode> xb xb=rr0nnnnn rr=00 for X, 01 for Y, 10 for SP, 11 for PC Assume (X)=$1000, (Y)=$2000 LDAA 0,X A6 00 rPf STAB –8,Y 6B 58 Pw After execution: (X)=$1000, $1000=X ? (A) (Y)=$2000, (B) ? Y-8=$1FF8

15. 9-bit Constant Offset Indexed AddressingIDX1 The numeric range is [–256,+255] Syntax: <opcode> xb ff xb=111rr00s ff: offset without sign bit. Assume (X)=$1000, (Y)=$2000 LDAA $FF,X A6 E0 FF rPO STAB –20,Y 6B E9 EC PwO After execution: (X)=$1000, $10FF=X+$FF ? (A) (Y)=$2000, (B) ? Y-$14=$1FEC

16. 16-bit Constant Offset Indexed AddressingIDX2 Whole 64Kbyte address space Syntax: <opcode> xb ee ff xb=111rr010 ee ff: offset Assume (X)=$1000 LDAA $FFFF,X A6 E2 FF FF frPP After execution: (X)=$1000, $0FFF=X+$FFFF ? (A)

17. Auto Pre/Post Decrement /Increment Indexed AddressingIDX The index register can be incremented or decremented by an integer value either before or after indexing takes place. incremented by any integer value [ 1,8], i.e. [0000,0111] decremented by any integer value [–8 , –1], i.e. [1000,1111] Syntax: <opcode> xb xb=rr1pnnnn p:0 (pre) Assume (X)=$1000 LDAA 3,X+ A6 32 rPf After execution: $1000? (A), (X)=$1003

18. Accumulator Offset Indexed AddressingIDX The offset is in one of the accumulators (A, B, or D). Syntax: <opcode> xb xb=111rr1aa aa:00 for A, 01 for B, 10 for D. Assume (X)=$1000 LDAA B,X A6 E5 rPf After execution: (X)=$1000, $1000+(B)? (A),

19. Indexed-Indirect Addressing Modes[D,IDX],[IDX2] Each index register is assumed to be a pointer to a table of pointers or addresses 16-bit offsets.

20. 16-bit Constant Offset Indexed Indirect Addressing[IDX2] Whole 64Kbyte address space Syntax: <opcode> xb ee ff xb=111rr011 ee ff: offset Assume (X)=$1000 (the base address of a table of pointers). Assume X+10:X+11= $2000 LDAA [10,X] A6 E3 00 10 fIPrPf Execution Add the value 10 to the value in X to form the address $100A. Fetch an address pointer ($2000) from memory at $100A. Read the value in $2000 is read and load into A After execution: (X)=$1000, ($100A:$100B)=$2000 ? (A)

21. Accumulator D Indirect Indexed Addressing[D, IDX] The offset is in one of the accumulators (A, B, or D). Syntax: <opcode> xb xb=111rr011 Assume (X)=$1000 and D=0002 and $1002:$1003=$1015 and $1015=$25 LDAA [D,X] A6 E3 fIfrPf Execution Add D (i.e. 2) to the value in X to form the address $1002. Fetch an address pointer ($1015) from memory at $1002. Read the value in $1015 and load into A After execution: (X)=$1000, ($1000+D)=$1015 ? (A)
