  1. NWD2205 Sales Kit ZyXEL Communications Corp.

  2. Agenda Key Takeaways of NWD2205 Product Introduction Product Introduction Product Position Target Customers Product Appearance Key Selling Points Application Diagram Product Specification Product Comparison Competitor Product Comparison ZyXEL Product Comparison Operation Information

  3. Key Takeaways of NWD2205 Target Customers Headline Description 5 Key Selling Points

  4. Key Takeaways of NWD2205 Target Customers: Notebook or PC users who need to upgrade wireless performance Telco/SP requires wireless N client solution Headline Description: Upgrade Wireless Connection in A Green Way! 5 Key Selling Points: Ultra-compact design for optimal portability Latest 802.11n compliant with data transfer rate up to 300 Mbps Soft AP feature for sharing wireless Internet access One-touch WPS button for easy wireless security setup Green adapter saves energy effortlessly

  5. Product Introduction • Product Introduction • Product Position and Target Customers • Product Appearance

  6. NWD2205Naming Rule Product Category Home Networking > Network Connectivity Device > WLAN Adapter Model Number NWD2205 Marketing Name Wireless N USB Adapter Headline Description Upgrade Wireless Connection in A Green Way!

  7. Product Introduction Compliant with the latest 802.11n standard, the compact-design NWD2205 brings the laptop and PC users the cost-effective way to upgrade the wireless connection at data transfer rate of up to 300Mbps, and backward compatible with the existing 802.11b/g network. It allows you to freely enjoy triple-play -- data, audio, and video streaming with greater wireless coverage at home. The one-touch WPS button makes it easy for users to connect laptops or PCs to a secure wireless network just in seconds. With advanced green feature, NWD2205 can automatically adjust wireless output power by detecting the distance from the device to the wireless access point. When the PC equipped with NWD2205 is close to the wireless access point, NWD2205 can lower the output power to save the unnecessary power consumption. Also, when there is no traffic transmission, NWD2205 will enter power-saving mode to save power consumption.

  8. Positioning Mainstream wireless N USB adapter for upgrading wireless connection of laptop and PC after market Target Customer • Laptop or PC users who need to upgrade wireless performance • Telco/SP requires wireless N client solution

  9. Wireless Client Product Portfolio 802.11n 2T3R Single band 802.11n 2T2R Dual-band 802.11n 1T2R Single band 802.11n 1T1R Single band 802.11g NWD-270N Wireless N-lite USB Adapter NWD-310N Wireless N PCI Adapter NWD-211AN Dual-Band Wireless N USB Adapter NWD-271N Wireless N USB Adapter G-202 Wireless 11g USB Adapter G-302 v3 Wireless 11g PCI Adapter 2010NEW 2010NEW NWD2205 Wireless N USB Adapter NWD2105 Wireless N-lite USB Adapter NWD2105 Wireless N-lite USB Adapter

  10. Product Appearance LED: WLANLED Lighting: Orange WPS Button • Dimension: 36(W) x 18(D) x 6(H) mm • Weight: 3g

  11. Key Selling Points

  12. Key Selling Points Ultra-compact design for optimal portability Latest 802.11n compliant with data transfer rate up to 300Mbps Soft AP feature for sharing wireless Internet access Wi-Fi WMM certified for prioritizing multimedia streaming One-touch WPS button for easy wireless security setup Green adapter saves energy effortlessly

  13. Key Selling Point 1Ultra-compact design for optimal portability Benefit Compact & light-weight design enhances the portability for users Actual Product Comparison NWD2205 NWD2105 NWD-270N NWD-211AN & NWD-271N NWD-211AN & NWD-271N NWD-270N NWD2205/NWD2105

  14. Key Selling Point 2Latest 802.11n compliant with data transfer rate up to 300Mbps* Benefit Connect USB-equipped desktop or notebook to a wireless network at up to 300Mbps* Backward compatible with IEEE 802.11b/g 54 Mbps 11g Wireless Adapter Data Transfer Rate 300 Mbps NWD2205 20 Mbps 11g Wireless Adapter Throughput 90~130 Mbps NWD2205 *The actual data transfer rate may vary depending on the network environment.

  15. Key Selling Point 3Soft AP feature for sharing wireless Internet access Benefit With the built-in soft AP function, NWD2205 enables users to instantly create the wireless network without an additional AP. Just plug NWD2205 to PC or laptops, which link to cable or xDSL modem, and all other wireless-capable devices can connect to the Internet through NWD2205.  Internet Laptop xDSL/Cable Modem NWD2205 Wireless N USB Adapter Game Console

  16. Benefit Enjoy high-quality file sharing and multimedia downloading Enhance users experiences for audio, video and voice application by prioritizing data traffic. Key Selling Point 4Wi-Fi WMM certified for prioritizing multimedia streaming w/o WMM QoS Voice Video Others (web browsers, file transfers, or email) High Priority w/ WMM QoS Prioritize Data Traffic Low Priority

  17. Benefit Secure wireless communications by WEP/WPA/WPA2 Just click one-touch WPS button and easily set up for data encryption Key Selling Point 5One-touch WPS button for easy wireless security setup WPS Button

  18. Power Consumption from low to high Key Selling Point 6-1 Automatically adjust wireless output power • Benefit • NWD2205 can automatically adjust wireless output power by detecting the distance from the device to the wireless access point. When the PC equipped with NWD2205 is close to the wireless access point, NWD2205 can lower the output power to save the unnecessary power consumption. NWD2205 Wireless Distance AP

  19. Key Selling Point 6-2 Power-saving mode when no traffic • Benefit • When there is no traffic transmission, NWD2205 will enter power-saving mode to save power consumption. Up to 35% Power Saving No Air Traffic Air Traffic NWD2205 Wireless N USB Adapter AP Enter Power-Saving Mode

  20. Application Diagram Internet NWD2205 Wireless N USB Adapter xDSL/Cable Modem NBG-419N Wireless N Home Router NWD2205 Wireless N USB Adapter

  21. Wi-Fi 802.11n compliant with the data transfer rate up to 300 Mbps • Configurable QoS ensures smooth delivery of user’s most important activities per the priority user set • Green product with wireless on/off switch and easy • set-up wireless scheduling for saving energy • Friendly user interface for fast function navigation • and setup • WPS button provides secure data transmission with • simple security setup NBG-419N Wireless N Home Router Works Best With Router • 802.11n compliant, data transfer rates of up to 300 Mbps • Gigabit Ethernet ports provide higher wired speed • 3 detachable antennas for maximal stability and wide-range • coverage • 2 IPSec VPN tunnels for secure data transfer between • remote sites and the central server • Advanced Media Bandwidth Management (MBM v2™) for • effective multimedia bandwidth allocation NBG-460N Wireless N Gigabit Router with VPN

  22. Works Best With • 300 Mbps wireless N with Gigabit Ethernet for optimized media streaming with whole-home coverage • TR-069 remote management for easy installation • Multiple SSIDs for secured private access and public access sharing • Utilization of firewall protection • VLAN enables efficient bandwidth allocation for the triple-play services* NBG4604 Wireless N Gigabit Managed Router *Future support Router • 300 Mbps wireless N with Gigabit Ethernet for optimized media streaming with whole-home coverage • NetUSB™ shares the USB devices wirelessly • Friendly user interface for fast function navigation and setup • Eco-friendly products with power and wireless on/off button • Configurable QoS ensures smooth delivery of users’ most important activities per the priority user set • Online auto-upgrade firmware service for convenient feature enhancement • Multiple SSID for separating access privileges for private and public access • WPS button for quick and easy wireless security setup NBG4615 Wireless N Gigabit NetUSB Router

  23. Works Best With • Wi-Fi 802.11n compliant with the data transfer rate up to 300 Mbps • Easy to extend the wireless network coverage • 5-in-1 operation modes: access point, WLAN Client, WLAN • bridge, WDS repeater, and universal repeater • Multiple SSID for separating access privileges • (secured and guest) • WPS button provides secure data transmission with • simple security setup AP WAP3205 Wireless N Access Point

  24. Product Specification

  25. Product Specification (1/2) Hardware Specifications • Operation voltage: DC 5V • 1 WPS button with Link/Act LED • 1 USB 1.1/2.0 port • Power consumption • Transmit: 315mA • Receive: 250mA • System Specifications • Compliant with 802.11n specification • Backwards compatible with 802.11 b/g • Wireless Data Transfer Rate • Transmit: 300Mbps* • Receive: 300Mbps* • Wi-Fi Multimedia (WMM) Support • Wireless Security • WEP, WPA. WPA-PSK, WPA2, WPA2-PSK, 802.1x** • WPS hardware button, WPS software feature • Soft AP mode support • Wireless green feature • Automatically adjust wireless output power by wireless distance between the NWD2205 and wireless access point • Enter power-saving mode when no traffic *The actual data transfer rate may vary depending on the network environment. **802.11x supports on Windows XP/Vista/7 OS, not support on MAC OS

  26. Product Specification (2/2) Certifications • FCC/CE/IC/NCC • Wi-Fi 11b/g/n, WMM, WPS • Windows XP/Vista/7 OS Support • Microsoft Windows XP/Vista/7 (32/64 bit) • MAC OS X v10.4/v10.5/v10.6 • Physical Specifications • Item weight: 3 g (0.01 lb) • Item dimension: 36 (W) x 18 (D) x 6 (H) mm (1.42(W) x 0.71(D) x 0.24(H) inch) • Package weight: 81 g (0.27 lb) • Package dimension: 95 (W) x 20 (D) x 135 (H) mm (3.74 (W) x 0.79 (D) x 5.31 (H) inch) Environmental Specifications • Operating Environment: • Temperature:0℃~50C / 32℉ ~ 122℉ • Humidity (non-condensing): 20% ~ 90% • Storage Environment: • Temperature: -30℃~ 70C / -22℉ ~ 158℉ • Humidity (non-condensing): 10% ~ 90%

  27. Product Comparison Wireless N USB Adapter Competitive Comparison Matrix Wireless N USB Adapter Family Comparison Matrix

  28. Competitive Comparison Matrix Note: TRENDnet also have compact-size 1T2R wireless USB dongle.
