1. Lithography Advanced

2. Lithography: Advanced • Key parameters: • resolution • alignment (or misalignment) • depth of focus • Resolution: • indicates the smallest feature (or space) that can be produced • One of the limiting factors is wavelength of the light used

3. Lithography: Resolution • Resolution and other parameters • Depth of Focus or Depth of Field (DOF) • Details Later • We need small s and large DOF

4. Lithography: OPC Resolution Enhancement Techniques (RET) • Optical Proximity Correction • To ‘accommodate’ for diffraction effects • Presence or absence of other features nearby (proximity) will affect the optical behavior • Corrections are made in the layout to account for it (Hence, Optical Proximity Correction or OPC) • Anti Reflective Coating (ARC) • Phase Shift Masks

5. Lithography: OPC Resolution Enhancement Techniques (RET) • Optical Proximity Correction • To ‘accommodate’ for diffraction effects Real Ideal Mask Resist • Presence or absence of neighboring features will alter the width / space of the feature

6. Original After Bias M1 layout M1 layout Lithography: OPC Resolution Enhancement Techniques (RET) • Biasing • OPC • Rule based (simple rules, reasonably effective) • Model based (more complicated, computationally intensive, better)

7. 2 Lithography: OPC Resolution Enhancement Techniques (RET) • Biasing (zoomed picture) Width is changed (usually increased) Line End is changed (usually extended) 1 • The idea is, after photolithography using mask with structure 2, the resulting structure will be close to what we planned originally (structure 1) • i.e. We try to account for non-idealities in the lithography process

8. 3 1 2 Lithography: OPC Resolution Enhancement Techniques (RET) • Other corrections A “Tee” may not “print” correctly • What we want is structure 1 • If we make a mask like structure 1, we will end up getting structure 3 • Hence, we make a plan like structure 2 to obtain on the wafer what we want • Add “dog ears” to the lines

9. 1 2 Lithography: OPC Resolution Enhancement Techniques (RET) • Summary • Layout is OPC’ed • Width bias • This is not the same as enlarging the layout. Here, if width is increased, then space is decreased • Other corrections • To account for non-idealities in the ‘printing’ process

10. OPC Example Wafer (after photo? After etch?) Drawn / Pre OPC Post OPC Mask • An example from intel web page

11. OPC vs PPC • Other processes (like etch) also have ‘proximity’ effect • Presence or absence of neighbor will affect how a process behaves for a particular feature • Litho ‘neighborhood’ is about 1 um • Etch neighborhood is probably few microns • CMP neighborhood can be few mm (or many microns) • Correcting for optical (litho) and few other processes is called ‘Process proximity correction’ or PPC • Typically litho + etch corrections are used for PPC • CMP corrections are at a different (larger) scale. • Dummy features

12. Lithography: ARC RET: Anti Reflective Coating • Reflection ==> Standing waves • ARC Animation

13. Intensity Amplitude Lithography: RET RET: Phase Shift Masks (PSM) • Normal Masks • OPC can correct only to some extent • When the space and the width are very small (and similar to wavelength of light used).... • Use Phase Shift Mask (PSM) X

14. Lithography: RET RET: Phase Shift Masks (PSM) • Normal Mask • Phase Shift Mask • Another way to obtain same effect: Etch the glass to different level (schematic in next page)

15. Lithography: PSM

16. Lithography: RET Review • Optical Proximity Correction • Changes in the layout, mask • Anti Reflective Coating • Change in the process • Phase Shift Mask • Change in the Mask • ==> Original layout is first generated • Then modified (to indicate where the change of phase is appropriate) • Computer programs which generate the ‘aerial image’ are used to decide where phase shifting is needed

17. Lithography: Production • Depth of Focus • Alignment • Partial Field/ Full Field

18. Lithography: Production Depth of Focus and Resolution

19. Out of focus Lithography: Production DOF: Focus Exposure Matrix DOF: Focus Exposure Matrix DOF: Focus Exposure Matrix • Exposure is easy to control • Focus: All the parts of chip will NOT be in focus Plane of focus • DOF in the range of micron

20. Lithography: Production DOF: Focus Exposure Matrix • FEM (Focus Exposure Matrix) to obtain process window information Exposure energy Likely shorts; False readings

21. Upper Limit Lower Limit Lithography: Production DOF: Focus Exposure Matrix • Remove the false readings (outliers) • Define the focus window • Note: CD here may be SEM CD or ECD Exposure energy

22. Lithography: Production • Photo Margin • Depth of focus and exposure margins are very important, particularly in the BEOL • Very little topography in the FEOL ==> usually sufficient photo margin exits • Misalignment • How well can one align to the previous layer? • Should one align to the previous layer or to a standard layer? • Typically a tolerance in the range of +/- 60 nm

23. Lithography: Production Alignment • Statistical Process Control (SPC) • Misalignment measured for example, on 2 wafers in a set of 25 wafers (lot) • In each (of the two) wafers, it may be measured in 5 points (minimum) to perhaps 49 points • Average x misalignment for each wafer is plotted (and similarly y misalignment is plotted) • Each misalignment must be below the absolute spec limit. Average must also be below the upper and lower spec

24. Lithography: Production Alignment • Alignment marks: • Box in box, cross • overlay budget • Statistical Process Control (SPC) Example data Misalignment vs run UL (upper limit) LL (lower limit)

25. Field (one ‘shot’) Has 9 chips (for example) Partial Field (one ‘shot’) Has < 9 chips on the wafer Lithography: Production Partial Fields at the edges of the wafer • Partial Fields/ Full fields

26. Lithography: Production Partial Fields at the edges of the wafer • So what? • Why chips in partial fields? • Use the available space in the wafer • Many processes are ‘pattern dependent’. Uniform pattern makes the process ‘behave’ better. More on this latter • If the partial field regions are left blank, such processes will not give ‘good results’ • What is wrong with using chips in the partial field?

27. Lithography: Production Partial Fields at the edges of the wafer • Significant number of chips are in partial fields ( the example in previous page is an exaggeration though) • The chips cannot be just thrown away (working chip == money) • All the partial field chips are in the edge • Majority of processes have center/edge variations and usually the edge chips are affected (partial field and full filed edge chips) • Automatic Focus algorithms are not very effective for partial field • Some of the ‘locations’ in the mask, which are used for determining focus, may fall out of the wafer, in the partial fields • Hence Partial field chips fail more • One solution: Modify algorithm for determining focus at partial fields • Optimize chip placements • Edge exclusion (for many processes)

28. Lithography: Production Review • Depth of Focus • Improved by CMP • Alignment • Alignment marks • Partial Field/ Full Field • Tweak focus algorithms • Optimize the field locations to obtain maximum number of ‘good chips’ (which is not always the same as maximum number of chips possible)

29. Lithography: Extra • What happens for monochromatic vs other light? • Refractive vs Reflective system • Weight/ curvature • Generation • Resolution/ Accuracy • Fiducials - alignment references • Closure checks • Klaris - KLA references

30. Lithography: Extra • Projection Printing : • Mask fabrication (size) • Mask cost • Alignment • Defect size • Higher cost & Maintenance

31. Lithography: Extra • Modulation Transfer Function (MTF) • M = (Imax-Imin)/ (Imax+Imin) • X-Ray Lithography (parallel) • E Beam Lithography (serial) • X-Ray : 1x mask, non-defect forming • Resist: no effect from x-ray induced photo electrons • Mask: from silicon substrate/ Ta barrier
