1. SP2013 app infrastructure and configuration and isolation Vesa Juvonen Principal Consultant Microsoft

2. Infrastructure configuration for SP Apps • Wild card DNS entry for app domain • Apps service application and subscription service created in environment hosting SP apps • SharePoint application for routing the incoming requests to app DNS entry • App catalog created for Apps for SharePoint to enable end users to utilize apps http://*.apps192.168.x.x

3. DNS configuration on-premises • Define wildcard DNS entry for apps • *.appscontoso.com or something similar • Notice that it’s recommended to create own domain, not use just sub domain due security reasons • Configure app address in SP side using Central Admin or PowerShell • One address per farm • PowerShell cmdlet’s • Get-SPAppDomain • Set-SPAppDomain

4. App configuration for on-premises farm • Ensure that App service application and subscription service are created and running in farm • Apps will be hosted on own domain • Leverages web browser same-origin policy for script isolation • URL naming – each app has unique URL – one app – one = URL • http://default-appUID.appscontoso.com • appUID – combination of unique identifier for site collection and particular SPWeb where app is installed app1 SharePoint site main SharePoint site tenant-uniqueID.appdomain http:// /appname/etc http://intranet.contoso.com http://default-9ac5d88f52de26.appscontoso.com/TrafficCameras/pages/default.aspx

5. Enterprise deployments – Single Farm Setup SharePoint Farm http://my.contoso.com192.168.1.2 http://intranet.contoso.com192.168.1.2 http://teams.contoso.com192.168.1.2 192.168.1.2 No Host Header192.168.1.2 NLB APP DNS:*.contosoapps.com = 192.168.1.2 http://default-87e90ada14c175.contosoapps.com

6. 4 • 5 • 1 • 3 • 2 Enterprise deployments – Follow The Request SharePoint Farm Request Gets Picked Up • 192.168.1.2 • Not using a Host Header so listens to all requests • SharePoint routes and serves from appropriate web app 192.168.1.2 5 *.contosoapps.com = 192.168.1.2 NLB ? APP DNS http://default-87e90ada14c175.contosoapps.com

7. https://*.contosoapps.com192.168.1.2 https://*.teamapps.com192.168.1.2 Enterprise deployments – Multi-farm options Corporate Farm Collaboration Farm http://intranet.contoso.com192.168.1.2 http://mysite.contoso.com192.168.1.3 http://teams.contoso.com192.168.1.3 192.168.1.2 192.168.1.3 NLB NLB APP APP

8. DNS vs. IIS configuration http://my.contoso.com192.168.0.3 http://intranet.contoso.com192.168.0.3 http://teams.contoso.com192.168.0.3 Host name – intranet.contoso.com IP Address – unassigned Host name – teams.contoso.com IP Address – unassigned Host name – unassigned IP Address – unassigned Host name – mysite.contoso.com IP Address – unassigned http://*.contosoapps.com192.168.0.3 192.168.0.3 APP

9. Extranet with split-back-to-back with split DNS SharePoint Farm NLB DMZ Corporate SSL Certification *.appcontoso.com App domain: appscontoso.com Example: https://default-10d7ae858e96d0.appscontoso.com/eventapp

10. Get app to site collection • All site content provides functionalityto add apps • Both SharePoint store and corporate catalog visible from single place • Users can add Apps to be available at the site • Apps can request permissions, which depending on implementation for operations using oAuth

11. Design Considerations for App infrastructure • You should always use SSL on web applications if you are using SharePoint Apps • Access tokens are included with requests, blocks cookie replay attacks • Your app domains should not be child domains • If your web apps are *.contoso.com, do not make app domain *.apps.contoso.com, instead make it something like *.contosoapps.com • Dedicated app domain is more secure with certain browsers • Apps for SharePoint on web applications using SAML authentication have special requirements on the FedAuth server/identity provider that most don’t support today • SharePoint Apps do not support multiple zones (i.e. AAM); all requests are served out of the default zone • Apps for SharePoint are however fully supported in Secure Site Access and host header site collections model which is the recommended approach for all deployments • You need to ensure that application pool account used for ”routing” application has sufficient permissions to other SharePoint applications • Easiest way to achieve this is to use same application pool account cross web applications

12. Demo Apps in details Installation, deployment, usage, configuration…
