  1. Copper Solutions

  2. Product Range LANmark 7 /7A Class F/FA • GG45 Connector • RJ45 Backward compatibility • Cat 7/ Class F 600Mhz • Cat 7A / Class FA 1000Mhz & 1200Mhz LANmark 6A • EVO Based, Screened only • No ALIEN Xtalk TESTING • “Optimising short links” • LANmark 6 • EVO Based • Screened & Unscreened LANmark5 • EVO Based

  3. LANmark RJ45 – from Cat 5 to 6A • Available in screened and Unscreened • Utilises the EVO connector Screened Unscreened

  4. LANmark 5 Cable • Extended drive distances available U/UTP F1/UTP

  5. LANmark 6 Cable • Other options available, Dual shotgun, F2/UTP U/UTP F1/UTP

  6. LANmark Patch cords Solid Core LeadsCut in Half and used as CP/Service PresentationAvailable as standard in 20 & 30m Lengths LANmark 5 & 6 screened & Unscreened Multi Coloured Retro-Fit Hoods Over moulded stranded Patch cords

  7. 10G & 6A • The term 6A and 10G are often mixed up in the same sentence showing that there is still some confusion regarding the requirements for 10Gbit over copper. • The IEEE specified the protocol requirements issued under IEEE 802.3an. • Detailed within this standard is the minimum requirements for the data cabling. • The ISO and TIA standards bodies have issued cabling standards that meet and greatly exceed the IEEE minimum requirements under Class EA at 6A respectfully. • Nexans are able to offer a cost effective solution to meet the IEEE 10G requirement as well as an outstanding solution for Class EA / 6A. • Introduced within these standards is a new parameter called “Alien CrossTalk”.

  8. Alien Cross Talk • Alien CrossTalk is the effect of adjacent cables transmissions interfering with each other. • Because of this issue Nexans Cabling Solutions are only offering a screened solution for 10G & 6A Unscreened cable Screened cable

  9. LANmark 6A – 10G Cable • The LANmark 6A/10G cable is available in two constructions F/FTP F1/UTP

  10. LANmark 6A • The LANmark 6A solution is able to Optimise Short Links being able to support Panel to Panel links at 5m. Channels as short as 12m possible • Service Presentation 5m • Patch Cord 1m • Horizontal Link 5m • Patch Cord 1m

  11. LANmark 7/7A • The LANmark 7 GG 45 connector offers full backward compatibility, able to support 6A channels in RJ45 mode 8 contacts 100% RJ45 compatible S/FTP 4 new contacts

  12. LANmark 7A • The 7A solution has two options on the cable. • LANmark-7A S/FTP 1000 MHzN100.371 Upgraded to Cat7A complianceIndividually shielded pairs with overall braid screening7.5mm OD • LANmark-7A S/FTP 1200MHzN100.382 up to 1200 MHzExcellent attenuation performancemaintains thin diameter of 7.8mm OD

  13. LANmark Hardware Angled Snap-in Sliding Snap-in Fixed Snap-in Angled Snap-in Dual

  14. LANmark Hardware

  15. LANmark Hardware Dust cap Consolidation point Coloured Shutters Shown on 12 Way zone box Keystone Adaptors Filler

  16. LANmarkIndustrial & Maritime Hardware Outdoor Cable & Ruggedized Anti Vibration Stainless Steel panel “Din Rail” IP-67 Enclosures

  17. Pre-terminated copper

  18. Impact of pre-termination • Customer • Reduce installation time • Reduce manpower required • Reduce handling • Simplify supply chain • More preparation – less operation • Could help accessing large projects or meet deadlines..

  19. Single units

  20. Single units

  21. Pre-terminated copper

  22. Bundles

  23. Bundles • Cat.6, 6A, 7 and 7A • Screened only • 3 – 4 – 6 – 8 – 12 or 12+12 • Black sleeve up to 30m or spirap

  24. Bundles • Nexans Bundle are laid-up • More flexible • Cables don’t slide or tangle • Connectors remain aligned • For all types of bundles

  25. Bundles

  26. Multipair Cat.6A

  27. Multipair Cat.6A

  28. Multipair Cat.6A • 3x4pr or 4x4pr or 6x4pr • U/FTP LSZH • Patented cable construction • True Cat.6A – Alien Next compliant • Compact – round – performance - unique

  29. Multipair Cat.6A

  30. Multipair Cat.6A

  31. Multipair Cat.6A

  32. 6 port Copper cassettes • Easy to install and remove • Automatic grounding • Reversible in the 3U panel • Easy to install and remove • Fits the 3 types of panels

  33. 1U 24 port Copper cassettes

  34. 1U Angled 24 port Copper cassettes

  35. 3U Vertical 96 Copper port cassettes

  36. Warranty applies • Same condition regarding installer qualifications • Respect length (see installation guideline and calculations) • Field test mandatory • 15 working days between order and availability BEL

  37. LANmark SoftwareVisio Nexans has developed a range of Microsoft Visio templates and stencils to enable both quotes and Operational Manuals to be professionally compiled. Each of the models has a direct link to the product data sheet in our comprehensive on line catalogue to simplify this task. Available Free @www.Nexans.com/eservice

  38. LANmark SoftwareInstallation Toolkit In order to assist our partners carry out quality installations Nexans has developed a series of software tools all packaged together to cover such subjects as; Power Separation, EN50174:2009 changed the complex requirements Cable Stacking Height Calculator, EN50174-2:2009 detailed requirements for this. Cable Fill Calculator, cable diameters have increased, ensuring the correct containment is installed is key to quality installations. Horizontal Link length Calculator, EN50173:2007 details the requirements for LAN design, make sure the different segments, once patched together conform to these requirements. Fibre Selection Tool, make sure you have the correct fibre for the job. This tool can also be downloaded Free from www.Nexans.com/eservice

  39. Thank You
