Mobile tagging utilizes two-dimensional barcodes to record data information efficiently within constrained spaces. Unlike one-dimensional codes, which have limited data capacity and description, mobile tagging addresses these limitations through advanced geometric designs and image recognition. This method offers greater data density, enabling more information storage and easier scanning. Examples include QR codes and Datamatrix. Learn how to use mobile tagging with powerful apps and modern scanning devices to enhance your information retrieval capabilities.

1 / 17

Télécharger la présentation

Mobile Tagging

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

Playing audio...

  1. Mobile Tagging • Member of Group: HughtonHylton • Jane Lee • Chengzhi Jia • Chuan Yu • Jiajun Xi Date: October 14th, 2013

  2. Introduction Mobile Tagging is used in a particular geometry according to certain rules in the plane (two-dimensional direction) distribution of black and white graphic recording data symbol information

  3. Why use mobile tagging Needs for storage more information in smaller spaces Disadvantages of one-dimensional code • Limited max data length • No product description • Low data density Ensure local damaged barcode can still correct identification Easy scanning

  4. Why use mobile tagging

  5. Varieties of Mobile tagging

  6. Varieties of Mobile tagging Two compositions of mobile tagging • Develop two-dimensional barcode based on one-dimensional barcode • Use of image recognition principle, new geometric and structural to design two-dimensional barcodes Stacked Matrix

  7. Varieties of Mobile tagging Stacked mobile tagging • Coding principle (bars) Want know more? Click me! • representative stacked two-dimensional barcode PDF417, Code16K, Supercode, Code49, etc.

  8. Varieties of Mobile tagging Matrix mobile tagging • Coding principle (dot combinations) Want know more? Click me! • representative stacked two-dimensional barcode Datamatrix, Maxicode, QR Code

  9. Mobile tagging reading devices

  10. How to use mobile tagging • You can download mobile tagging app to scan it.Microsoft tag http://tag.microsoft.com/what-is-tag/home.aspx • Mobiletag reader generator QR code product https://itunes.apple.com/us/app/mobiletag-qr-product- scanner/id324679839?mt=8 • Kuaipai mobile tagging http://as.baidu.com/a/item?docid=4327407&f=web_alad_5_title_2

  11. Examples of mobile tagging

  12. Examples of mobile tagging

  13. Thanks! Contact with us: cj82@njit.edu or you can scan below~
