Current and Voltage

DESCRIPTION

Current and Voltage. Current. Flow rate of electricity Current flows from + to – Measured in Amps – 1 Amp = 1 Coulomb per second Actually electrons flow in the opposite direction Many electrons make up one coulomb of charge

1 / 3

Télécharger la présentation

Current and Voltage

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Current and Voltage

  2. Current Flow rate of electricity Current flows from + to – Measured in Amps – 1 Amp = 1 Coulomb per second Actually electrons flow in the opposite direction Many electrons make up one coulomb of charge All the current flow rate around a circuit is the same. (Current in branches adds up to equal the total current (exception! = capacitors)

  3. 1 Volt is 1 Joule per Coulomb It is the energy transfer to or from a coulomb of charge Electro-motive force (EMF) The work done on (energy transferred to) a coulomb of charge by a battery or power supply Voltage Potential Difference The energy level difference between two places P = VI Voltage and current The greater the potential difference between two places the higher the current. The ratio voltage:current is resistance ( V = IR )
