This Near Miss Safety Report is intended to share crucial safety information without assigning blame or disciplinary action. On April 29, 2006, during hose testing at Station 20, a failure occurred when the pressure was raised to 300 psi. The subsequent investigation revealed damage to a 30-degree elbow and other apparatus components. Recommendations from this report emphasize the importance of proper testing procedures, the use of personal protective equipment (PPE), and the need for caution when handling pressurized hoses.

#training division #training division ppt #powerpoint #presentation
TRAINING DIVISION - slide 1
01 / 24TRAINING DIVISION
1 / 17

Télécharger la présentation

TRAINING DIVISION
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. TRAINING DIVISION NEAR MISS SAFETY REPORT

  2. The purpose of this Near Miss Safety Report is not to place blame, fault or be used for any disciplinary action. The sole purpose of this Near Miss Safety Report is to pass information on to all personnel to insure safety.

  3. HOSE TEST ACCIDENT:Station 20, App 48April 29, 2006

  4. Synopsis: • Engine 20 had connected 2-100 foot lengths and 1-50 foot length of 5 inch hose. • Connected to the 4 ½ inch discharge. • Line was charged and the air was bleed out. • Pressure was raised to 300 psi.

  5. View of Apparatus After the Accident • Apparatus Bay • 2 100 foot lengths of LDH • 1 50 foot length of LDH • Damaged 30 degree elbow and coupling

  6. Synopsis (continued): • The Engineer had gated the discharge down. • The Captain and Firefighter were checking the couplings. • The Engineer was at the rear of the engine watching the evolution. • The entire crew then heard what sounded like a hose failure.

  7. Damaged Hose:

  8. Synopsis (continued): • There appeared to be a hose failure at the discharge. • The Engineer shut the rig down. • The crew then observed the severity of the damage.

  9. Right Side LDH Discharge • Remains of a 30 Degree Elbow • Part of the discharge pump access panel was removed by the shop

  10. Both pieces sitting on the Captain side running board

  11. Fractured 30 Degree elbow • Both pieces set together

  12. 30 Degree elbow • Fractured pieces put back together • Notice the missing pieces • Threaded hole is for the discharge drain

  13. Captains side • Bent chrome

  14. Captains side • Bent light pole • Light pole is bent over and in toward cab • Hole in diamond plate was a part removed by the shop, not related to near miss

  15. Captains side • Bent diamond plate

  16. Captains side • Enough force was applied to the rear of the cab that the Firefighters door will not close all the way. • The latch and lock mechanism on the Firefighters door operate normally

  17. TRAINING DIVISION: RECOMENDATIONS

  18. Excerpts from Instruction 55: • 5 inch hose shall be tested at 300 psi for five minutes. • 5 inch hose can be tested with the Hydrostatic Test Pump or an Engine.

  19. Excerpts from Instruction 55: • Provide a continuous flow of water from a reel line. • When using an engine use a flow-limiting device, orifice plate.

  20. When Using an Engine to Test Hose: • Connect one or more lengths of 2 ½ inch hose to a discharge with an orifice plate installed, then connect 5 inch hose with a 2½ by 4½ inch double female adaptor. • Connect no more than 500 feet of LDH hose to the 2 ½ hose.

  21. SEFETY RECOMMENDATIONS: • Always wear PPE when operating hose lines. • When testing hose, use discharges away from the pump panel.

  22. Treat hoses and couplings under test pressure as dangerous – THEY ARE! Never straddle the hose. The pump operator shall be ready to shut the pump down at any moment. SEFETY RECOMMENDATIONS:
