  1. PHYSICS OF NUCLEAR WEAPONS

  2. Nuclear Binding Energy

  3. Nuclear Stability

  4. Weapon Types • Fission

  5. “Little Boy”

  6. “Fat Man”

  7. Weapon Size

  8. Nuclear Weapons & States

  9. The Fission Reaction 200 MeV/240 ≈ 0.8 MeV/nucleon ≈ 1,000,000 X Echemical

  10. Weapon Types • Fusion

  11. Two-Stage Thermonuclear

  12. The Fusion Reaction 17.6 MeV/5 ≈ 3.5 MeV/nucleon ≈ 5 X Efission

  13. Comparison of Fission & Fusion

  14. Paths to Fissionable Material

  15. Nuclear Fuel - Uranium • Ore → Yellow Cake → Enriched

  16. Uranium Deposits

  17. Uranium Deposits

  18. UraniumEnrichment Slightly Enriched (SEU): 0.9%-2.0% Used in Heavy-Water Reactors (HWR) Low-Enriched (LEU): 2%-20% 3%-5% used in Light-Water Reactors (LWR) 12%-19.75% used in Research Reactors Highly Enriched (HEU): >20% ≥ 85% used in weapons primaries ≥ 20% ‘weapons-usable’ in implosion designs 40%-80% used in secondary of two-stage ≥ 20% used in fast neutron reactors 50%-90% used in naval reactors 26.5% in commercial fast reactors

  19. CriticalMass

  20. Critical Masses TABLE A-1 Properties of Nuclear-Explosive Nuclides

  21. Comparison of Energy Content • Fission of U-233: 17.8 kt/kg • Fission of U-235: 17.6 kt/kg • Fission of Pu-239: 17.3 kt/kg • Fusion of pure deuterium: 82.2 kt/kg • Fusion of tritium and deuterium (50/50): 80.4 kt/kg • Fusion of lithium-6 deuteride: 64.0 kt/kg • Fusion of lithium-7 deuteride: • Total conversion of matter to energy: 21.47 Mt/kg • Fission of 1.11 g U-235: 1 megawatt-day (thermal) Broader comparison of Energy Densities

  22. Enrichment Process

  23. Uranium • Isotopic Masses and Abundances • 235U Abundance = 0.720% • 238U Abundance = 99.274% • 235U Mass = 235.04393 (UF6, 349.03433) • 238U Mass = 238.05079 (UF6, 352.04119) • m238/m235 = 1.0086 • = 1.0043 → = 1.0043

  24. UF6

  25. Enrichment Methods • Electromagnetic (Calutron) (≤ 15% enrichment)

  26. Enrichment Methods • Gaseous Diffusion

  27. Enrichment Timeline

  28. Enrichment Methods • Thermal Diffusion

  29. Enrichment Methods • Gas Centrifuge

  30. Centrifuges • Materials: Aluminum → Maraging Steel → Carbon Fiber Composite • 100,000 rpm (balanced, magnetic bearings) • STUXNET

  31. Enrichment Methods • LASER Techniques (AVLIS/MLIS)

  32. Method Comparison

  33. Resources • IAEA/INFCIS • The Atomic Archive • World Nuclear Association • Nuclear Chemistry • Federation of American Scientists • Nuclear Pathways • ALSOS Digital Library • Nuclear Safeguards Education Portal • World Information Service on Energy (WISE) Uranium Project
