Gene Regulation

genna avatar
genna
16 diapositives · 343 Views · Jul 22, 2014

This chapter explores the fundamental concepts of gene regulation, particularly how the presence of lactose influences the production of the enzyme lactase. It discusses the mechanism of the lac operon, including the role of the repressor protein and RNA polymerase in regulating gene expression. Additionally, the chapter delves into eukaryotic gene regulation, emphasizing the importance of the TATA box and enhancer sequences in the transcription process. Finally, it highlights the significance of hox genes in developmental biology and how their mutations can impact body plan organization.

#gene regulation #gene regulation ppt #powerpoint #presentation
Gene Regulation - slide 1
01 / 16Gene Regulation
1 / 17

Télécharger la présentation

Gene Regulation
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Gene Regulation How does your body know when to make proteins? Unit 4 – Chapter 12-5

  2. No Lactose Present: • Is lactase made? WHY? • NO, because the repressor protein is blocking RNA polymerase from copying the gene for lactase

  3. With Lactose Present: • What happens to the repressor when lactose is present? • Lactose fits into the active site of the repressor protein, which causes it to release from the operator. RNA polymerase can copy the gene.

  4. Lactose present: mRNA is made • What will happen after all the lactose is broken down? • The repressor protein will grab onto the operator stopping the production of lactase.

  5. lac Operon from Dolan DNA Learning Center • http://teachercenter.insidecancer.org/p/920

  6. Eukaryote and Prokaryote Gene Regulation: • ___________ generally are not found in eukaryotes • Most eukaryotic genes are controlled ___________ and have __________ sequences that are much more ______ than those of the lac operon. Operons Individually Regulatory Complex

  7. Eukaryote and Prokaryote Gene Regulation: • A typical feature in a eukaryotic cell is the presence of a gene sequence about 30 base pairs long with a sequence of ___________ or ___________. This sequence is found directly before the starting point for __________________. This region is known as the _______ TATATA TATAAA RNA Polymerase TATA Box

  8. Eukaryote and Prokaryote Gene Regulation: • What does the TATA box do? • Helps position the RNA polymerase by “marking” the spot just before where transcription will take place. • How do enhancer sequences affect gene regulation? • Allow proteins to bind to DNA opening up tightly packed chromatin so genes can be copied. Also, some use repressor proteins to prevent transcription.

  9. Regulation and Development: • What are hox genes? Genes that control organ and tissue development in various parts of the embryo. Determines organism’s basic body plan.

  10. Regulation and Development 2. How important are hox genes? If they are mixed up, an animal’s body plan will be mixed up; In the wrong order.

  11. Regulation and Development 3. What example does the book give as a possilbe mutation for Drosophila is the hox gees are mutated?

  12. Repeat in hox genes: Double Winged Drosophila

  13. Regulation and Development Side Side 4. Hox genes are located _______by ______ in a single cluster, arranged in the _________ order in which they are expressed in the body. 5. Draw: Exact
