Presentation Transcript

  1. 43 feet stage 15 feet 15 feet 19 feet 12 feet 12 feet 36 feet 43 feet sub woofe TRC121K(120 x50 assym) SR7(120x50assym) sub woofer Mono mix Right channel Left channel 68 feet Seating area within dotted line 44 feet Sound booth Wood stud and drywall - cement slab w/carpet and 250 fabric covered chairs

  2. Speaker placement front of house speakers Closed circuit TV camera 21.5 feet 16 feet 44 feet sub Sound booth

  3. Speaker placement Sloped ceiling Sloped ceiling Mid/high Mid/high Center mono a 16 ft. classroom Chair storage room subwoofer
