  1. Processor ICPSC 321 Andreas Klappenecker

  2. Midterm 1 • Thursday, October 7, during the regular class time • Covers all material up to that point • History • MIPS assembly language programming • Computer arithmetic • MIPS architecture • Review on Tuesday, October 5

  3. Administrative Issues • Allen Parish will not have a help session this Friday, but again in subsequent Fridays. • I will have extra office-hours this Friday, 10:30am-11:30am. • There will be no office hours on Tuesday morning (PhD defense).

  4. Questions? Problems?

  5. Today’s Menu The Processor: Datapath and Control

  6. The Processor: Datapath and Control We want to implement portions of MIPS • memory-reference instructions: lw, sw • arithmetic-logical instructions: add, sub, and, or, slt • control flow instructions: beq, j We ignore multiply, divide, and other integer and floating point instructions.

  7. Five Execution Steps • Instruction Fetch • Instruction Decode and Register Fetch • Execution, Memory Address Computation, or Branch Completion • Memory Access or R-type instruction completion • Write-back step

  8. Implementations All right, give us the details if you can’t help it!

  9. 1) Fetch Instructions • A memory unit is used to hold and supply the instructions given an address • A state element, called the program counter, determines the address • We need an adder to increment the program counter to the address of the next instruction.

  10. 2) Decode Instructions & Fetch Registers Premise: We do not know at this point which instruction we ought to execute. BUT, we can do some speculative executions: • We can fetch the registers using the bits 21-25 and 16-20 of the instruction • Which instructions do not need this information? • The branch command uses bits 0-15 of the instruction (=> sign-extend to 32 bits).

  11. Instruction Word Formats Register format Immediate format Jump format 0 rs rt rd shamt funct 6 5 5 5 5 6 op-code rs rt immediate value 6 5 5 16 op-code 26 bit current segment address 6 26

  12. 3) Execution, Address Calculation, or Branch Completion • Execution (depending on instruction) • compute a memory address (lw and sw) • compute an arithmetic result (int ops) • compare (for a branch) and set PC to appropriate address The content of the registers are used as an input to the arithmetic-logic unit. The instruction decode sets the appropriate control signals.

  13. Role of the ALU The output of the arithmetic logic unit is • written to a register in the case of arithmetic-logical instructions • used as an address in the case of load and store instructions • used to determine the next instruction address for branch instructions The ALU has a great variety of roles!

  14. 4) Memory Access or R-Type Instruction Completion For load and store instructions, the address ALU_Out calculated by the arithmetic-logic unit is used for memory reference: • read MDR = Mem[ALUOut] or • store Mem[ALUOut] = B For arithmetic-logical instructions, write the result of the operation into the destination register (Actually, this is the description for the multi-cycle processor)

  15. 5) Write-Back Load instructions complete by writing back the value from the memory.

  16. Design Choices We can implement the MIPS processor as a • single-cycle processor or as a • multi-cycle processor. We will use a synchronous design, so the clocking strategy will be important. The control unit will be simpler for the single-cycle processor, so we start with that.

  17. Simplified Datapath • Abstract, simplified view • Two types of functional units: • elements that operate on data values (combinational) • elements that contain state (sequential)

  18. Combinatorial and Sequential Elements • The ALU is a combinatorial element • Other elements of the design are not combinatorial, but contain a state • An element with some internal storage is called a state element • State elements have at least two inputs: • data • clock (determines when data is written)

  19. falling edge cycle time rising edge Clocking Methodology • We need to decide when signals can be read and written • We need to specify timing behavior • For simplicity, we assume an edge-triggered clockingstrategy (synchronous design) • All storage elements are updated on either raising edge or falling edge:

  20. Synchronous Design • Typical execution: • read contents of some state elements, • send values through some combinational logic • write results to one or more state elements

  21. D-latch • Two inputs: • the data value to be stored (D) • the clock signal (C) indicating when to read & store D • Two outputs: • the value of the internal state (Q) and it's complement

  22. D flip-flop Output changes only on falling clock edge

  23. Summary • We will use D-flip flops to build the register file • We gradually build up the datapath • Simple components will allow us to do this • We add the control logic a little later • You will need a firm understanding of logic design • Study Chapter 4, read Appendix B

  24. Instruction Fetch • Use PC to find new instruction • PC = PC + 4, preparing for next instruction

  25. Instruction Fetch + PC update

  26. R-Format Instructions Register format op: basic operation of instruction funct: variant of instruction rs: first register source operand rt: second register source operand rd: register destination operand shamt: shift amount op-code rs rt rd shamt funct 6 5 5 5 5 6

  27. Implementing R-Format Instructions • R-Format ALU operations need the register file • and an implementation of the ALU

  28. Register File • Built using D flip-flops • How can we realize it?

  29. Reading the Register File Multiplexers select the outputs

  30. D flip-flop Output changes only on falling clock edge

  31. Writing into the Register File • log n+1 input bits address n+1 registers • Falling edge of clock signal determines when to write

  32. Implementing Loads and Stores Register file, ALU, data memory unit, sign extension unit

  33. Datapath for a load and store • register access • memory access calculation • read or write from memory • in the case of a load, write into register file

  34. Datapath for a Branch Use ALU to evaluate the branch condition, another adder for branch target = PC + 4 + (sign extended 16 bits)>>2

  35. Summary • Found implementations for R-format instructions • Found implementations for loads and stores • Found implementations for branches • We need to compose these datapaths • Simplicity of the implementations is striking!
