  1. Union Pacific Wind Program October 27, 2009

  2. Farm String Nacelle Hub Blades Tower Base section Tower mid Section Tower upper section DtA = Down Tower Assembly Wind Energy Supply Chain 1 Port or Plant 2 4 3 UPDS Rail DC Rail 6 5 PAD Carriers

  3. Wind – Rail Clearances 14’ 2” + width & Turns

  4. UPDS WIND Distribution Centers • Current Operating DC’s • --Abilene, TX • -- Boardman, OR • -- Manly, IA • --Carr, CO • -- Tucson, AZ • -- Devils Lake, ND • -- Liberal, KS • -- Mojave, CA • -- Colton, CA • Pre-qualified DC Sites • --Bloomington, IL • -- Peoria, IL • -- Indio, CA • -- Kanopolis, KS • -- Butte, MT • -- El Reno, OK • -- Arlington, OR • -- Miller, SD • -- Milford, UT • -- Egbert, WY • -- Sidney, NE • -- Montevideo, MN • -- Milwaukee, WI Top States in Wind Production States with significant growth potential

  5. Manly, Iowa

  6. Short Line - Universal Tower Fixtures

  7. Short Line – Universal Blade Fixtures
