  1. Training Program

  2. Razr i-Board Training Program • Razr i-Board Introduction • Software and Installation • Software basic function • Writing, Erasing and Moving function • Screen annotation and other tools to collaborate with media • Video recording • Summary and Q&A • Assessment

  3. Razr i-Board Training Program Razr i-Board Introduction

  4. Razr i-Board Product • Made of aluminum for robustness • User friendly english and thai interface • Big touch screen. Operating with your finger • Safe and simple connection with a USB cable to computer

  5. Razr i-Board Product • Infrared Sensor technology for quick response • No need special pen x

  6. Razr i-Board Product • NewInfrared Sensor technology HID which provide Multi Touch operation in Windows7 and dual writing in Razr i-Board software.

  7. Razr i-Board Product • Support Windows Touch Pack which can be download and install to use with Razr i-Board

  8. Razr i-Board System • Razr i-Board • Projector • Computer • Whiteboard Software

  9. Making connection • Connect USB cable to i-Board and computer. Always use the same USB port on computer for quick and smooth startup.

  10. Razr i-Board Training Program Software and Installation

  11. installation White Board • Whiteboard can work under Windows XP, Windows Vista, and Windows 7 • Desktop and Laptop • Pentium4or higher • Ram 1GB or higher • Require space140 Mb on harddisk • License software with unlimited installation • Download new version atwww.chinavut.com

  12. Installation steps 1 Double click to install Click to install Install from software CD

  13. Installation steps 2 ClickNext 3

  14. Installation steps 4 Chooseboth User Name and Company Name ChooseComplete thenclickNext 5

  15. Installation steps Restartthe computer by click Finish. Please save all your works before restart. 5

  16. Checking the connection Disconnected Connected

  17. Calibration • Calibration is the process to match the position of finger to the cursor in computer.

  18. Calibration13 positions 10 11 2 3 4 9 1 5 8 7 6 12 13

  19. Touch to control computer • Teacher can easily control everything on computer by finger. • Click, Double click and Right click can be operated with the finger same as mouse. • i-Board will be the bigtouch screen to enhance and ease your teaching.

  20. Razr i-Board Training Program Software basic function

  21. Familiar User Interface Whiteboard Ms PowerPoint

  22. Working inWhiteboard software • There are 3 ways to open the software • Double clickWhiteboard icon • Pick up pen from pen tray • Click on Shortcut icon on both side of i-Board

  23. Whiteboard Software Interface Date, Time Page Index Page Toolbar When you are in Whiteboard mode

  24. Whiteboard Toolbar Different Toolbar adjustment

  25. Basic functions To access more functions and tools To switch between WindowsandWhiteboard To add new slide To remove current slide

  26. Basic functions To access more functions and tools

  27. Basic functions Switch mode To switch betweenWindows andWhiteboardmode. Similar to minimize button.

  28. Basic functions To add new slide

  29. Basic functions To remove current slide

  30. Basic functions Zoom out and Zoom in

  31. Basic functions Backward and Forward slide

  32. Basic functions Undo ReUndo To roll back your previous change. This cannot be apply to screen annotation.

  33. Razr i-Board Training Program Writing, Erasing and Moving function

  34. Writing tools 5 writing tools Pen Intelligent Pen Line size Brush Pen color Laser Pen Highlight Pen

  35. Pen Normal line effect just like whiteboard pen or ball-point pen.

  36. Brush Thick and thin line effect can be made with this tool. Choose big line size to get better effect from Brush tool.

  37. Brush Brush for drawing in art and writing will get the effect by moving your writing fast and slow.

  38. Laser Pen To make a single point of interesting at a time.

  39. Highlight Pen To highlight interesting position or sentence. If you want to highlight on screen annotation, please add new Windows page.

  40. Highlight Pen To highlight on the text and picture.

  41. Intelligent Pen To easily, quickly and perfectly draw basic figures.

  42. Intelligent Pen Quickly draw the bar graph.

  43. Intelligent Pen To show the property of figure drawing with intelligent pen. Choose figure with select tool.

  44. Intelligent Pen Fill color, Change line color, Change line format and Set transparency

  45. Intelligent Pentray Line color will be automatically changed by pick up the pen.

  46. Erase Eraser Region Eraser Clear All Pixel Eraser

  47. Move Touch the button or touch on i-Board with 3 or more positions. Can move in every direction without Limit.

  48. Bird’s eye To view everything over the scope of page in 1 page.
